ENERGY SERVANT
10 FUNCTIONS CONTROLLER
Model: TIS-HealTH-CM
Input
Output
TIS BUS
PIR Detection
Protection
Connection terminal
Operating and display
elements
Functions
Weight
Dimensions
Housing
BARCODE (UPC-A)
6 58921 79871 3
TIS Health Sensor helps you maintain air quality by
regulating temperature and detecting dangerous
gases. This solution is a fashionable ceiling sensor
with numerous functional features that can help
support healthcare in hospitals, clinics, and other
healthcare institutions.
P R O D U C T S P E C I F I C AT I O N S
PIR motion sensor
Digital input. Open / Close
Length of connected wire to DI
Light intensity sensor
IR receiver
Temp sensor
Infrared transmitters
DC Output
Number of devices on 1 line
Bus voltage
Current consumption
PIR range
PIR detection angle
Data / bus
Programming button
Indicator LED
Logic/ Timers
IR Code memory / Flags
Security Function
IR receiver
Without packaging
Length × Width × Height
Materials
Casing color
Base color
IR window cover
IP rating

PRODUCT INFORMATION

Dual element pyro-electric ceramic
2 Channels
< 350 meter
0 – 8000 Lux meter
TIS Infrared code receiver
Resistance Temp sensor
6 probes to cover 360 degree
12 V DC / 50 mA
Max. 64
12-32 V DC
<15 mA / 24 V DC
4-6 meters (installation height 2.6 - 3 meters)
110° from the celling down
Reverse Polarity Protection
terminal connector 0,25...2mm2
For assignment of the physical address
Blue or Red LED (optional)
32 Timers and Logic conditions
250 IR code memory and Flags
Away, Night, Day, fire alarm setting
8 buttons function
0.06 KG
92mm × 39mm × 92mm
Fire-proof ABS / Fire-proof PC
Gray White
Black
Transparent White
IP 20
