Directions for
using Pingpong

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PingPong and is the answer not in the manual?

Questions and answers

Related Manuals for ROBORISEN PingPong

Summary of Contents for ROBORISEN PingPong

  • Page 1 Directions for using Pingpong...

  • Page 2: Safety Information

    Safety information 1. Pingpong is designed for over 6, educational use, and makers. Keep the unit away from small children. Do not use units unintended ways. 2. Pingpong can cause failure or trouble by the wrong power supply, malfunction from hardware or software of computers, users' carelessness, unsuitable installations or environments, or other various causes.

  • Page 3: Specifications

    Specifications Power DC 5V, 1A Battery Lithium-ion battery, 3.7V, 300mAh Connectivity Bluetooth LE 5.0 IoT Multiprotocol Sensors and others Infrared Proximity sensor 6DOF IMU, Accelerometer and Gyroscope Infrared Origin Detector LED: for power, Green for Bluetooth, and LED indicator Electromagnetic Buzzer Motor Stepper 100:1, 180DPS/1000SPS Digital I/O port 4-pin External input port: Servo, IR Remote connector CPU ARM Cortex M4 (32-bit, compatible with BLE 5.0)
  • Page 4 Getting to know pingpong LED indicator proximity sensor...
  • Page 5 Getting to know pingpong magnetic external input (4pin) charger stepper...

  • Page 6: Control Button

    Control button  To turn on, press the yellow button shortly.  To turn off, press the button longer.  To connect pingpong to other devices, press the button one more time.

  • Page 7: Led Indicator

    LED indicator 1. If your pingpong did not connected to others, the LED indicator slowly changes its colors. 2. If your pingpongs are paired, the master’s indicator shows red, and slaves shows green, blue, sky-blue, pink, yellow, purple in order.
  • Page 8 LED indicator...

  • Page 9: Power Management

     When the unit won’t be used for a long time, press the button long to turn off. Full battery charge is needed before using.  Recharge your pingpong with rated output adaptor (3A), do not recharge it through USB port in laptop or desktop computers.
  • Page 10  motor stops. Then you need to power off the pingpong, and cool down it more than 10 minutes. The overheat warning occurs if the pingpong raises other units and maintains it, or it worked hard for a...
