Summary of Contents for Qu-Bit Electronix CASCADE
- Page 1 GETTING STARTED WITH CASCADE...
-
Page 2: Table Of Contents
CONTENTS Skip Ahead Description First Patch Ratcheting AD ADSR Envelope Follower Compressor Edit Functions Gravity Gate Behavior Sound Sources Patch Examples Bouncy Ball Trap Hi-Hats Ocean Waves... -
Page 3: Description
VCA. You can patch in external audio to the VCA, or take advantage of 4 internal audio algorithms: white noise, 808 drums, and sine tones. Cascade will open up your system in ways that make you wonder how you ever lived without it. -
Page 4: Ratcheting Ad
RATCHETING AD Attack / Decay Envelope with Ratchetable Repeats Flips the envelope in place, maintaining Attack time from .5ms same voltage range to 5 seconds set by offset and level. (Green LED) Release time from Adjusts the output .5ms to 10 seconds level of the envelope signal Adjusts curve from... - Page 5 AD ENVELOPE Attack / Decay Flips the envelope in place, maintaining Attack time from .5ms same voltage range to 5 seconds set by offset and level. (Green LED) Release time from Adjusts the output .5ms to 10 seconds level of the envelope signal Adjusts curve from logarithmic to linear...
-
Page 6: Asr
ASR ENVELOPE Attack / Decay Envelope with Gate Configured Sustain Flips the envelope in place, maintaining Attack time from .5ms same voltage range to 5 seconds set by offset and level. (Green LED) Release time from Adjusts the output .5ms to 10 seconds level of the envelope signal Adjusts curve from... -
Page 7: Adsr
ADSR ENVELOPE Attack / Decay / Sustain / Release Envelope Flips the envelope in place, maintaining Attack time from .5ms same voltage range to 5 seconds set by offset and level. (Green LED) Decay time from .5ms Adjusts the output to 5 seconds level of the envelope signal... -
Page 8: Envelope Follower
ENVELOPE FOLLOWER Envelope Generator with Audio Detection Flips the envelope in place, maintaining Attack time from .5ms same voltage range to 5 seconds set by offset and level. (Green LED) Decay time from .5ms Adjusts the output to 5 seconds level of the envelope signal Adjusts the response... -
Page 9: Compressor
COMPRESSOR Compressor with Virtual Sidechain Flips the envelope in place, maintaining Attack time from .5ms same voltage range to 5 seconds set by offset and level. (Green LED) Decay time from .5ms Adjusts the output to 5 seconds level of the envelope signal Compression ratio adjustment... -
Page 10: Edit Functions
EOA Mode: Gate is HIGH when envelope is not in attack stage Input for external sound sources. For a more detailed look at Cascade, Used for Envelope Follower, additional example patches, and more, Compressor, and VCA head over to the product page and manual here: www.qubitelectronix.com/shop/cascade... -
Page 11: Bouncy Ball
- Level: 100% - Offset: 0% Don’t want to use a sound source? Send out Cascade’s VCA which normals to 1 of 4 sound sources you can choose by using the SHIFT MODE command. Cascade will shape the sound to the bounciness amount you desire. -
Page 12: Trap Hi-Hats
- Level: 100% - Offset: 0% Send Gate signal to the Trig input on Cascade. CV is sent to Repeats to increase/de- crease the number of ratchets. TO get a consistent ratcheting experience, send a clock signal into the Trig input. For more experimental trap hats, send a gated sequence into Trig. -
Page 13: Ocean Waves
- Level: 50% - Offset: 10% Cascade is set to White Noise and using a slow attack and decay to simulate the rolling waves crashing onto the shore. The sound is then sent out to Data Bender for textural layering in Micro Mode, while adding a lower register pitch to echo distant waves.
