Summary of Contents for Galaxy Audio ANY SPOT AS-DCTVMBP
- Page 1 ANY SPOT ® AS-DCTVMBP TWIN BODYPACK CHARGING STAND User's Guide Body-pack Transmitter Body-pack Receiver Bodypack charging stand...
- Page 2 INTRODUCTION Thank you for purchasing our twin bodypack charging stand for TRAVELER wireless microphone bodypacks. Please read this manual carefully before using.
-
Page 3: Description Of Functions
DESCRIPTION OF FUNCTIONS 1. Fully Charged Indicator (Indicates OK with green LED) 2. Charging Indicator (Indicates ON with amber LED) 3. DC Power connector 4. Charging stand for TRAVELER, wireless microphone bodypacks. AS-DCTVMBP... -
Page 4: Setup And Operation
SETUP AND OPERATION 1. Plug the AC adapter into an AC outlet of the voltage specified on the adapter. Plug the DC cable into the DC in Jack on the charger stand. The charger will perform a self-test with the following indications: Both OK (GREEN)indicators blink, then both ON (AMBER) indicators blink. - Page 5 ATTENTION: Avoid Excessive Heat Don't leave the charging stand in the hot sun, on a radiator, or near other sources of high temperature. Avoid Rough Handling Charging stand may be damaged if dropped. USE only Ni-CD or Ni-MH Rechargeable Batteries.
-
Page 6: Troubleshooting
TROUBLESHOOTING Problem Solution Charging Indicator (ON Make sure the batteries are AMBER) Keeps Flashing the rechargeable type. Make sure bodypack is installed properly. Some belt clips may need to be changed or removed to allow full insertion of the bodypack into the charger. - Page 7 SPECIFICATIONS Number of charging 2 (receiver or transmitter) or compartments multi-series Power requirement 115V or 230V AC adaptor 12V DC, 500mA OK (GREEN) LED lit. Bodypack fully charged ON (AMBER) LED lit Charging in progress Charging current 450 ~ 500 mA Charging time Ni-MH.
- Page 8 ANY SPOT ® AS-DCTVMBP TWIN BODYPACK CHARGING STAND User's Guide Product Page www.galaxyaudio.com/support/warranty https://www.galaxyaudio.com/support/warranty 2021Copyright Galaxy Audio Inc. V20210914...
