VENTED DECORATIVE NATURAL GAS LOGS
OWNER'S OPERATION AND INSTALLATION MANUAL
COMFORT GLOW LOG SET AND BURNER MODELS
CVSR18, CVSR24, CPVSR18, CPVSR24, CVDR18
CVDR24, CVDR30, BFLT18 AND BFLT24
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may result
causing property damage, personal injury or death.
— Do not store or use gasoline or any other flammable
vapors or liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS :
• Do not try to light any appliance.
• Do not touch any electrical switch;
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
FOR YOUR SAFETY
For more information, visit www.desatech.com
ANSI Z21.84
O-TL REPORT
# 114-L-31-4
Advertisement
Table of Contents
Related Manuals for Desa BFLT18
Summary of Contents for Desa BFLT18
- Page 1 OWNER’S OPERATION AND INSTALLATION MANUAL ANSI Z21.84 O-TL REPORT # 114-L-31-4 COMFORT GLOW LOG SET AND BURNER MODELS CVSR18, CVSR24, CPVSR18, CPVSR24, CVDR18 CVDR24, CVDR30, BFLT18 AND BFLT24 WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. FOR YOUR SAFETY — Do not store or use gasoline or any other flammable vapors or liquids in the vicinity of this or any other appliance.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ..............2 Troubleshooting ..........16 Local Codes............4 Service Hints ............. 19 Unpacking............4 Technical Service..........19 Product Identification ........... 5 Replacement Parts ..........19 Optional Product Features........5 Parts ..............20 Installation ............5 Accessories ............26 Operation ............ - Page 3 SAFETy Continued Natural gas is odorless. An odor- Natural Gas: Appliance assembly becomes making agent is added to the gas. The odor very hot when in use. Keep chil- helps you detect a gas leak. However, the odor added to the gas can fade. Gas may be dren and adults away from hot present even though no odor exists.
-
Page 4: Local Codes
National Fire Protection Association, Inc. to logs and base for shipment. Batterymarch Park Quincy, MA 02269 3. Check heater for any shipping damage. If heater is damaged call DESA Heating, LLC at 1-866-672-6040 for replacement parts before returning to dealer. www.desatech.com 901265-01S... -
Page 5: Product Identification
PRODUCT IDENTIFICATION Grate Steps (not required for models CVSR18/24) Grate Hearth Kit Model ___________________ Serial Number _____________________ Log Set Model _____________________ Burner Burner Clamp Burner Inlet Burner Manifold Fitting Figure 1 - Product Identification (Dual Burner Shown) OPTIONAL PRODUCT FEATURES ON/OFF SAFETY VALVE/PILOT KIT or other sources to light. - Page 6 Front Width* Back Width** Depth Height 18" CVDR18 55,000 45,000 8" dia. Dual 36" 27" 18" 18" CVDR18 24" Model: BFLT18 65,000 55,000 8" dia. CVDR24 Dual Front Width* Back Width** Depth Height 30" 28" 16" " 18" CVDR24 70,000 60,000 8"...
- Page 7 INSTALLATION Continued CHECK GAS TYPE CONNECTING TO GAS SUPPLY Use only natural gas. If your gas supply is not WARNING: A qualified ser- natural gas, you must install ON/OFF Safety vice person must connect log Valve/Pilot Kit (see Accessories, page 26). Call dealer where you bought log set.
- Page 8 INSTALLATION Continued We recommend that you install a sediment PRESSURE TESTING GAS SUPPLY trap in supply line as shown in Figure 4. PIPING SYSTEM Locate sediment trap where it is within reach Test Pressures In Excess Of 1/2 PSIG for cleaning. Install in piping system between (3.5 kPa) fuel supply and heater.
- Page 9 Only 1. Determine which side gas line will be Burner Inlet coming into fireplace. Fitting NOTICE: Triple-burner mod- els BFLT18 and BFLT24 come preassembled with gas inlet Knockout on right side of burner pan. Plugs DO NOT attempt to reposition...
- Page 10 INSTALLATION Continued Installation and Gas Connection 2. Attach pilot gas line to pilot outlet of gas 1. Place burner pan assembly in center of control valve and tighten. Connect ther- fireplace floor. Make sure front of pan mocouple to rear of gas control valve. faces forward.
- Page 11 INSTALLATION Continued 6. Install gas connector tube to gas supply PROPANE/LP GAS CONVERSION fitting. Carefully shape tube to attach to To convert to propane/LP gas, burner inlet adapter fitting. Be careful not to cause fitting and pilot orifice must be replaced. kinks in tube.
- Page 12 INSTALLATION Continued Changing Pilot Orifice Note: Burner design includes more ports The pilot is provided with a natural gas ori- on the outside of the bar. Make sure that fice installed. For propane/LP gas you must all ports are clear and producing flame remove it and replace it with an propane/LP evenly across burner.
- Page 13 INSTALLATION Continued 5. Place smaller top logs onto bottom logs (see Figure 17). Leave as much open space between logs as possible to mini- mize flame impingement and sooting. Note: Logs may chip if they are handled roughly or if hit together while being placed.
-
Page 14: Operation
OPERATION FOR YOUR SAFETY GAS SHUTOFF READ BEFORE LIGHTING VALVE OPERATION Flame Adjustment WARNING: Keep flue open Adjust the flame ON/OFF by turning gas shut- when operating unit. off valve counterclockwise to open or clockwise to close, as necessary. WARNING: If you do not fol- Shutting Off Appliance low these instructions exactly, Turn gas shutoff valve clockwise... -
Page 15: Cleaning And Maintenance
OPERATION Continued Note: You may be running this log set Control Knob Pilot for the first time after hooking up to gas Ignitor supply. If so, the control knob may need to be pressed in for 30 seconds. This will FROM "PILOT"... -
Page 16: Troubleshooting
TROUBLEShOOTING WARNING: Turn off log set and let cool before servicing. Only a qualified service person should service and repair log set. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Log set is smoking/sooting 1. Poor fuel quality 1. Contact local natural or excessively propane/LP gas company (Note: It is natural and unavoid- 2. - Page 17 TROUBLEShOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When ignitor button is pressed, 1. Gas supply turned off or 1. Turn on gas supply or open there is spark at pilot but no equipment shutoff valve equipment shutoff valve ignition (GA9050A-1 Only) closed 2.
- Page 18 TROUBLEShOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions. • If you cannot reach your gas supplier, call the fire department. IMPORTANT: Operating log set where impurities in air exist may create odors. Cleaning sup- plies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles, etc., create fumes.
-
Page 19: Service Hints
• heater will not produce specified heat serial numbers of your heater ready. • propane/LP gas supply may be low You can also visit DESA Heating, LLC’s web You may feel your gas pressure is too low. If site at www.desatech.com. -
Page 20: Parts
PARTS MODELS CvSR18, CvSR24, CPvSR18 AND CPvSR24 Oxford Round Oak Logs CPVSR Models Only Amherst Round Oak Logs www.desatech.com 901265-01S... - Page 21 PARTS This list contains replaceable parts used in your log set. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. NO. PART NO. DESCRIPTION QTY. 901056-01 Brass 3/8 FLR x 1/2 FPT Adapter •...
- Page 22 PARTS MODELS CvDR18, CvDR24 AND CvDR30 Berkshire Oak Log Set Coventry Oa www.desatech.com 901265-01S...
- Page 23 PARTS This list contains replaceable parts used in your log set. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. NO. PART NO. DESCRIPTION 901056-01 Brass 3/8 FLR x 1/2 FPT Adapter • • • 901059-01 Brass 3/8 FLR x 3/8 FPT Adapter •...
- Page 24 PARTS MODELS BFLT18 AND BFLT24 Mendocino Oak Log Set www.desatech.com 901265-01S...
- Page 25 PARTS This list contains replaceable parts used in your log set. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. PART NO. DESCRIPTION QTY. 901056-01 3/8 FLR x 1/2 FPT Adapter • • 901059-01 3/8 FLR x 3/8 FPT Adapter •...
-
Page 26: Accessories
Purchase these accessories from your local dealer. If they can not supply these accessories For decorative purposes only. Not to be used call DESA Heating, LLC at 1-866-672-6040 for as additional logs on unit. information. You can also write to the address INDIVIDUAL SPLIT LOG - GA9550A listed on the back page of this manual. - Page 27 NOTES _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 901265-01S www.desatech.com...
-
Page 28: Warranty
This is DESA Heating, LLC’s exclusive warranty, and to the full extent allowed by law; this express warranty excludes any and all other warranties, express or implied, written or verbal and limits the duration of any and all implied warranties, including warranties of merchantability and fitness for a particular purpose to one (1) year on new products and 30 days on factory reconditioned products from the date of first purchase.
