- Page 1 FUSION-Link...
- Page 2 Accessing FUSION - Link Page 5.2. FUSION - Link – Full Screen 5.3. FUSION - Link – Media Bar 5.4. Quick Access to FUSION - Link by Two Finger Tap 5.5. FUSION - Link Page for Different Resolutions 5.6. Automatic Volume Adjustment by Speed...
- Page 3 NavNet TZtouch2 and TZtouch3 Only 2.1. Compatible Fusion Stereos Fusion stereos with NMEA2000 interface can be connected to the NavNet TZtouch2/3 network for control via NMEA2000. When connected by NMEA 2000; they should not be connected to Ethernet. ONLY one method used not both.
- Page 4 Diagram from Fusion Entertainment 2.3. Limitation for NMEA2000 Network When Fusion stereos are networked via NMEA2000, album artwork will not be shown on the FUSION-Link page or the media bar. The artwork will be shown with Ethernet connected systems only.
- Page 5 3.2. Interconnection with Fusion Stereos Fusion stereos can be networked with the MFDs as follows. The stereos should be assigned with an IP address by manual setting as shown in Section 3.3. Notes: (1) FUSION-Link supports both NMEA2000 and Ethernet protocols, but NavNet TZtouch and TZtouch2 MFDs use the Ethernet network to interface with Fusion stereos for FUSION-Link.
- Page 6 Procedures (Screenshots from MS-RA770) In [Settings] – [NETWORK] – [ADVANCED] – [ETHERNET IP], check [STATIC IP] and set the IP address to [172.31.xxx.xxx] in [IP] and subnet mask to [255.255.0.0] in [MASK]. E.g. STATIC IP page IP: 172.31.6.16 MASK: 255.255.0.0 4.
- Page 7 5. Operating Fusion Stereos This section describes how to access and operate the Fusion stereos from the MFD. 5.1. Accessing FUSION-Link Page If the stereo is available in the MFD network, the Fusion the FUSION - Link page. TZT9/14/BB TZTL12F/15F /2BB and TZT9F/12F/16F/19F 5.2.
- Page 8 If you tap the Menu or Tone icon, setting items will appear on the right side of the page. Menu/Tone Page In this example, Menu is open. Close Icon The FUSION-Link full page can be closed by tapping this icon.
- Page 9 E.g. TZT9/14/BB (Left) and TZTL12F/15F/2BB (Right) 5.3. FUSION-Link – Media Bar A media bar is available at the bottom of each navigation page to show the audio status and partially operate the audio. TZT9/14/BB – Media Bar...
- Page 10 TZTL12F/15F – Media Bar Item Descriptions TZT9/14/BB The media bar will appear by selecting [Fusion Ctrl] from the context or RotoKey™ menu. TZTL12F/15F/2BB and TZT9F/12F/16F/19F Fusion Option The media bar will appear by selecting [Fusion] from the universal setting option accessible by edge swipe at the right side of the screen.
- Page 11 5.4. Quick Access to FUSION-Link by Two Finger Tap When the stereo is available in the network, functions associated with FUSION-Link can be allocated in [Menu] / [Setting] – [General] – [Function Gesture] (TZT9/14/BB) or [Two Finger Tap] (TZTL12F/15F/2BB and TZT9F/12F/16F/19F).
- Page 12 There is no significant difference in the full page. When the media bar is shown at the bottom of the screen, the active area of the navigation page reduces, compared to the TZT14/BB. Note: There is no significant difference between the TZTL12F/TZT12F and TZTL15F/TZT16F because they have similar screen resolutions.
- Page 13 Note that this feature is available on the TZT9/14/BB v4.01 or later and all versions from TZTL12F/15F/2BB and TZT9F/12F/16F/19F. Settings [Menu] / [Settings] – [Initial Setup] – [Fusion] [Fusion Auto Volume] – [ON] [Minimum Speed] –...
