INSTRUCTION MANUAL
INSTRUCTIONS MANUAL
Circuit breaker finder and socket tester
C-LOGIC 3600 Cod: 301000062
ENGLISH
The task of Circuit Breaker F inder/Socket Tester (C-LOGIC 3600) is finds correct breaker or fuse and test socket.
You will have annoyance no more far locating the corree!
circuit breaker supplying power to an AC outlet or lighting fixture.
WARNING: Please caution extremely when use the C-LOGIC 3600 in the gigantic circuit breaker ark. Don't use
when voltage more !han 120V/230V AC. You can turn on the flashlight in the dark surroundings.

Features

• Automatically and quickly finds correct breaker or fuse.
• Quickly and easy identifies conditions of circuit socket.
• MS5902-Tx Works on 220V AC, MS5902-TB Works on 11 0V AC
• Operating temperature: O - 50ºC

Operation: Locating a Circuit Breaker or Fuse

• Keep the pillar at left on the C-LOGIC 3600
• Plug the C-LOGIC 3600 into the receptacle. if there is a candescent light fixture, please install a socket adapter
befare make sure the switch is OFF. then plug the C-LOGIC 3600 into the socket adapter,turn the switch on at one
time.(Socket adapter need purchase additional)
• Go to the circuit breaker panel box.
• Turn the C-LOGIC 3600 on,the red LED is light.
• Place the chapiter of the C-LOGIC 3600 directly onto the circuit breaker or fuse.
• Slide the chapiter of the C-LOGIC 3600 down each breaker along both si des of the panel . Then the C-LOGIC
3600 will beep frequently as it denote the relative signal strength.
• Move the C-LOGIC 3600 down each breaker once more. On the third pass, the C-LOGIC 3600 will beep ,the red
LED will quench and the green LED will light only at the circuit Breaker powering the C-LOGIC 3600.
• Push the breaker off and check that the LED on the KPSCC820 in the outlet is off to confirm you have found the
corree! breaker or buse.

Test Socket

• Keep the pillar at right on the C-LOGIC 3600.
• Please contradistinguish nameplate on the C-LOGIC 3600.

Maintenance

• Keep clean with a dry cloth.
• When the yellow LED is light on the C-LOGIC 3600, please unscrew and
• remove cover, insert new 9V battery so as to the C-LOGIC 3600 is well-
balanced.
Comprobador de enchufes y localizador de protecciones
MGL EUMAN, S.L.
Parque Empresarial de Argame,
C/Picu Castiellu, Parcelas i-1 a i-4
E-33163 Argame, Morcín
Asturias, España, (Spain)
ENG
