Summary of Contents for greenfeathers NCTV2A
- Page 1 HD Wired Bird Box Camera Kit Quick Start Guide NCTV2A/NCTV2WP/NCTV8A Please read me before you start!
-
Page 3: Table Of Contents
Contents 1. Camera setup Congratulations! You are now the proud 2. Connect to your TV owner of a Green Feathers wildlife camera. 3. Physical installation For years we have been a leading provider of wildlife cameras and our bird box 4. -
Page 4: Camera Setup
1. Camera Setup Before installing the camera in your nest box, wire it up inside the house fi rst to make sure everything is working as it should. First, remove the lens cap. Take your 3-way cable and plug it into the camera’s trailing cable. -
Page 5: Connect To Your Tv
2. Connect to your TV Make sure you can get an image on your TV before mounting the camera into position. Please read through the following setup options. A. Direct Connection – SD Viewing If your TV has RCA (phono) connections, you can connect the AV cable directly to your TV using the provided adaptor for standard Audio not available on all models... - Page 6 TV or monitor (see diagram below). Select the correct source on your TV that corresponds to the HDMI input. USB Power In From Camera HDMI Cable to TV Audio connection (NCTV2A only) RCA TO HDMI Converter...
- Page 7 C. Connection via HDMI – Full HD Viewing Our HDMI converter allows you to watch Select the correct source on your TV that true 1080p HD images straight from your corresponds to the HDMI input. TV. Plug the twist-fi t connector into the converter and run an HDMI cable between Need a converter? Search on our website for GTTV2HDMI...
- Page 8 D. Use with DVR Recorders Enthusiasts can use this camera with HD DVRs using the BNC connection for recording. Connect the twist-fit connector into an available channel on the rear of your recorder. Set the camera to the compatible mode for your recorder (see opposite).
- Page 9 How to Set Camera Mode This camera is compatible with different video technology modes. The camera is set by default to CVBS. † If you are using our Full HD HDMI Info-Cir converter, you will need to set the camera to TVI to get the best experience.
-
Page 10: Physical Installation
3. Physical Installation Now you are ready to mount the camera into your nest box. What you will need Focussing your camera lens M Camera with bracket (included) Place a small bird-sized object in your bird M 5M screw (included) box. - Page 11 Mount the Camera in Nest Box Inside Box Rear of Installing in one of our bird boxes: Pass the 5M screw provided through the pre- drilled hole in the back of the box, screwing into the nut on the easy mount bracket. Our innovative anti-slip bracket design will hold the camera in place against the wood.
- Page 12 Wired Connection Tips Plan beforehand where you plan to lay If drilling a hole through the side of your your cable from your bird box to your house isn’t an option then you can bury a viewing device. Are you going to bury your shorter cable in the garden up to a window cable and where is the entry point to your and keep a coiled cable inside that can...
-
Page 13: Accessories
4. Accessories Now it’s time to install your accessories (sold separately). Boost the Light in your Nest Box Your camera’s night vision helps to improve Lamp the picture at night but you can also benefit from adding an extra light source to improve daytime images. -
Page 14: Troubleshooting
5. Troubleshooting Having trouble? Here are some answers. I’m not seeing an image on my TV 1. Is the power supply on? 3. Check wired connections Make sure the camera’s power supply is Make sure there are no loose connections at properly connected to a mains outlet. - Page 15 Question Need more help? If you require more assistance setting up your bird box camera or you need further support then please head to our Help website where you’ll be able to find all our support guides and videos. Find more help online. Mouse-Po green-feathers.co.uk/help...
- Page 16 For more help visit: green-feathers.co.uk/help Ver: 2010NCTV...
