Summary of Contents for PadBot P2

  • Page 1 PadBot User Manual...
  • Page 2 PadBot P2 1. P2 Part Identifications Size 26.6*37.2*110cm Sim Card Supported 10 inches Screen Size Main Switch 10’’ HD Screen HD1280*800 Resolution USB Charging Port N.W. 6.5Kg Battery Capacity 5000 mAh Foldable Body Charging Input 12.6V/1.5A 5.5*2.1 Charging Interface Body Fixer...
  • Page 3 PadBot P2 3. PadBot P2 Installation Body Installation Black bulge is marked in red Notch 1) Screw Body Fixer up to fix robot body, and follow correct direction to connect Body line with Base port. 2) Use screw key to fix M6 screw, and cover it with offered black plastic part...
  • Page 4 PadBot P2 4. PadBot P2 Tablet Installation, Connect Tablet with Body properly, and use M4 screw to fix Tablet. 5. How to Start Long press Main Switch until screen start. 6. Should connect with Internet, supporting WiFi & 4G: WiFi: recommending bandwidth 8Mbps.
  • Page 5 Charging PadBot P2 Charging 1. Robot equips with lithium battery, please charge robot fully in the first time to guarantee normal operation. 2. During charging, the charger’s light is red, when charge fully, the light turns green. And charger still shows green if connects no robot.

  • Page 6: How To Use

    How to Use Start robot after fixing Tablet, and open PadBot Telepresence Robot App; download PadBot Telepresence Admin App as the User side. Robot Side User Side (PadBot Telepresence Robot) (PadBot Telepresence Admin) 1. Open the App 1. Download the App 2.
  • Page 7 PadBot Telepresence Robot App--Main Interface Click the App, enter into Main Interface. There shows the serial number and QR Code of robot, scan QR Code with PadBot Telepresence Admin App firstly, to be the robot’s administrator. Main Interface PadBot...
  • Page 8 PadBot Telepresence Robot App--Robot Info In Main Interface, slide to left to switch to Robot Info page. There are the basic information of robot like: Icon, nickname, serial number and current status, etc. Robot Info Page PadBot...
  • Page 9 PadBot Telepresence Robot App--Robot Settings 1.In Robot Info page, click edit button to enter into Settings page. 2.Robot speed: there are 4 speed levels available, the higher level, the quicker speed. 3.Auto Charge: open auto charge function. When robot battery lower than 10%, robot will find nearby Charging Base to charge itself automatically.
  • Page 10 How to download App Ways to download PadBot Telepresence Admin App in iOS or Android device: l Mode1 1. iOS: Search “PadBot Telepresence Admin” in App Store 2.Android :Search “PadBot Telepresence Admin” in Google Play. l Mode2 Enter below link to download: http://s.padbot.cn:9080/cloud/updatemgr/appDownloadLink.action?app=p...
  • Page 11 How to use PadBot Telepresence Admin App 1. Open PadBot Telepresence Admin App, log in with phone number. 2. After log in, click “+” icon in Main Interface, find “Scan” option to add robot or add a specific video invitation into list. Scan QR Code in Main Interface to become the administrator of robot, or scan invitation Code to accept video invitation.
  • Page 12 PadBot Telepresence Admin--How to Set Up Video Invitation As administrator, user can set up video invitation by clicking “Invite” button. In set-up page, user can edit all details. After finish, share the invitation to relative people to join the video chat.
  • Page 13 PadBot Telepresence Admin--Video Call 1. In main interface, click “ Video Call” button in robot After video connecting successfully, user can control (as administrator) or “Video Call” button in meeting list robot to look up or down, move forward or backward, (as participant) to start video chat, and control robot to turn right or left;...
  • Page 14 PadBot Telepresence Admin--Control As administrator, user can control robot to move forward or backward, turn right or left by using “Control” button. In Control page, user can also adjust robot speed and control robot to charge. Control page Main Interface...

  • Page 15: Technical Support

    Yes, it support 4G LTE card, and also support WiFi. Q3 How to set up video invitation? Log in PadBot Telepresence Admin App, and click “Invite” button in Main Interface to set up video invitation. Share invitation with relative people, so they can join the meeting conveniently.
  • Page 16 2. Check if giving authorization to camera and microphone, if not, please open these authorizations in Settings of handhold device. For example, to open camera authorization in iOS device is “Settings→Privacy→Camera→PadBot Telepresence Admin”; for Android device, please follow “Settings→Installed Apps→PadBot Telepresence Admin- Permissions”.

  • Page 17: Matters Need Attention

    3. Please put the charger or charging base in a proper place for convenient use. 4. Please note that wrong type of battery may evoke explosion, please do follow instructions to dispose used battery. Contact Us Scan to follow PadBot’s Official Account in WeChat Inbot Technology Ltd. ADD: Room 1221-1222, No 140, West Zhongshan Ave, Tianhe District, Guangzhou, Guangdong, China.
