Customer Service
If you experience difficulty with your system, call Toll-Free
for Customer Assistance:
1-800-843-3544 (U.S.A.) or
+1 952 943 2252 (Outside the U.S.A.)
If it is necessary to return the system for service, your
Customer Service Representative will give you a Return
Authorization Number (RA) and shipping instructions.
This is a quick setup guide. For a
detailed user manual, please visit
our website.
info@williamsav.com / www.williamsav.com
800-843-3544 / INTL: +1-952-943-2252
©2021 Williams AV, LLC MAN 170I
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Williams AV PPA T46
Summary of Contents for Williams AV PPA T46
- Page 1 Customer Service Representative will give you a Return Authorization Number (RA) and shipping instructions. This is a quick setup guide. For a detailed user manual, please visit our website. info@williamsav.com / www.williamsav.com 800-843-3544 / INTL: +1-952-943-2252 ©2021 Williams AV, LLC MAN 170I...
-
Page 2: System Specifications
System Specifications FM Transmitter, Model PPA T46 Battery Type: Two (2) AA 1.5 V non-rechargeable Alkaline batteries (BAT 001-2), 75 mA nominal current drain, up to 30 hours battery life, or Two (2) AA 1.5 V rechargeable NiMH batteries (BAT 026-2), 75 mA nominal current drain, up to 20 hours battery life per charge, recharges in 14–16 hours, uses CHG 3502 or CHG 3512... - Page 3 System Specifications (Continued) FM Transmitter, Model PPA T46 Audio Compression: 1:1 (off) or 2:1 (on) ratio, selectable in menu Compatible Microphones: MIC 044, MIC 090, MIC 100 Compatible Receivers: PPA R37, PPA R37-8, PPA R38 Approvals/Directives: FCC, Industry Canada, RoHS, WEEE...
-
Page 4: Safety Information
Safety Information HEARING SAFETY CAUTION! This product is designed to amplify sounds to a high volume. To protect your hearing and the hearing of others: 1. Make sure the unit is OFF or the volume is turned down before putting on the earphones. 2. -
Page 5: Recycling Instructions
Take batteries to a retail or community recycling location. Battery Information The PPA T46 uses 2 AA batteries. We recommend using Williams AV Alkaline batteries (BAT 001-2) or rechargeable batteries (BAT 026-2) for longer battery life than other brand batteries. - Page 6 PPA T46 Personal PA ® FM 72-76 MHz Body Pack Transmitter QUICK SETUP GUIDE MAN 170I...
- Page 7 Operating Instructions 1. Open the battery compartment. Slide the battery selection switch to the correct position for the type of batteries that will be used. Use “Alkaline” for non-rechargeable batteries, “NiMH” for rechargeable NiMH batteries (only). (FIG. A) IMPORTANT: If the battery switch is not in the correct position, damage may be caused to the unit.
-
Page 8: Auxiliary Input Jack
3. Plug in the microphone cord (sold separately) using the “Mic Jack” on top of the transmitter (FIG. B). Do not curl or wrap the microphone cable. The microphone cable is also the transmitting antenna. 4. Optionally, plug in a desired audio source such as a CD or MP3 player using the “Auxiliary Input”... - Page 9 6. Select the desired operating frequency. Refer to the following channel selection chart. Make sure the transmitter and receiver channels match. Up to eight T46’s can operate simultaneously on different channels. These channels must be used to avoid interference (see “Note on Interference” on page 4.) See 8-Ch.
- Page 10 7. Change the transmitter to the desired operating frequency. Use the Menu to select any of the 17 available channels on 72-76 MHz. To access the channel setting, push the menu button until you see the channel displayed. Change the channel by pushing the left or right arrow buttons. T46 FRONT To access additional settings, push the menu button repeatedly until you see the setting you want.
- Page 11 8. To install the belt clip on the rear of the T46, position the belt clip on the back of transmitter. Turn the belt clip 180˚ left or right to secure the clip. The transmitter can now be clipped onto a belt. To remove, turn the belt clip 180˚ so the open end of the clip points up, and gently pull the belt clip off.
- Page 12 Limited Lifetime PLUS Limited Warranty Williams AV products are engineered, designed, and manufactured under carefully controlled conditions to provide many years of reliable service. Williams AV warrants the T46 against defects in materials and workmanship. Microphones, earphones, headphones, batteries, chargers, cables, carry cases, and all other accessory products carry a 90-day warranty.
