Summary of Contents for Cool-Icam CIC-220
- Page 1 AQUA-CAM...
-
Page 2: Product Overview
Camera 1. Shutter/Select Button 2. Flash Light 3. Viewfinder 4. Lens 5. Mode/ON Button 6. LCD Display 7. Power Indicator 8. Hand Strap Holder (Hand strap not included) 1. Viewfinder 2. Flash Light Indicator 3. Flash ON/OFF Button 4. Battery door Product Overview... -
Page 3: Table Of Contents
6 Troubleshooting Problems ... 20 • Troubleshooting ... 7 Getting Help... 21 • Software Help ... 21 • Cool-iCam Online Services ... 22 • Customer Support ... 22 8 Appendix ... 22 • Technical Specifications ... 22 • Using your batteries... 22 •... -
Page 4: Getting Started
Send the video clip over the internet to family and friends. User’s Manual Registration Card CD-ROM includes Digital Camera Manager Software (PC), Digital Camera Driver (Mac), PhotoStudio® 4.0 (PC & Mac), ArcSoft Funhouse™ 1.0 (PC & Mac), ArcSoft PhotoPrinter® 2000 (PC & Mac), ArcSoft VideoImpression™... -
Page 5: Installing The Batteries
• Installing the batteries 2 x AA (UM-3) Alkaline batteries are supplied with the product. Follow the procedure below for installing batteries. Make sure the batteries are placed correctly in their positive (+/-) negative position. See inside marking on battery door cover. Note: Before opening the battery door and inserting the batteries, you must download all the pictures in the camera to a computer rst, otherwise pictures will be lost once battery power has been cut off. -
Page 6: Other Picture Taking Settings
• Other Picture Taking settings Setting Set Picture Quality Using the flash mode Self Timer Set Continuous Mode Deleting Pictures • Setting the Picture Quality 1. Pressing the Mode/On button will alter the camera settings – in order Images Remaining Continuous Mode Self-Timer Mode Clear Memory Mode... -
Page 7: Taking A Picture Under Water
• Taking a Picture under water The waterproof case will allow you to use your AQUA-CAM in the rain, at the beach or on the ski slopes. You can also use it underwater at depths down to 10 meters and in wet or dusty environments. Before you use the waterproof case, please make sure the case is functioning correctly and does not leak. -
Page 8: How To Install Arcsoft® Software
How to Uninstall Digital Camera Driver To uninstall Digital Camera Manager, click the “Start Menu” on your Windows® desktop, choose Digital Camera Manager folder under Program and choose “Uninstall Digital Camera Manager”. onscreen instructions. Notes: Uninstalling your Digital Camera Manager does not delete your album folders and therefore all images transferred into your default or created albums will be preserved. -
Page 9: Mac
How to Install Digital Camera Driver Software You are now able to enhance the resolution of your taken images by using the Digital Camera Driver. The images can be converted to higher resolution automatically by using a driver named “WWL Mac Installer”. -
Page 10: Software Included With Your Camera
Cool–iCam “Digital Camera Manager” Picture Transfer Software Digital Camera Manager software enable Pictures and Movie files to be transferred to the computer from the camera. Create your own files and folders to store the Pictures. Use the Arcsoft® software suite to edit and print the Pictures. - Page 11 2. Click “1. Get Template” to select the template in the different type of category and then click “OK” to confirm. Important! Make sure the “Digital Camera” CD-ROM is in the CD-ROM Drive. Using the images stored in your AQUA-CAM:- 3.
- Page 12 ArcSoft PhotoPrinter® 2000 Picture Printing Software ArcSoft PhotoPrinter® is an easy-to-use printing utility that enables the user to layout and print multiple images in different sizes quickly and easily on a single sheet of paper. The program offers a large selection of printing templates, including Kodak Digital Science Inkjet Photo Paper Templates and Avery-brand paper products.
- Page 13 Step 4 Double click on the small frame directly right of the large frame. A new template will appear at the top called “special effects” Double click on the “1. Fire” special effect which will now drop into the special effect frame you highlighted. Step 5 Double click on the next right large frame and repeat step 3 using a video template and double click template 5.
- Page 14 1. Double click the “Funhouse 1.0” icon from the Funhouse™. 2. Click “1. Get Template” to select the template from the category and then click “OK” to confirm. Important! Make sure the “Digital Camera” CD-ROM is in the CD-ROM Drive. Using the images stored in your AQUA-CAM:- 3.
-
Page 15: Computer System Requirements
ArcSoft VideoImpression™ 1.6 Movie Making Software Lets make a video! Follow these basic steps to make your first video. Step 1 Click on new Icon. Step 2 Using the Step 3 Double click on the Static.avi screen in the video template selection and a copy will appear in the first large frame on the storyboard on the bottom. -
Page 16: Transferring Pictures, Video Clips To Your Computer
Important Notes: You can use the Digital Camera Manager to upload images captured by your AQUA-CAM at any time whether or not the AQUA-CAM is full. Connect your AQUA-CAM to your PC via the USB cable. Plugging the USB connector into the AQUA-CAM will cause it to reset and issue a double beep but all stored images will remain. -
Page 17: Uploading Images
Uploading Images You are now able to enhance the resolution of your taken images by using the Digital Camera Manager. Before you start to capture all stored images, a window will pop up and ask you if you want to convert all the stored images to Higher Resolution automatically. - Page 18 High Resolution supports 20 frames of video. • When the AQUA-CAM is full, attach it to your PC via USB and run the Digital Camera Manager. • You can now start to create your own movie clips by following these steps: 1.
-
Page 19: Making A Call
To adjust frame rate: You can adjust the frame rate (number of frame per second) by pressing the 1. Click the button. 2. Enter the frame rate you want for your movie clip. To adjust resolution: You can adjust resolution for the movie clip by pressing the Resolution Button. -
Page 20: Troubleshooting Problems
Take picture in sufcient light. Use the ash light to take the photograph. Put Digital Camera CD in CD ROM drive. Go to the computer desktop. Right click on “My Computer”. Click “Properties”. Select “Device Manager”. -
Page 21: Getting Help
For Macintosh® Users Symptom I receive an error message when I am installing the Digital Camera Manager. “STV0680 Capture”/”WWL Import” plug-in le and STV0680 Camera Snapshots”/”WWL Mac” folder is not found in the Programs menu after I have installed the driver. -
Page 22: Cool-Icam Online Services
• Cool-iCam Online Services Website: http://www.coolicam.com • Customer Support SPECTRA MERCHANDISING INTERNATIONAL, INC. Chicago Industry Tech Park 4230 North Normandy Avenue Chicago, Illinois 60634, USA. Internet Address: spectra@interaccess.com For customer service, please call 1-888-235-0808 or visit our WebSite www.coolicam.com • Technical Specications Camera: •... -
Page 23: Tips, Your Safety & Maintenance
• Tips, Your Safety & Maintenance Your Camera should only be operated within the following environmental conditions; • 41 - 104º Fahrenheit; 5 - 40º Celsius • 20% - 85% relative humidity, non condensing Battery life or image quality may be affected outside these conditions Camera Cautions •... -
Page 24: Regulatory Information
• Regulatory Information FCC Notice This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
