1. Introduction
Congratulations on purchasing the Stylus 1500. Using the latest innovations in technology the
Stylus 1500 offers fun, affordable and easy to use digital imaging.
Although you probably want to get started right away, please take a few minutes to read this
guide and familiarise yourself with your new Stylus 1500. Your new Stylus 1500 will take 80
Hi-Res (High Resolution) or 322 Low-Res (Low Resolution) images, which you upload to your
PC (Personal Computer) running Windows® 98 and Windows® Me or Macintosh™ running OS
8.6 - 9 via the USB (Universal Serial Bus) port.
You can also use your Stylus 1500 to capture not only snaps of your family and friends, but
also video and audio clips of them in action.
Your Stylus 1500 can also be used as a Web Cam. If you have an internet connection and
microphone (not supplied) you can chat face-to-face with friends and colleagues, conferencing
in real time.
Stylus 1500 comes with Time Lapse Photography. You can set your Stylus 1500 to operate
on its own throughout the day at predetermined intervals and take a series of images. With
this technique, you can make for example high speed video clips of:-
• changing cloud and weather formations
• watch the hands of a clock speed round in double quick time
• watch the tide go in and then out
• watch a flower open as the sun rises
The effects are amazing.
Please note that your images and audio clips are stored on your Stylus 1500's internal
memory. When you have taken your images and audio clips, the Stylus 1500 will wait for 30
seconds and then automatically switch to Stand-by mode, which draws a constant trickle of
power from the battery. To preserve your images, there is a backup battery which should
only be used in emergency cases to change your battery when you are away from your
computer and cannot upload your images.
© 2001 TCG.
TM
User's Manual
Page 1
www.cool-icam.com
EN FL Version 3 0801
Part No.: OM837033
