Summary of Contents for FASANO TOOLS FGA 330
- Page 1 AIR SAW Rev.092016 FGA 330 The reproduction of this document (even in partial form) is prohibited without the Fasangas S.r.l. authorization...
- Page 2 CONTENT GENERAL WARNINGS TECHNICAL FEATURES OF THE TOOL IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS FOR THE USE OF THE TOOL MAINTENANCE TROUBLESHOOTING DISPOSAL INFORMATIONS EC DECLARATION OF CONFORMITY WARRANTY...
- Page 3 2. TECHNICAL FEATURES OF THE TOOLS Model: FGA 330 Type: air saw Weight: 0,4 kg (0.9 lb)
- Page 4 3. IMPORTANT SAFETY INSTRUCTIONS When using this air tool, the following basic safety precautions should always be followed to reduce the risk to personal injury: Always wear safety glasses with side shields in accordance with applicable regulations. Air powered equipment are capable of propelling materials such as metal chips, saw dust and other debris at high speed, which could result in serious eye injury.
- Page 5 4. INSTRUCTIONS FOR USE OF THE TOOL Before each use: ATTENTION Before proceeding with the operation of lubrication, detachment / attachment, adjustment or installation of accessories, disconnect the air supply hose from the tool, having first taken care to close the tap of compressed air supply Drain water from air compressor tank and ATTENTION Always use clean, dry air at 90 PSI (6.2 bars) maximum air pressure.
- Page 6 Fasten the screws by hex wrench. Turn air compressor on and allow air tank to fill. 90 PSI (6.2 bars). This tool operates at a maximum 90 PSI (6.2 bar) pressure. Connect tool to air hose of recommended size (see the Technical specifications paragraph of this user manual). ATTENTION Do not use damaged, frayed or deteriorated air hoses and fitting.
- Page 7 ATTENTION Any excess oil in the motor is immediately expelled from the exhaust port. Always direct exhaust port away from people or objects. 6. TROUBLESHOOTING WARNING ALWAYS DISCONNECT AIR SUPPLY BEFORE PERFORMING ANY WORK ON THE TOOL. If the tool does not start: make sure that in the compressed air circuit there is really pressure;...
