Contemporary Research IP-HDVR Dimensional Drawing

Hard Disk Drive
120 GB
Contemporary
Research
ANTENNA
AV IN 1 AV IN 2
V
AV OUTPUTS
CABLE
L
G-LINK OUT
TV Guide On-Screen guide and VCR+ is
protected by one or more US Patents.
This device complies with Part 15 OF the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
R
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Manufactured under license from Dolby Laboratories.
S-VIDEO
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
19.0" [482.6 mm]
17.0" [431.8 mm]
IP-HDVR
HDTV Tuner - DVR IR
Channel: 52-1
Recording
Front Panel
AV1 AV2 YPbPr
V
ETHERNET
Y
DIGITAL
AUDIO
L
Authorized
Pb Service Only
R
FIXED VARIABLE Pr OPTICAL
RGB OUT
(1080i/720p/480p)
Back Panel
MENU
SELECT EXIT
POWER
SETUP
RS-232
IR IN
DVI OUT 1 2
(1080i/720p/480p) IEEE-1394
UNLESS OTHERWISE SPECIFIED:
DECIMAL DIMENSIONS INCLUDING HOLES
XXX
FRACTIONAL DIMENSIONS INCLUDING HOLES
ANGLES 1
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
ALL DIMENSIONS IN INCHES.
DO NOT SCALE THIS DRAWING.
3.0"
[76.2 mm]
S 12
CAUTION
!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
R
AVIS RISQUE DI CHOC ELECTRIQUE NE
PAS OUVRIR
MODEL IP-HDVR
U L
120VAC~ 60Hz 35W
C R US
UL FILE NO. E225515
LISTED
MADE IN KOREA AND USA
DTV RECEIVER
41TB
17630 Davenport, Ste 113
Dallas, TX 75252
SYM ECO NO. DESCRIPTION
**** REVISIONS ****
DRAWN DATE
Contemporary
RSH 02/03/06
Research
XX .010
CHECKED DATE
TITLE
.005
1/64
APPROVED DATE
IP-HDVR WITH RKHDVR RACK SHELF
SCALE NONE DWG. NO.
RELEASED DATE
SHT OF
1 1 950-5063
DIR FILE IP-HDVR_PD.DWG
3.46"
[87.9 mm]
DATE APPR.
DWG. SIZE
C
