1/22/09 5:04 PM Page 1 ENGLISH DV454 / DV487 As an E Partner, NERGY ® LG has determined that this product or product models meet the E ® guidelines for NERGY energy efficiency. ® is a U.S. registered mark. NERGY...
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 2 CAUTION: The apparatus shall not be exposed to water (dripping or splashing) Safety Precaution and no objects filled with liquids, such as vases, shall be placed on the appara- tus. CAUTION CAUTION concerning the Power Cord RISK OF ELECTRIC SHOCK Most appliances recommend they be placed upon a dedicated circuit;...
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 3 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 5 Hooking up the unit Hooking up the unit - more you can do Component Video Connections Audio and Video Connection Connect the COMPONENT(VIDEO)/PROGRESSIVE SCAN(YP The unit Audio/Video jacks are color coded (yellow for video, red for right audio OUTPUT jacks on the unit to the corresponding input jacks on your TV using and white for left audio).
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 6 Remote Control OPEN/CLOSE POWER (1) Opens and closes the disc tray. Switches the unit ON or OFF. CLEAR Removes a track number on the Program SCAN (m / M) List. Search backward or forward.
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 7 Main Unit DV454 DV487 a 1/I (Power) g VOL. Turn the unit ON or OFF. Adjust microphone volume. b Disc Tray h USB Port (DV487 only) Insert a disc here. Connect an USB Flash Drive.
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 8 Display Mode – If you selected 4:3, you’ll need to define how you would like Adjust the settings widescreen programs and films to be displayed on your TV screen. [Letterbox]: This displays a widescreen picture with black bands at the top ON REMOTE and bottom of the screen.
All the downloaded videos from DivX ® VOD can only be played back on this unit. Game (DV454 only) – You can play games with this unit using remote control. (See “Game” on page 15) [Select]: The game menu appears on the TV screen.
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 10 Pause a playback Playing a Disc Press PAUSE/STEP (X) to pause playback. Press PLAY ( ) to continue playback. ON REMOTE 1 Open the disc tray: OPEN/CLOSE Frame-by-Frame playback DivX Press PAUSE/STEP (X) repeatedly to play Frame-by-Frame playback.
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 11 Watching a enlarged video image DivX Playing a DivX movie file During playback or pause mode, press ZOOM repeatedly to select zoom mode. You can move through the zoomed picture using vVb B buttons.
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 12 MP3/WMA music file requirement Listening to Music Disc or files MP3/WMA compatibility with this unit is limited as follows: ON REMOTE • File extensions: “.mp3”, “.wma” 1 Open the disc tray: OPEN/CLOSE • Sampling frequency: within 8 - 48 kHz (MP3), within 32 - 48kHz (WMA) •...
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 13 Listening to music during slide show VOICE – If you wish to sing a duet with the recorded karaoke singer, select a voice you desire. You can listen to music during slide show, if the disc contain music and photo Output files together.
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 14 The making of unauthorized copies of copy-protected material, including computer USB Direct Recording (DV487 only) programs, files, broadcasts and sound recording, may be an infringement of copyrights and constitute a criminal offence. Connect USB Flash Drive to the unit before recording.
11:59 AM Page 15 Hitrat Playing a Game (DV454 only) The rat hides in 1 of 9 holes. Hit the rat when it appears, one time matching hit makes one score. The time is limited to within 90 seconds. ON REMOTE...
DV454.487-SN.AMEXLLK_7006_ENG 1/19/09 11:59 AM Page 16 Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Language Code Language Code Afar...
Plug the power cord into the wall Power consumption 10 W outlet securely. Dimensions (Approx.) DV454: 360 x 35 x 200 mm DV487: 430 x 35 x 200 mm The power is on, No disc is inserted. Insert a disc.
