  • Page 2: Table Of Contents

    Crestron CPC-CAMI Contents Pan/Tilt Camera Head with Control Interface: CPC-CAMI Description... 1 Functional Description ... 1 Physical Description... 2 Leading Specifications... 7 Setup ... 8 Camera/Lens Mounting ... 8 Identity Code ... 10 Preparation for Use... 11 Initialization... 11 Limit Stop Adjustment ... 12 Calibration ...

  • Page 3: Pan/Tilt Camera Head With Control Interface: Cpc-Cami

    CPC-CAMI with its four jumpers can control nearly any camera/lens in the industry. Refer to the table below for exact voltage outputs for each jumper board. NOTE: If no jumper board is connected to the CPC-CAMI, the lens outputs are disconnected.

  • Page 4: Physical Description

    Physical Description The CPC-CAMI, shown below, is housed in a black enclosure with two rotating disks for the pan and tilt axes. A stop sensor is located on each side of the unit having a rotating disk. Each disk has two adjustable locking screws. The disks also feature heavy duty precision bearings for long life and minimal friction.
  • Page 5 Adjustable mounting plates (flat and angled) and mounting hardware are provided with each CPC-CAMI. The two plates can be fixed to one of the rotating disks with the mounting hardware to provide camera/lens support. The other disk serves as a mounting platform for the CPC-CAMI with attached camera/lens assembly.
  • Page 6 Pan/Tilt Camera Head with Control Interface CPC-CAMI Pinout for LENS Port Wiring Diagram for Lens A, B, and D (+/-12V, +/-8V, and +/-6V) 4 • Pan/Tilt Camera Head with Control Interface: CPC-CAMI DESCRIPTION Focus Out Focus Common Zoom Out Zoom Common...
  • Page 7 ZOOM_FEEDBACK FOCUS_FEEDBACK ANALOG_GROUND DESCRIPTION Rx (to CPC-CAMI) Input Tx (from CPC-CAMI) Output RTS (from CPC-CAMI) Output CTS (to CPC-CAMI) Input Pan/Tilt Camera Head with Control Interface: CPC-CAMI • 5 HIROSE LENSE CONNECTOR FOCUS_MOTOR FOCUS CONTROL POWER_GND GROUND ZOOM_MOTOR ZOOM CONTROL...
  • Page 8 Pan/Tilt Camera Head with Control Interface CPC-CAMI Indicators A number of indicators are located on the CPC-CAMI interface box. Each has a silk- screened label. Refer to the illustration shown in “CPC-CAMI Ports” on page 3 and the descriptions after this paragraph.

  • Page 9: Leading Specifications

    Crestron CPC-CAMI Leading Specifications The table below provides a summary of leading specifications for the CPC-CAMI. Dimensions and weights are rounded to the nearest hundredth unit. Leading Specifications of the CPC-CAMI Power Requirements Default Network ID SIMPL™ Windows® CNMSX-AV/PRO Upgrade File (.upz) CNRACKX/-DP Upgrade File (.upz)

  • Page 10: Specification

    However, realize that the height of the two sides to which the disks are attached are not equal. Therefore, mounting the camera/lens assembly to the longer side allows for a greater range of motion (assuming that the CPC-CAMI is directly mounted to a large horizontal surface).
  • Page 11 ROUND OBJECT 5. Use two 1/4-20 x 3/8” pan Phillips head screws (supplied) to loosely secure the angled mounting plate to the CPC-CAMI. Verify that the two pins on the plate align with the slot on the rotating disk. 6. Adjust the vertical position of the angled mounting plate (refer to the illustration below).

  • Page 12: Identity Code

    03 to FE. The NET ID of each unit must match an ID CODE specified in the SIMPL Windows program. The NET ID of each CPC-CAMI has been factory set to 34, but may be changed from the PC via VisionTools™ Pro-e (VT Pro-e) or SIMPL™...

  • Page 13: Preparation For Use

    Libraries) of the Crestron website (www.crestron.com). Search for the MODULAR.PDF or CRESNET.PDF files, respectively. NOTE: To insure safe operation of the CPC-CAMI, all cables around the unit must be properly “dressed” so that the cables do not strike surrounding surfaces or equipment which would endanger safe system movement when in operation.

  • Page 14: Limit Stop Adjustment

    Pan/Tilt Camera Head with Control Interface Limit Stop Adjustment Two locking screws are found on each rotating disk on the CPC-CAMI. Complete the following steps to properly set the limit stops. Calibration Over time it may be necessary to recalibrate the CPC-CAMI to ensure proper operation.

  • Page 15: Maintenance

    Two sample SIMPL Windows programs are presented in this document for the two separate lens control configurations. The first subsystem supports lenses that use CPC-CAMI jumper boards A, B, or D. The second subsystem is specific for lenses using CPC-CAMI jumper board C and have the separate rate/position drive.
  • Page 16 (www.crestron.com). Search for CPC-CAMI.SMW. Jumper Board A, B, or D For most "standard" lenses using CPC-CAMI jumper board A, B or D, programming is essentially the same. A sample SIMPL program is shown in block diagram form below. SIMPL Windows contains a couple of macros within the Crestron Modules folder, which can easily control pan/tilt, zoom/focus as well as store and recall presets (if available on the lens).
  • Page 17 MD, BMD series), do not have true feedback pots. Instead they have separate rate and position control modes. If presets are not required, the CNCAMI RATE CONTROL module can be used for direct drive of the rate lines on the CPC-CAMI definition.
  • Page 18 CPC-CAMI. Four position drive signals, TILT_SET, PAN_SET, FOC_SET, and ZOOM_SET, are used to instruct the CPC-CAMI to drive the camera to a preset position. Anytime the analog level on one of these drive signals change, the CPC-CAMI adjusts the corresponding pan/tilt axis and focus/zoom lensposition until the feedback matches the level at the programmed output.

  • Page 19: Problem Solving

    Presets can not be recalled. Further Inquiries If after reviewing this Operations Guide for the CPC-CAMI, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling: For local support from exclusive Crestron factory-trained personnel in New Zealand call Amber Technologies at +649-410-8382.

  • Page 20: Return And Warranty Policies

    CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures.

  • Page 21: Appendix: Application Examples

    The application examples in this appendix suggest the lens cabling connection for the lens type jumper (A through D) to be used for a given camera lens. The camera lens pins are listed in the left-most column. The CPC-CAMI LENS connector pins are listed in the right-most column.

  • Page 22: Lens Cabling Connection For Jumper B (+/-8V)

    CONNECTOR 8000-9801-00 Lens Cabling Connection for Jumper C (+2.5V to +7.5V) Fujinon MD/BMD/SD Series and Canon KTS/KTS-A Series CONNECTOR J2/CN2 20 • Pan/Tilt Camera Head with Control Interface: CPC-CAMI red,blk Lens Common green Focus Motor Drive purple Feedback Supply blue...
