1
Introducing the CoolMax CD-320

Product Overview

The CoolMax CD-320 is available from leading storage partners in pre-configured set-ups
with eSATA host connections; some also include USB host connections. Simply open the
box and connect the appliance with an appropriate host cable; it's that simple.
The CoolMax CD-320are available in four different configurations, each offering a different
subset of features and capabilities, as shown in the following table:
Table 1
Available Product Features by Chip Type
-
Feature
SATA
USB
JBOD
BIG
FAST
SAFE
SAFE33
SAFE50
Drive Locking
All Others Features
Throughout the remainder of this manual, all descriptions and screen images reflect the
SiI5744, which supports all product features. All references to "rotary switch" refer to the
settings of the CONFIG[2:0] pins, which can be hard-strapped to a specific configuration, or
dynamically selected using a rotary switch selection.
CoolMax CD-320 is powered by Silicon Image's industry-leading SteelVine™ architecture
(see Figure 1) which provides:
• SATA or USB host connectivity
• eSATA capable on all SATA ports
• Enhanced data protection
• High-performance storage
SiI5744
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
