Summary of Contents for ClimateCraft DHII-007
- Page 1 Indoor Custom AHU Outdoor Custom AHU Factory Assembled Custom Air Handling Units Installation, Operation, and Maintenance Manual April 2021 IOM-SL-E-041521-AHU...
-
Page 2: Table Of Contents
13.1 ....Fan Surge ..................................29 13.2 ....Dwyer Digihelic DHII Programming ........................30 14.0 ....Useful Equations ................................. 32 FCD-0025 ClimateCraft Startup Form 101310 ....................34 ⚠ WARNING Only qualified personnel should install and service the equipment. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury. -
Page 3: General
This manual is a guide for the installation, operation, 3.1 Short-Term Storage and maintenance of ClimateCraft custom air handling If your ClimateCraft air handling unit will not be installed units. Due to the custom nature of ClimateCraft air immediately, it is important to properly store your unit to handling units, it is not possible to cover every aspect maintain its condition and warranty coverage. -
Page 4: Roof Curb Installation
A sealant may be used in place of the curb gasket if desired. ROOF DECKING Your ClimateCraft air handling unit will fit over the roof ROOF STRUCTURE curb and rest on the curb angle within the perimeter of the unit base as shown in Figure 4-1. -
Page 5: Rigging
Figure 4-2, cont’d. Suggested Roof Curb Installations Rigging CURB GASKET Proper equipment handling is critical to avoid damage to your ClimateCraft air handling unit during lifting. 2 X 4 NAILER ClimateCraft air handling units may be delivered fully assembled or in sections requiring on-site assembly. In... - Page 6 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 Figure 5-1. Example of proper rigging and lifting Figure 5-2. Example of proper rigging and lifting...
-
Page 7: Unit Assembly
Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 Squaring and alignment can be accomplished by using Unit Assembly a “come-along” or other device to apply pressure to the 6.1 Squaring the Unit Sections opposing side to square it up prior to assembly. Figures Units shipped in sections due to shipping requirements 6-3 and 6-4 show depictions of how the squaring of the or clearance limitations must be assembled at the unit... - Page 8 Because ClimateCraft, Inc. specializes in the the unit split opening. manufacture of custom products, it is difficult to 3. Install panel joint gasket, ClimateCraft part generalize about product clearances. However, certain number PGSK-001-001 along base frame tube. minimum clearances should be observed to facilitate Two pieces of gasket material should be used access to the unit and major components.
- Page 9 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 Figure 6-5. Figure 6-6. We make air handling technology. Better.
- Page 10 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 Figure 6-7. Figure 6-8.
- Page 11 Installation, Operation, and Maintenance Manual April 2021 6.3 Vestibule (Doghouse) Assembly Figure 6-11. Some ClimateCraft air handling units accept a bolt-on vestibule (doghouse) for field attachment. 1. Using double-sided tape, affix two layers of PGSK-001-001 to the base frame of vestibule as shown in Figure 6-9.
-
Page 12: Condensate Drain
“stacked” configuration where one unit section sits atop a lower section, it is essential to seal any air openings between the sections. Gasket is provided by ClimateCraft for this purpose and must be installed per H = Fan inlet pressure the instructions below. - Page 13 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 Figure 7-2. Negative Internal Static Pressure in Coil Section- Figure 7-3. Positive Internal Static Pressure in Coil Section- Fan On (Draw-Through Application) Fan Off (Blow-Through Application) Condensate drain pan Condensate drain pan H = Fan inlet pressure Recommendation: (in.
-
Page 14: Filters
Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 Figure 7-4. Positive Internal Static Pressure in Coil Section- 8.2 Universal Holding Frames Fan On (Blow-Through Application) The universal holding frame (Figure 8-1) surrounds each filter and can accommodate a variety of filters from the Condensate drain pan standard 2”... -
Page 15: Isolators
Installation, Operation, and Maintenance Manual April 2021 9.2 FanMatrix™ Isolators Isolators ClimateCraft FanMatrix™ isolators (Figure 9-3) do not 9.1 Plenum and Centrifugal Fan Isolators require adjustment. The shipping bolt should be removed ClimateCraft installs spring isolators under most fans. before operation with the bracket left in place (Figure 9-4). -
Page 16: Rainhoods
10.2 Stacked Rainhoods 10.0 Rainhoods Prior to installation, stacked rainhoods must be Due to shipping size constraints, ClimateCraft generally assembled. This is so the edge of the birdscreen of ships rainhoods loose for field installation. The installation an upper hood can be attached to the top of the hood process differs slightly if there is more than one rainhood immediately under. -
Page 17: Startup
April 2021 11.0 Startup 12.0 Maintenance ⚠ Once the ClimateCraft air handling unit is fully assembled, WARNING installed and all utilities have been connected, the unit is now ready for operation. However, before doing so, check Disconnect all electric power, including remote disconnects the following: before servicing. - Page 18 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 Do not open “8V” sheaves more than 8 ½ turns Two-Groove Variable-Pitch Key-Type Sheaves – Tighten BOTH locking screws “A” in the outer Figure 12-3 locking ring to 100-110 LB-IN. Each flange of the sheave has a small notch on the k) Verify sheave alignment, replace belts and apply O.D.
- Page 19 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 12.3 Belt Adjustment Figure 12-4. Improper belt fitment may cause pulley misalignment, excessive power consumption, reduced belt life, premature bearing wear, and noise. To check belt tension, press the belt firmly at the center of the span to check deflection objective (Figure 12-4).
- Page 20 Consult factory for lubrication intervals under severe operating conditions such as high temperatures, moisture, dirt or excessive vibration. Lubricant should be a high quality lithium complex grease conforming to NLGI Grade 2. ClimateCraft recommends Mobilux EP-2. Storage periods of 3-months or longer require monthly shaft rotation and purging of the grease prior to startup.
- Page 21 Consult factory for lubrication intervals under severe operating conditions such as high temperatures, moisture, dirt or excessive vibration. Lubricant should be a high quality lithium complex synthetic grease conforming to NLGI Grade 2. ClimateCraft recommends Mobilith SHC-100. The use of non-synthetic grease will decrease lubrication intervals by approximately 3 times.
-
Page 22: Fanmatrix™ Maintenance
2200 hrs* 7400 hrs 12000 hrs 15000 hrs including (225) Over 360 to 5000 2200 hrs* 3500 hrs 7400 hrs 10500 hrs including (300) *Relubrication intervals are for ball bearings **For operation at speeds >3600RPM, contact ClimateCraft for relubrication recommendations... - Page 23 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 Table 12-4. Service Conditions Hours per Ambient Service Severity of Service day of Temperature Atmospheric Contamination Interval Operation Maximum Multiplier Standard 104°F (40°C) Clean, little corrosion Severe 122°F (50°C) Moderate dirt, corrosion Severe dirt, abrasive dust, 122°F (50°C)* or Extreme...
-
Page 24: Door Adjustment
Occasionally due to racking occurring in transit or uneven storage or placement, the service doors may require adjustment. The following is a step-by-step process for adjustment of the air handler service doors: To adjust the ClimateCraft Door vertically or horizontally only one tool is required; a 1/8” Allen Wrench (tool shown in photo). -
Page 25: Field Penetration For Electrical Wiring
Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 12.8 Field Penetration for Electrical Wiring Determine size and location of penetration from outside of air handling unit. Drill, then hole-saw desired hole in proper location first from outside of unit. Repeat process on interior skin from inside unit. - Page 26 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 Continued from previous page. When finished, assembled coupling will appear as shown. Insert wall coupling into panel from outside of unit with appropriately sized nipple. Slide reducing washer over nipple and attach a second wall coupling to nipple.
-
Page 27: Troubleshooting Guide
Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 13.0 Troubleshooting Guide Symptom Source Condition Solution Vibration Drive Assembly Fan and motor pulleys not Align pulleys per Section 12.4 of this manual. aligned Fan and motor shafts not parallel Align motor shaft with fan shaft by adjusting the motor position and/or installing shims. - Page 28 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 Continued from previous page. Symptom Source Condition Solution CFM too low Filters Clogged, filter selection • Verify filter is correct for application. • Replace clogged filters. Coil Dirt clogged Clean coil Fan running backward •...
-
Page 29: Fan Surge
ClimateCraft air handling unit resulting from may have a design or construction problem with the operation in surge it not covered by the ClimateCraft system. Consult your building design professional and Limited Warranty. The fans also produce excessive noise ClimateCraft for solutions to the problem. -
Page 30: Dwyer Digihelic Dhii Programming
1.180 1. The fan sizes referenced above are for ClimateCraft FanMatrix™ fans. 2. The “CFM @ Full Range” is a programming parameter used to scale the 4-20mA output signal when interfaced with a building automation system. The values given are for a K-factor of 1. - Page 31 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 To program the DHII to display flow in CFM and set the Y dim (above) and K factor (above) complete the following: Press the menu key once. The display should read SECr MENU Hit the down arrow key once.
-
Page 32: Useful Equations
Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 14.0 Useful Equations 14.1 General Equations Total Pressure = Velocity Pressure + Static Pressure Velocity Pressure = (Velocity / 4005) = CFM * (RPM / RPM Static Pressure = Static Pressure * (Velocity /Velocity = Hp... - Page 33 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 14.3 Belt and Drive Equations Pitch Diameter of Driver = (Driven Pitch Diameter * Driven Speed) / Driver Speed Pitch Diameter of Driven = (Driver Pitch Diameter * Driver Speed) / Driven Speed Speed of Driver = (Driven Pitch Diameter * Driven Speed) / Driver Pitch Diameter Speed of Driven = (Driver Pitch Diameter * Driver Speed) / Driven Pitch Diameter Belt length(pitch) = 2*C+1.57*(D+d)+(D-d)^2/4*C...
-
Page 34: Fcd-0025 Climatecraft Startup Form 101310
Inspect lighting circuit. Verify filter installation. Clean inside of unit of all construction dirt and debris. Adjust access doors for proper alignment as required in accordance with ClimateCraft IOM. Operational Check: WARNING! DO NOT OPERATE UNIT IS SYSTEM IS NOT PROPERLY BALANCED. - Page 35 Air Handling Unit Installation, Operation, and Maintenance Manual April 2021 This page intentionally left blank. We make air handling technology. Better.
- Page 36 Item Description 04/15/2021 Created 1427 NW 3rd St. Oklahoma City, OK 73106 FanMatrix™ and ClimateCraft ® are trademarks or registered Ph: (405) 415-9230 Fax: (405) 415-9231 trademarks of ClimateCraft, Inc. www.climatecraft.com IOM-SL-E-041521-AHU | © ClimateCraft, Inc. All rights reserved 2021...
