Page 1 TrimMac 210 INSTRUCTION MANUAL IMPORTANT INFORMATION : Please read these instructions carefully and make sure you understand them before using this unit. Retain these instructions for future reference. MANUEL D’INSTRUCTIONS RENSEIGNEMENTS IMPORTANTS: Avant d’utiliser cet appareil, veuillez lire atentivement les instructions et assurez- -vous de les avoir comprises. Conservez les instructions pour référence ultérieure.
Page 2: Identification Of Symbols
IDENTIFICATION (WHAT IS WHAT?) Fuel tank Assist handle Manual Tube Wrench ON/OFF Switch Throttle Choke Assist handle adjustment Trimmer head Shield Muffler Starter Handle Primer Bulb IDENTIFICATION OF SYMBOLS WARNING! This trimmer can be dangerous! Careless or improper use can cause serious or even fatal injury.
Page 3: Safety Rules
S Maintain unit according to recommended procedures. Keep cutting line at proper length. WARNING: S Use only 2 mm diameter McCulloch® Trimmer line throws ob- brand line. Never use wire, rope, string, jects violently. You and others can be blinded/ etc.
Page 4: Special Notice
CUTTING SAFETY S Store unit and fuel in an area where fuel va- pors cannot reach sparks or open flames WARNING: from water heaters, electric motors or Inspect the area before switches, furnaces, etc. each use. Remove objects (rocks, broken S Store unit so line limiter cannot accidentally glass, nails, wire, etc.) which can be thrown cause injury.
Page 5: Operation
OPERATION Starter Handle WARNING: Be sure to read the fuel information in the safety rules before you be- gin. If you do not understand the safety rules, do not attempt to fuel your unit. Contact an authorized service dealer. FUELING ENGINE Choke Lever WARNING:...
Page 6: Starting A Flooded Engine
NOTE: CUTTING METHODS If engine has not started, pull starter rope 5 more pulls. If engine still does not run, it WARNING: is probably flooded. Use minimum speed and do not crowd the line when cutting around STARTING A FLOODED ENGINE hard objects (rock, gravel, fence posts, etc.), Flooded engines can be started by placing which can damage the trimmer head, become...
Page 7: Maintenance
MOWING - - Your trimmer is ideal for mowing SWEEPING - - The fanning action of the rotat- in places conventional lawn mowers cannot ing line can be used for a quick and easy reach. In the mowing position, keep the line clean up.
Page 8: Service And Adjustments
SERVICE AND ADJUSTMENTS REPLACING THE LINE 10. Pull the line extending outside of the hub to release it from the notch. 1. Move the ON/OFF switch to the OFF position. CARBURETOR ADJUSTMENT 2. Disconnect the spark plug lead wire. 3. Remove spool by firmly pulling on tap but- WARNING: Keep others away when ton.
Page 9: Troubleshooting Table
S Check entire unit for loose screws, nuts, OTHER and bolts. Replace any damaged, broken, S Do not store gasoline from one season to or worn parts. another. S At the beginning of the next season, use S Replace your gasoline can if it starts to rust. only fresh fuel having the proper gasoline to oil ratio.
Page 10: Declaration Of Conformity
We, Electrolux Home Products, Inc., Texarkana, TX, 75501, USA, Tél. : +1 903 223 4100, declare under sole responsibility that the McCulloch model TrimMac 210 grass trimmer was assessed in accordance with Annex V of the DIRECTIVE and from serial numbers 2001- -305N00001 and onwards, conforms to the provisions of the DIRECTIVE.
Page 11: Technical Data Sheet
TECHNICAL DATA SHEET ODEL: TrimMac 210 ENGINE Displacement, cm Maximum engine power, measured in accordance with ISO 8893, kW ENGINE ROTATIONAL SPEEDS At maximum engine power 8000 Recommended maximum speed 8000 Recommended speed idling 4000 FUEL AND LUBRICATION SYSTEM Fuel tank volume capacity, cm...
