READ AND SAVE THESE INSTRUCTIONS
MONTEREY LUMINA
52" Ceiling Fan Owner's Manual
CF776BS00 -
CF776ORB00 -
CF776SW00 -
Questions, problems, missing parts: Before returning to the store call
Part No. F40BP74680000
Revision: 130228
Model Numbers
Brushed Steel
Oil Rubbed Bronze
Satin White
28.9
Net Weight:
Emerson Electric Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-800-654-3545
www.emersonfans.com
™
Lbs.
Form No. BP7468
E.T.L. Model No.: CF776

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CF776BS00 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Emerson CF776BS00

Summary of Contents for Emerson CF776BS00

  • Page 1 Oil Rubbed Bronze CF776SW00 - Satin White 28.9 Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-800-654-3545 Part No. F40BP74680000 Form No. BP7468 www.emersonfans.com Revision: 130228...

  • Page 2: Safety Instructions

    Emerson Electric Co. Substitution of parts or accessories not Additional Safety Instructions for Installation designated for use with this product by Emerson could result in personal injury or property damage. 1. To avoid possible shock, be sure electricity is turned...

  • Page 3: Unpacking Instructions

    Emerson Electric Co. Substitution of parts or Switch Housing Cover Plate accessories not designated for use with this product Switch Housing Assembly by Emerson Electric Co. could result in personal injury or property damage. Glass Bowl 60-Watt (max.) Candelabra Bulbs 1.

  • Page 4: Tools Needed For Assembly

    This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Installed Wire Length Wire Size A.W.G. Tools Needed for Assembly Up to 50 ft. One Phillips head screwdriver One stepladder 50-100 ft.
  • Page 5 4. Make sure the grommet is properly installed in the coupler cover, then slide the coupler cover on the CEILING COVER downrod until it rests on the motor housing. Place the ceiling cover over the downrod. Be sure that the ceiling cover and the coupler cover are both oriented correctly (Figure 3).
  • Page 6 13. Remove one of the screws from the switch adapter. REMOVE SWITCH SWITCH HOUSING Retain for future installation. Loosen the two ADAPTER SCREW COVER PLATE remaining screws in the switch adapter for installation of the switch housing cover plate (Figure 7). 14.
  • Page 7 20. Install three 60-watt (maximum) candelabra base light bulbs (included) into the light fitter sockets FINIAL NUT (Figure 10). OUTER BOWL CAP WARNING 60-WATT Over lamping the fan will result in the light bulbs being CANDELABRA automatically shut off. Use only 60-watt maximum BASE LIGHT candelabra light bulbs.

  • Page 8: Electrical Requirements

    8 - 9 feet above the floor for optimal occupied space. Remember to adjust your thermostat airflow. Consult your Emerson Retailer for optional when using your ceiling fan - additional energy and mounting accessories.
  • Page 9 How to Hang Your Ceiling Fan CEILING WARNING The fan must be hung with at least 7' of clearance from floor to blades (Figure 12). WARNING AT LEAST The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. Use only a U.L. outlet box listed as “Acceptable for Fan Support of 15.9kg.
  • Page 10 Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury LOCKWASHERS (2) or property damage. THREADED STUD (2) 2.

  • Page 11: Maintenance

    Emerson Electric Co. Substitution of parts or WARNING accessories not designated for use with this product by Emerson Electric Co. could result in personal injury The use of any other control not specifically approved or property damage. for this fan could result in fire, shock and personal injury.

  • Page 12: Repair Parts

    Repair Parts E.T.L. Model No.: CF776...

  • Page 13: How To Order Repair Parts

    Repair Parts Listing Model Numbers Description CF776BS00 CF776ORB00 CF776SW00 Hanger Ball Assembly, 761655-17 761655-32 761655-92 Consisting of: Hanger Bracket — — — Hanger Ball — — — Downrod, 4.5” — — — Parts Bag Containing: 764388-CHRM 764388-BLOX 764388-CHRM Wire Connector (3) —...

  • Page 14: Troubleshooting

    Trouble Shooting WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not start. 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers. 2.
  • Page 15 What We Will Do To Correct Problems: If during the one (1) year warranty period the motor or any component or accessory of your Emerson Ceiling Fan is defective in materials or workmanship, or if during the expected lifetime of the Emerson Ceiling Fan (when used in accordance with the User Manual or other instructions) the motor is defective in materials or workmanship, you must contact Emerson during the applicable warranty period.
  • Page 16 Air Comfort Products DIVISION OF EMERSON ELECTRIC CO. 8100 W. Florissant • St. Louis, MO 63136 Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-800-654-3545 www.emersonfans.com Retain this manual for future use.
