Superior
PAPER HANDLING SOLUTIONS
Xtreme ™ Series
Touchscreen Manual
Software version 4.2.XX
Have this information ready when calling in about your equipment:
Model:
Serial #:
PLC firmware version:
HMI firmware version:
Warranty Start Date:
© Superior Paper Handling Solutions, Inc. All rights reserved.
Illustrations in this guide are for reference only and may depict optional features that are available
at additional costs.
Superior Paper Handling Solutions, Inc.
14414 21st Avenue North
Plymouth, Minnesota 55447 – USA
Tel. 763-546-9140
Fax. 763-546-8883
Email. info@Superior-PHS.com
Web.
www.Superior-PHS.com
Why Would You Go Anywhere Else?

Advertisement

loading
Need help?

Need help?

Do you have a question about the Xtreme Series and is the answer not in the manual?

Questions and answers

Related Manuals for Superior Xtreme Series

Summary of Contents for Superior Xtreme Series

  • Page 1 PLC firmware version: HMI firmware version: Warranty Start Date: © Superior Paper Handling Solutions, Inc. All rights reserved. Illustrations in this guide are for reference only and may depict optional features that are available at additional costs. Superior Paper Handling Solutions, Inc.
  • Page 2 CONTENTS SCREEN LAYOUT ......................3 MECHANICAL PUSH BUTTONS ..................4 POWER UP SCREEN ..................... 4 RUN SCREEN ......................... 5 5_JOB SETUP SCREEN ..................6 1_SETUP 1 SCREEN ...................... 7 2_SETUP 2 SCREEN ...................... 8 3_SETUP 3 SCREEN ...................... 9 4_COUNTERS SCREEN ....................9 6_DROPPER SELECT SCREEN ..................
  • Page 3 Why Would You Go Anywhere Else? page 3 © 2005-2015 Superior-PHS...
  • Page 4 COUNTER: Takes operator directly to 4-Counters Screen DROPPER: Takes operator directly to 6-Dropper Select Screen INPUTS/OUTPUTS: Takes operator directly to 7-Inputs 1 Screen SETUP: Takes operator directly to1-Setup 1 Screen HMI and PLC firmware versions page 4 © 2005-2015 Superior-PHS...
  • Page 5 NOTE: If using the EXT I/O to remotely STOP, RESET and CYCLE the feeder; Upon an error or remote stop, the Actual Count will always reset to zero and not retain the partial batch. If required to retain the partial batch, then remotely PAUSE/RESUME the feeder through the EXT I/O. page 5 © 2005-2015 Superior-PHS...
  • Page 6 Job Set function is not being used. The 4 - Counters Screen also displays the Batch Count field. They are also mirrored displays and the Reset buttons from either screen will zero it. COUNT to TOTAL : Display only. Displays the quantity left until the Job Set is complete.S page 6 © 2005-2015 Superior-PHS...
  • Page 7 This button will illuminate green when the condition is ON. PAUSE RESUME TIME: Enter the time value in seconds. This represents the time between the batch cycles. [KEYBOARD ENTRY-MIN/MAX WITHIN KEYBOARD DISPLAY ] page 7 © 2005-2015 Superior-PHS...
  • Page 8 KEYBOARD DISPLAY ] LOW STACK HALT: Set how many pieces once the Low Stack eye clears to when the feeder will stop. Product must be filled again to cycle the feeder. [KEYBOARD ENTRY-MIN/MAX WITHIN KEYBOARD DISPLAY ] page 8 © 2005-2015 Superior-PHS...
  • Page 9 TOTAL PIECE COUNTER: Display only. Counts the number of products through the sheet counter. NOTE: This Display is not resettable. It will reflect the number of pieces through the feeder at any given time page 9 © 2005-2015 Superior-PHS...
  • Page 10 [KEYBOARD ENTRY -MIN/MAX WITHIN KEYBOARD DISPLAY ] FEEDER DELAY: Sets the time in seconds the feeder will delay before feeding the next batch. [KEYBOARD ENTRY-MIN/MAX WITHIN KEYBOARD DISPLAY ] MANUAL CYCLE: Cycles the dropper once. page 10 © 2005-2015 Superior-PHS...
  • Page 11 This button will only activate the dropper forks and it will not activate the feeder. Note: This feature is active with the cover open if it's in manual mode. page 11 © 2005-2015 Superior-PHS...
  • Page 12 TAMPS # OF TIMES : Set how many times the tamper will extend and return during its tamping cycle. [KEYBOARD ENTRY-MIN/MAX WITHIN KEYBOARD DISPLAY ] TAMPER DISABLED : Turn the Tamper ON/OFF. Green Illuminate when the function is enabled. page 12 © 2005-2015 Superior-PHS...
  • Page 13 CYCLE: This function ONLY works when the 2nd Stage Dropper is enabled. From the home position the 2nd Stage dropper will perform 5 INDEX DOWN steps and then RAISE and return Home. It will place the feeder in a stopped mode while this test runs page 13 © 2005-2015 Superior-PHS...
  • Page 14 ENABLE OUTPUT FORCE ON. The button will illuminate green when on. Here you can test certain indicator lights and motor commands within the feeder and droppers. For assistance please contact the manufacturer. ***WARNING***do not leave the ENABLE OUTPUT FORCE ON for it will affect the feeder performance. page 14 © 2005-2015 Superior-PHS...

  • Page 15: Message Displays

    - The Batch count request is too large for the dropper to handle - Only one Dropper can be turned on in #6 Screen. With the error on screen you will have to turn one off. There is no reset page 15 © 2005-2015 Superior-PHS...
