1415

Heavy Duty Gas Grill

Gril Résistant de Gaz

OWNER'S MANUAL / NOTICE D'UTILISATION

ASSEMBLY AND OPERATING INSTRUCTIONS

INSTRUCTIONS D'ASSEMBLAGE ET D'UTILISATION

SAVE THIS MANUAL FOR FUTURE REFERENCE

CONSERVER CETTE NOTICE POUR RÉFÉRENCE

WARNING/AVERTISSEMENT

NOTICE TO INSTALLER:

HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS AND INSTRUCTIONS

LEAVE THESE INSTRUCTIONS

ARE IGNORED. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS

WITH THE GRILL OWNER FOR

MANUAL TO AVOID PERSONAL INJURY, INCLUDING DEATH OR PROPERTY DAMAGE.

FUTURE REFERENCE.

UNE EXPLOSION DANGEREUSE RISQUE DE SE PRODUIRE SI CES AVERTISSEMENTS

AVIS À

ET INSTRUCTIONS SONT IGNORÉS. LIRE ET RESPECTER TOUS LES

AVERTISSEMENTS ET INSTRUCTIONS DE CETTE NOTICE POUR ÉVITER DES

L'INSTALLATEUR:

BLESSURES GRAVES, VOIRE MORTELLES, OU DES DÉGÂTS MATÉRIELS.

REMETTRE CETTE NOTICE AU

PROPRIÉTAIRE POUR QU'IL

PUISSE S'Y RÉFÉRER PLUS

TARD.

Table of Contents

Summary of Contents for BRINKMAN 1415

Page 1 1415 Heavy Duty Gas Grill Gril Résistant de Gaz OWNER’S MANUAL / NOTICE D’UTILISATION ASSEMBLY AND OPERATING INSTRUCTIONS INSTRUCTIONS D’ASSEMBLAGE ET D’UTILISATION SAVE THIS MANUAL FOR FUTURE REFERENCE CONSERVER CETTE NOTICE POUR RÉFÉRENCE WARNING/AVERTISSEMENT NOTICE TO INSTALLER: HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS AND INSTRUCTIONS LEAVE THESE INSTRUCTIONS ARE IGNORED.
Page 2 IMPORTANT SAFETY WARNINGS WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR GRILL.
Page 3: Table Of Contents
TABLE OF CONTENTS General Warnings ..........3 Installation and LP Cylinder Specifications and Safe Use.
Page 4: General Warnings
GENERAL WARNINGS WARNING • Never use natural gas in a unit designed for liquid propane gas. • Never use charcoal or wood briquets in a gas grill. Flavoring chips must be contained in a metal smoking box to contain ash and prevent fires. •...
Page 5: Installation And Lp Cylinder Specifications And Safe Use
WARNING • FOR OUTDOOR USE ONLY. DO NOT operate indoors or in an enclosed area such as a garage, shed or breezeway. • Use your grill OUTDOORS in a well ventilated space away from dwellings or other buildings to prevent dangers associated with gas accumulation and toxic vapors. Although minimum clearance s 36 inches (91 cm), we strongly recommend that you do not operate this appliance within 10 ft.
Page 6 CYLINDER SPECIFICATIONS: When purchasing or exchanging a cylinder for your gas grill, it must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S. Department of Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339 Cylinders, Spheres and Tubes for Transportation of Dangerous Goods;...
Page 7: Connecting Lp Cylinder And Hose / Regulator To Grill
WARNING FILLING THE LP GAS CYLINDER: • Allow only qualified LP gas dealers to properly fill or repair your LP gas cylinder. • New tanks should be purged prior to filling; inform LP gas dealer if you are using a new tank. •...
Page 8 DO NOT attempt to connect it to any other fuel supply source such as a natural gas line. • DO NOT use any other pressure regulator/hose assembly other than the one supplied with your grill. Replacement pressure regulator/hose assembly must be part No 155-1415-0, which can be obtained by contacting customer service at 800-527-0717. •...
Page 9: Leak Testing
DANGER LEAK TESTING: To prevent fire or explosion hazard: • DO NOT smoke or permit ignition sources in the area while conducting a leak test. • Perform test OUTDOORS only in a well ventilated area. • Never perform a leak test with a match or open flame. •...
Page 10: Pre-Start Check List
Inspect the gas supply hose for burns, chaffing, kinks, and proper routing before each use. If it is evident there is excessive abrasion or wear, or the hose is cut, it must be replaced prior the grill being used. Replace with hose and regulator, Model No. 155-1415-0, which can be obtained by contacting customer service at 800-527-0717.
Page 11: Lighting Instructions
WARNING Read, understand and follow all warnings and instructions contained in this manual. DO NOT skip any of the warnings and instructions contained in the preceding sections of this manual. WARNING LIGHTING INSTRUCTIONS: Follow the instructions exactly. 1. OPEN THE GRILL LID before attempting to light a burner so that fumes do not accumulate inside the grill.
Page 12 Note: If burner does not light or flame is too low, you may have spider or other insect blockage in burner, or the flow limiting device has been activated. See "Burner Assembly/Maintenance" under Proper Care and Maintenance, or "Regulator Resetting Procedure" under Connecting LP Cylinder and Hose/Regulator to Grill.
Page 13: Operating Grill And Helpful Hints
WARNING OPERATING THE GRILL: Never use charcoal or wood briquets in a gas grill. Flavoring chips must be contained in a metal smoking box to contain ash and prevent fires. Read and follow all warnings and instructions contained in the preceding sections of this manual. BREAKING IN YOUR GRILL: •...
Page 14 ROTISSERIE COOKING: • Your grill was pre-drilled from factory to include mounting holes for a rotisserie (sold separately). Do not use a rotisserie not specifically manufactured for this grill. • Read and follow all instructions provided with the rotisserie. Save instructions for future reference. •...
Page 15: Proper Care And Maintenance
GRILL COOKING TIPS CLEANLINESS • Always wash hands thoroughly with soap and hot water prior to handling food and after handling raw meat, uncooked poultry or seafood. • When using a platter to carry raw meat, uncooked poultry or seafood to the grill, make sure to wash the platter thoroughly with soap and hot water before placing cooked foods back on the platter or use different platters for raw and cooked foods.
Page 16 CLEANING AND MAINTENANCE: • Keep the appliance free and clear of combustible materials, gasoline and other flammable vapors and liquids. • Keep the ventilation openings of the cylinder enclosure free and clear of debris. • Visually check burner flames for proper operation (see pictorial in "Burner Assembly/Maintenance" under Proper Care and Maintenance).
Page 17: Transporting And Storage
BURNER ASSEMBLY/MAINTENANCE CONTINUED Note: Follow the "Gas Leak Testing" section of this manual. Relight burners to verify proper operation. 12. Replace heat distribution plates and cooking grills. PROPER BURNER OPERATION COOKING GRILLS • Clean with mild soap detergent and water. A brass bristled brush or a nylon cleaning pad can be used to remove residue from the stainless steel surfaces.
Page 18: Trouble Shooting
BEFORE STORING YOUR GRILL: • Ensure that the cylinder valve is fully closed. • Clean all surfaces. • Lightly coat the burners with cooking oil to prevent excess rusting. • If storing the grill indoors, disconnect the LP tank and leave the LP tank OUTDOORS. •...
Page 19: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Your grill's serial number and model number, and the contact information for Brinkmann Customer Service, are listed on a silver label found beneath the control panel, on the back of the grill or on the side of the grill body, under the side shelf.
Page 20 FREQUENTLY ASKED QUESTIONS Cleaning Stainless Steel Cooking Grills: Wash grills with a mild detergent and rinse with hot water before initial use and as needed. DO NOT use a commercial oven cleaner. For stubborn food residue, use a degreaser and fiber or brass cleaning brush. Cleaning Porcelain-Finished Cast-Iron Cooking Grills: Wash grills with a mild detergent and rinse with hot water before initial use and as needed.
Page 21: Parts List And Assembly Instructions
PARTS BAG CONTENTS Make sure you have all items listed under PARTS LIST and PARTS BAG CONTENTS before you begin the installation process. Your Parts Bag will include: Qty. Qty. 16 M6 X 12 mm Bolts Plastic Rivets M6 Star Washers Screwdriver Hex Nut Wrench #8 Self-Tapping Screws...
Page 22 BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT. The following provided tools are required to assemble this ProSeries ™ 1415 Gas Grill: • Screwdriver • Hex Nut Wrench PARTS LIST: 1 Grill Body Assembly...
Page 23 FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT: www.brinkmann.net (Proof of purchase will be required.) Inspect contents of the box to ensure all parts are included and undamaged.
Page 24 Choose a good, cleared assembly area and get a friend to help you put your grill together. Lay cardboard down to protect grill finish and assembly area. CAUTION: Some parts may contain sharp edges. Wear protective gloves if necessary. Step 1 Attach cart base to side cart legs.
Page 25 Step 6 Install the wheels as illustrated, by inserting the wheel axle bolts Wheel through the wheels, washers and right side panel axle holes. Tighten Hub Cap axle bolts securely using hex nut Wheel Washer wrench provided in parts card. Wheel Axle Bolt Axle Note:...
Page 26 Grill Body Assembly Note: When performing Step 10, lift grill body from front and rear panels to avoid injury to hands and fingers. Step 10 With the help of a friend, place grill body assembly on grill cart. Align bolt holes located on the cart frame, secure using four M6 X 12 mm bolts with star washers.
Page 27 Step 11 Insert the two bolts with pre- attached nuts on the left side table into the keyholes in side table front panel. Tighten the nuts with a wrench. Step 12 Insert the two bolts with pre- attached nuts on the right side burner assembly into the keyholes in side burner assembly table front panel.
Page 28 Step 13 Attach side table to left side of cart frame assembly. Place table over pre-attached bolts and slide toward back of grill, then tighten securely. Fasten side table front panel to grill body with one M6 X 12 mm bolt. Step 14 Attach side burner assembly to right side of cart frame assembly.
Page 29 Step 16 Burner Venturi Firmly seat the valve nozzle into the burner venturi. Hold in place while you perform Step 17. Side Burner Valve Valve Nozzle Step 17 Insert the two screws that are Figure 1 Figure 2 already attached on the side burner valve through the corresponding key holes on the side burner front panel and bezel, from the back of...
Page 30 Step 19 Attach side burner igniter lead wire to the electrode as illustrated. Side Burner Igniter Lead Electrode Step 20 Hang grease cup from brackets on bottom of grill body assembly. Grease Cup...
Page 31 Warming Rack Step 21 Cooking Grills Place the heat distribution plates on lower level of grill body assembly directly above burners. Heat Distribution Plates Step 22 Place cooking grills on support ribs directly above heat distribution plates. Step 23 Place warming rack in grooves so Grooves that it sits above the cooking grills.
Page 32 ProSeries ™ 1415 (Assembled)
