Electric Fireplace Insert
Model Number: (EF42B, EF43B, EF44B, EF45B, EF302B)
O W N E R 'S M A N U A L
Read and understand this entire owner's manual, including
all safety information, before plugging in or using this
WARNING
product. Failure to do so could result in fire, electric shock,
or serious personal injury.
Keep this owner's manual for future reference. If you sell or
give this product away, make sure this manual accompanies
CAUTION
this product.
DO NOT RETURN!
Contact our customer service team for help first.
service2@richenchina.com
Call: 844-377-5786
Advertisement
Table of Contents
Summary of Contents for Ningbo EF42B
- Page 1 Electric Fireplace Insert Model Number: (EF42B, EF43B, EF44B, EF45B, EF302B) O W N E R 'S M A N U A L Read and understand this entire owner's manual, including all safety information, before plugging in or using this WARNING product.
-
Page 2: Table Of Contents
CONTENT Important Safety Information ……………………………………….…1 Technical Specifications ………………………….……..………4 Before Installation …………..……………………………..………5 Installation Instruction ………………………………....……...…6 Operation Instruction ………………………………………...…10 5a. Manual Control Panel ………………………………..……10 5b. Remote Control ………………………………………..…...12 Care and Maintenance ……………………………………..……13 Limited Warranty …………………...……………………....…15 Troubleshooting Guide ..……………………………………..…. 15 Schematic Diagram ……………………………………….. …………17... -
Page 3: Important Safety Information
1. IMPORTANT SAFETY INFORMATION When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • Read all instructions before using this appliance. • Use this appliance only as described in this manual. Any o t h e r u s e n o t r e c o m m e n d e d b y t h e m a n u f a c t u r e r m a y cause fire, electric shock, or injury to persons. - Page 4 • AW G mini mum size and rated to not less than 1875watts. N O T insert or allow foreign objects to enter any ventilation or exhaust opening, as this may cause electric shock or fire, or damage the appliance. •...
- Page 5 • Avoid use of an extension cord because an extension cord may overheat and cause a fire. However if you have to use an extension cord, the cord should be No.14 AW G minimum size and rated to not less than 1875watts. •...
-
Page 6: Technical Specifications
2. TECHNICAL SPECIFICATIONS Electric Specifications Watt (min/max) BTU(max) Heating Area(max) Model Volt EF42-45B, 5000 12.5 400 square feet 750/1500 EF302B Product Dimensions unit Model inch 51/64 13/16 15/16 7/16 25/32 13/16 1/16 E F42B inch 25/32 15/16 1/16 1/16 3/16 51/64 E F43B inch... -
Page 7: Before Installation
3. BEFORE INSTALLATION WARNING! DO NOT operate or use this Electric Fireplace if it is damaged or has malfunctioned or any part has been under water. Immediately call a qualified service technician to inspect and to replace any part of the electrical system if necessary. Keep plastic wrapping away from children. -
Page 8: Installation Instruction
POWER FLAME CRACKLING HIGH Remote Handset (1 pc) Battery (1 pc) Door Handle (2 pcs) ST4*10 Screw (4 pcs) Function Testing Please refer to section 5a. Manual Control Panel and 5b. Remote Control to test the appliance first before installation. Should any defects found, please contact service team for help. - Page 9 Tools Required A Phillips screwdriver Locating the Appliance Your new electric fireplace may be installed virtually anywhere in your home. However, when choosing a location, ensure that the general instructions for safety are followed. • For best results, install out of direct sunlight, water or very damp air.
- Page 10 long enough to reach the outlet, a grounded extension could be run from an existing socket outlet but a minimum size 14 AWG with a minimum rating 1875W would be recommended, and it should not be longer than 7ft and 10 31/64”. •...
- Page 11 Width (min) (suggest) inch - 21 7 ¹ ³/ 8 ³/ 22 ³/ - 24 EF42B 580-610 515 - 540 2 3 ⁷ / 7 ¹ ³/ inch 26 - 27 ³/ - 24 8 ³/ EF43B 660 - 690 595 - 620 ⁵...
-
Page 12: Operation Instruction
5. OPERATING INSTRUCTIONS Read and understand this entire owner's manual, including all safety information, before plugging in or using this product. Failure to do so could result in electric shock, fire, serious injury, or death. WARNING! Do not operate the unit if it is damaged or has malfunctioned. - Page 13 BUTTON NAME FUNCTION Turn the main power switch on. A long “beep” sound will be heard when the switch is turned at ON Position “I”. POWER SWITCH Note: The remote control will lost the memory for function settings when the switch is turned at OFF Position “O”.
-
Page 14: 5B. Remote Control
5b. Remote ControI Note: Remote control can be used only when the main power switch is on. Aim the remote control at the remote receiver (see picture on page 10) which is on the left of the main power switch. POWER FLAME CRACKLING... -
Page 15: Care And Maintenance
Temperature Limiting Control This heater is equipped with a Temperature Limiting Control. Should the heater reach an unsafe temperature, the heater will automatically turn O F F. To reset: • Unplug the power cord from the outlet. • Turn the Power Switch on the CONTROL PANEL to OFF. Wait at least 5 minutes. - Page 16 Glass: • Use a good quality glass cleaner and dry thoroughly with a paper towel or lint-free cloth. • NEVER use abrasive cleansers, liquid sprays, or any cleaner that could scratch the surface. Plastic: • Wipe gently with a slightly damp cloth and a mild solution of dish soap and warm water.
-
Page 17: Limited Warranty
7. LIMITED WARRANTY This warrants to the original purchaser that this product is free from defects in material and workmanship as of the date of purchase and that it will, under normal use and proper care, remain so for one year from the date of purchase. Missing or initially defective parts will be replaced free of charge during the period of this limited warranty. - Page 18 3) If there is no beep, the connecters on the PCB board might be loosen, please contact service team for a checking instruction. 4) If there is a beep and the control panel can be used but the remote is not working, the remote is not working either close or far, please contact service team for help.
-
Page 19: Schematic Diagram
see if the heater will work. 2) Product has been used for some time: Confirm if there's hot air blowing from the air outlet or something turning red inside when the heater is turned on. If yes, the fan is got stuck or the heat motor is not at the right position. - Page 20 Ningbo Richen Electrical Appliance Co., Ltd Address: No.19, Yongdinghe Road, Xiapu, Beilun, Ningbo PR. China 3.EF.42.05.051.A0...
