Anleitung/Manual: EnOcean-Bridge Befolgen Sie die Instruktionen bzw. technischen Daten aus dem Handbuch und dem Datenblatt. Diese finden Sie auf der Homepage comexio.com. Die Installation darf nur durch eine Elektrofachkraft oder eine elektrotechnisch unterwiesene Person erfolgen. Follow the instructions or technical data from the manual and the data sheet. These can be found on the homepage comexio.com.
Page 2
Schnellstart/Quick Start Installation: Installation: 1. Schließen Spannungsversorgung, 1. Connect the power supply, the extension bus and Extension-Bus und die SMA-Antenne, die aus the SMA antenna, which must be conducted out dem Verteiler heraus geführt werden muss, an. of the distribution. 2.
Page 3
Übersicht (Bild 1) Overview (Figure 1) 1. Anschluss Extension-Verbinder 1. Connection Extension connector 2. Stromversorgung 24V DC 2. Power supply 24V DC 3. Extension Bus (Erweiterungsbus) 3. Extension bus 4. Anschluss SMA Antenne 4. SMA antenna connector 5. Codierschalter 5. Code switch Bild 1...
Page 4
128 Aktoren und 256 Sensoren Maximum participants EnOcean Funk Bewegungsmelder/EnOcean wireless movement detector Typ: ZC017 EnOcean Magnethaftantenne/EnOcean antenna with magnetic base Typ: ZC012 Eisenberger Str. 56a 67304 Kerzenheim Deutschland Telefon: 06351 - 47804 0 Fax: 06351 - 47804 99 http://www.comexio.com info@comexio.com...
