Hubbell GAI-TRONICS 13310 Series Manual

Confidentiality Notice
This manual is provided solely as an installation, operation and maintenance guide and contains sensitive
business and technical information that is confidential and proprietary to GAI-Tronics. GAI-Tronics
retains all intellectual property and other rights in or to the information contained herein, and such
information may only be used in connection with the operation of your GAI-Tronics product or system.
This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party.

Mounting Instructions

See Figure 1 for the 13310 Series Driver installation configuration with an associated horn and mounting
assembly. The installation of explosion-proof speakers must conform with regulations governing
electrical equipment for hazardous locations and the provisions of the National Electrical Code.
NO ALTERATIONS MAY BE MADE TO THESE DRIVER UNITS!
No holes may be made or holding devices screwed into the case, which may weaken or endanger the
structure after installation. All main bolts on the case housing of the driver must be tightened to
10.8–12.5 ft-lbs. dry (14.6–17 n-m dry).
Wiring may be run in threaded rigid or approved standard electrical flexible conduit with five full threads
engaged. Explosion-proof conduit boxes, junctions, and fittings are of approved type and usually contain
screw-in covers. Unions, elbows, and bends are also of special design.
GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA
610-777-1374
V
ISIT WWW
G A I - T R O N I C S ®
A H U B B E L L C O M P A N Y
13310 Series
Explosion-proof Drivers
Figure 1. 13310 Series Driver Installation
