Installation manual
The Intergas Gateway is simple and effective and uses its own RF wireless network to
connect to a boiler. This installation manual provides step-by-step instructions for
installing the Intergas Gateway, including verifying the RF link to the boiler ICX 120
controller and the Internet. The Intergas Gateway is compatible with the Intergas
Superflow series boilers.
Contents
Gateway
Power adapter
Ethernet cable
2 screws
2 wall plugs
1. Remove the gateway from the packaging
5. Connect the power adapter to the gateway
9. Download the Comfort Touch app
Download the Comfort Touch app from
Google Play or App Store.
Gateway
The gateway makes the connection
between the boiler, thermostat and
Comfort Touch app.
2. Remove the Ethernet cable from the packaging
6. Plug the power adapter into the wall socket
10. Create an account
Create an Intergas
account. Follow the
instructions in the app.
Comfort Touch thermostat
Our Comfort Touch is an incredibly
easy-to-use thermostat with a sleek,
compact design.
3. Connect the Ethernet cable
7. Five indicators will light up briefly
1 2 3 4 5
1 PWR: Gateway powered ON
2 WAN: Connection between gateway and Intergas server established
3 LAN:
Connection between gateway and home network established
4 RF:
Connection between gateway and boiler established
5:
Control
11. Link to your boiler
Login to your Intergas account from the app to pair
your gateway and the boiler. Follow the instructions
in the app.
INTERGAS
GATEWAY
INTERGAS
GATEWAY
Comfort Touch app
The Comfort Touch app makes it
extremely easy to operate the thermostat
using a smartphone and offers various
additional functionalities and options.
4. Remove the power adapter from the packaging
8. Local Wi-Fi (home) network
1 2 3
4 5
Make sure your smartphone and the Intergas Gateway
are using the same local network. To make the link,
3 indicators must light up.
12. Your boiler is now linked
1 2 3 4
5
If the link is successful, the first 4 indicators on the gateway
will light up. You can now operate your boiler remotely.
Note: The gateway is equipped with an auto restart function.
If the connection is interrupted for more than an hour,
the gateway will restart itself automatically.
Advertisement
Summary of Contents for Intergas LAN2RF
- Page 1 Installation manual The Intergas Gateway is simple and effective and uses its own RF wireless network to INTERGAS connect to a boiler. This installation manual provides step-by-step instructions for installing the Intergas Gateway, including verifying the RF link to the boiler ICX 120 GATEWAY controller and the Internet.
- Page 2 (see below for instructions). Indicators 1, 2 and 3 are lit Indicators 1, 3 and 4 are lit No RF connection with the boiler. There is no response from the Intergas server. 1 2 3 Possible causes/solutions: Possible causes: - Your boiler is not connected. Repeat the connection process.
