ANV TC200 Manual

PID TEMPERATURE CONTROLLER
TC200 MANUAL
TC100
TC110 TC210
TC100
LOCK
AT OUT AL LOCK
AL
OUT
AT
AT OUT AL LOCK
NOTICE
Please confirm the specification of controllers is to totally with
your requirement before using it, also read this user's manual
in detail.
DANGER
D anger! Electric Shock!
D on't touch AC power wiring terminal when controller has been
powered!
Keep the power off until all of the wiring are completed!
WARNING
1. Please confirm the AC power wiring to controller is correc
otherwise it would be caused aggravated damage on
controller . (
TC100/200/210/300/400 with Pin 1,2; TC110 with Pin 7,8)
2. Be sure to use the rated power supply(100~240VAC or 24VDC)
otherwise it would be caused aggravated damage on
controller.
3. Please confirm wires are connected with correct terminal
(Input, Output, Alarm).
4. Use M3 screw-compatible crimp-on terminals with an
insulation sleeve, as shown below.
φ3.2mm
.
5 8mm
or less
Torque : 0.4 N.m(4kgf.cm)
5. Avoid to install controller in following places:
a. A place where the ambient temperature may reach beyond
℃
the range -10 to 50 .
b. A place where the ambient humidity may reach beyond the
range from 35 to 85% RH.
c. A place where the controller likely to come into contact with
water, oil, chemicals, steam and vapor.
d. A place where the controller is subject to interface with static
electricity, magnetism and noise.
6. For thermocouple(TC) input, use shield compensating lead wire.
7. For RTD input, use shield wires which have low resistance and no
resistance difference between the 3 wires.
8. DIP switch mounts on the PCB, inside the unit. Power off and
detach the case before change setting.
SPECIFICATIONS
TC100
TC110-10
Model TC110-11 TC200
TC110-20
TC110-21
Dimension(mm) 48Hx48W 96Hx48W
Rated Voltage 100 ~240VAC 50/60Hz or 24VDC
Voltage Range
Accuracy
Input
Relay NO 5A / NC 3A 250VAC
Output
and Voltage DC24V (for SSR drive)
Electrical Life
100000 times or more (Under the rated load)
Control Algorithms
Ω
10M
Isolated Resistance
and case(ground) at DC 500V
1000V AC for 1 minute between input terminals and case(ground)
Dielectric Strength
1500V AC for 1 minute between output terminals and case(ground)
Power Consumption Approx.3VA Approx.4VA
Ambient Temperature
Ambient Humidity
Weight Approx.130g Approx.200g Approx.200g Approx.200g Approx.260g
INPUT TYPE TABLE
INPUT TYPE CODE
1
K
2
3
Pt100
4
ANV ELECTRIC
TC400
TC300
MD
MD
MD
t
3.2mm
.
5 8mm
or less
TC210 TC300 TC400
48Hx96W 72Hx72W 96Hx96W
Rated 90~110%
0.5% of F.S.
,
K Pt100
,
PID ON/OFF
or more between input terminals
Approx.4VA Approx.3VA Approx.4VA
-10 ~ +50℃
35 ~ 85%RH
RANGE ( ) ℃ RANGE ( ) ℉
0.0 ~ 400.0℃ 0.0 ~ 752.0℉
0 ~ 1200℃ 0 ~ 2192℉
-50.0 ~ 400.0℃ -58.0 ~ 752.0℉
-50 ~ 600℃ -58 ~ 1112℉
PARTS DESCRIPTION
SYMBOL
PV
SV
TC100
1
9
2
7
AT OUT AL LOCK
MD
3
LOCK
AL
10 6 5 4 8
OUT
AT
SWITCH FUNCTIONS
Select the sensor input
type & control output by
DIP switch on the PCB.
OPERATIONS
POWER ON : Controller will display as following
Light all LEDs and all Display input type
7 segment displays
SETTING SV : Ex: Change SV from 100.0 to 200.0
(Setting without pressing any key over 30 seconds will no save and return to RUN mode)
Press key the SV Press key to select
number started to the digits.
flash Cyclic selection.
PARAMETER CONFIGURATION (LEVEL 1)
Press key into the LEVEL 1 parameter configuration.
(Setting without pressing any key over 30 seconds will no save and return to RUN mode)
UPPER LIMIT ALARM :
Setting range : 0.0 ~ 200.0
Default : 0.0
Press key to select the digits. Press
then press key save value and change to
3 seconds save value and return to
LOWER LIMIT ALARM :
Setting range : 0.0 ~ 200.0
Default : 0.0
Press key to select the digits. Press
then press key save value and change to
3 seconds save value and return to
UPPER ALARM SENSITIVITY :
Setting range : 0.0 ~ 200.0
Default : 0.0
Press key to select the digits. Press
then press key save value and change to
3 seconds save value and return to
LOWER ALARM SENSITIVITY :
Setting range : 0.0 ~ 200.0
Default : 0.0
Press key to select the digits. Press
then press key save value and change to
or press key 3 seconds save value and return to
INCREASE ON/OFF CONTROL SENSITIVITY :
Setting range : 0.0 ~ 200.0
Default : 0.0
Press key to select the digits. Press
then press key save value and change to
or press key 3 seconds save value and return to
DECREASE ON/OFF CONTROL SENSITIVITY :
Setting range : 0.0 ~ 200.0
Default : 0.0
Press key to select the digits. Press
then press key save value and change to
RUN
save value and return to mode.
NAME
1
Present Value Displays PV
2 Setting Value Displays SV
Down Key / Decrease numerals / Press more then
3
Lock Key 3 seconds to lock key or unlock key
4
Up Key Increase numerals
5
Shift Key Shift digits when settings are changed
Mode Key / Use for parameter calling up and
6
Save and Exit Key set value registration
7
Lock Indicator Lights when lock is activated
8
Alarm Indicator Lights when alarm is activated
9 Output Indicator Lights when output is activated
10
Autotuning Indicator Lights when autotuning is activated
ON
DIP Switch
Description
1 2 3
DIP Switch Number
, )
K Type Thermocouple (Default
Pt100 Type RTD
SSR Output
Relay Output
Display range (0~400.0)
Press key Increase
or Press key
Decrease value
key Increase or Press key Decrease value.
LOWER LIMIT ALARM
mode or press
RUN
mode.
key Increase or Press key Decrease value.
UPPER ALARM SENSITIVITY
RUN
mode.
key Increase or Press key Decrease value.
LOWER ALARM SENSITIVITY
RUN
mode.
key Increase or Press key Decrease value.
INCREASE ON/OFF CONTROL SENSITIVITY
RUN
mode.
(PID control mode without this option)
key Increase or Press key Decrease value.
DECREASE ON/OFF CONTROL SENSITIVITY
RUN
mode.
(PID control mode without this option)
key Increase or Press key Decrease value.
AUTO TUNING
mode or press
FUNCTION
ON OFF
1 2 3
ON OFF
OFF ON
ON
OFF
Ready for use
Press key save
value and return
to RUN mode
key
mode or press key
mode or press key
mode
mode
key 3 seconds
