Site Survey Tool SST2 for DECT
USER GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the SST2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mitel SST2

  • Page 1 Site Survey Tool SST2 for DECT USER GUIDE...
  • Page 2 The information is subject to change without notice and should not be construed in any way as a commitment by Mitel or any of its affiliates or subsidiaries. Mitel and its affiliates and subsidiaries assume no responsibility for any errors or omissions in this document.
  • Page 3 User Guide Site Survey Tool for DECT 1 INTRODUCTION 1.1 ABOUT THE SITE SURVEY TOOL The Site Survey Tool is used by technicians to plan base station locations for a DECT telephone system with TDM-DECT or IPBS base stations. With the Site Survey Tool you can determine the required number and positions of base stations.
  • Page 4 1.3 COMPONENTS OF THE SITE SURVEY TOOL WITHOUT BATTERY UNITS AND CHARGERS SST2 is aimed for site survey measurements for IP DECT with MiVoice MX-ONE, MiVoice Business, MiVoce 250, and for Integrated DECT with MiVoice MX-ONE. The Site Survey Tool consists of: •...

  • Page 5: Specifications

    User Guide Site Survey Tool for DECT 1.7 SPECIFICATIONS Operating temperature 0 - 40 Storage temperature -20 - +70 Relative humidity 10 to 80%, non-condensing 1.8 USE OF HANDSETS This user´s guide assumes that you are familiar with the use of handsets. If necessary, see the handset user´s guide.

  • Page 6: Preparations For Use

    User Guide Site Survey Tool for DECT 2 PREPARATIONS FOR USE 2.1 CHARGING THE BATTERY (ONLY FOR VERSION WITH BATTERY UNITS AND CHARGERS) Charge the battery units with the supplied chargers for approximately 12 hours. A fully charged battery offers about 8 hours of operation. When the battery voltage becomes too low, the site survey base station stops operating, The battery unit and the site survey base station are connected with the included battery patch cable.
  • Page 7 Set error rate (f/s) Show RFPs Select Back Figure 2. Site survey tool menu items in Mitel 5614, DT69x/DT4x3 and 5604/ 5607 3.2 ACTIVATE INFORMATION DISPLAY Mitel 5614, DT69x/DT4x3 and 5604/5607 DECT Telephones The first item in the Site survey tool menu is Link that shows information described below.
  • Page 8 PARI: 9004043D02 C-Plane: - Pwr: - Encryp: - Cap: On Back Figure 3. Information display in Mitel 5614, DT69x/DT4x3 and 5604/5607 First row Shows the current carrier (C), slot (S) and signal strength (SS). Second row Shows the amounts of bad frames per second which are received by the handset.
  • Page 9 Select "On" to activate the error rate beep. 3.6 BASE STATION LISTING The sub menu shows RFPs for Mitel 5614, DT69x/DT4x3 and 5604/5607 (see figure 4 on page 10) give possibilities to scan the air for base stations and sort them in order of signal strength - strongest first.
  • Page 10 Residential RFPs Select Back Figure 4. Base station listing menu in Mitel 5614, DT69x/DT4x3 and 5604/5607 Mitel 5614, DT69x/DT4x3 and 5604/5607 ; press the soft key "Select" for making a list over all RFPs. Scroll the list with the Navigation key. From the left; a counter, signal...
  • Page 11 User Guide Site Survey Tool for DECT 4 SITE SURVEY WITH IPBS BASE STATION NOTE: If the Enhanced DECT Security feature is to be used in the system (to gain early encryption and re-keying) then the Enhanced DECT Security feature must be activated before performing the site survey.
  • Page 12 User Guide Site Survey Tool for DECT In the PARI Master IP Address text field, enter loopback address 127.0.0.1. If the base station shall be used without a network and a DHCP server, a static IP address must be set. Do as follows: Select LAN >...
  • Page 13 User Guide Site Survey Tool for DECT IPBS2 Figure 7. LED on IPBS4x2/IPBS2 Deployment: 2000 ms blue, 400 ms yellow. The IPBS4x2/IPBS2 is in deploy Good sync mode and has good air sync coverage. Deployment: 400 ms blue, 600 ms off, 400 ms blue, The IPBS4x2/IPBS2 is in deploy Bad sync 600 ms off, 400 ms yellow.

  • Page 14: Broadcast And Multicast Messaging

    User Guide Site Survey Tool for DECT 5 BROADCAST AND MULTICAST MESSAGING Special requirements need to be considered when planning a system for broadcast and multicast messaging. Broadcast and multicast messages are without any handshake procedure between the base stations and the handsets instead a number of retransmissions are being made to increase the probability of a complete transmission.
