Spectroline FC-100 Series Manual

(1,1) -1- FC-100 Series AM05010-9.indd 3/30/2011 10:15:35 AM (1,1) -1- FC-100 Series AM05010-9.indd 3/30/2011 10:15:35 AM
English
Fan-Cooled, Long Wave UV Lamps
Ultraviolet radiation emitted from this product. Avoid exposure. ALWAYS
WEAR PROTECTIVE CLOTHING. EXPOSURE MAY CAUSE PREMATURE
AGING OF THE SKIN AND CANCER. ALWAYS WEAR PROTECTIVE
EYEWEAR; FAILURE TO DO SO MAY RESULT IN SEVERE BURNS OR LONG
TERM INJURY TO EYE. Never look directly into the lamp. Exposure can
cause eye and skin allergy and allergic reactions. Medications or cosmetics
may increase your sensitivity to ultraviolet radiation. Consult physician
before operating this product if you are using medications or have a history
of skin problems or believe yourself especially sensitive to sunlight.
FOR PROFESSIONAL EXAMINATION USE ONLY

IMPORTANT SAFETY INSTRUCTIONS

1.Read all instructions.
2.Care must be taken, as burns can occur from touching hot parts.
3.Do not operate the lamp with a damaged cord or if the lamp has been damaged.
4.Do not look directly into the UV light. Wear UV-absorbing protective eyewear (such as
the UVS-30 glasses provided) when operating this or any UV lamp. Never operate the
lamp with the UV filter lens removed.
5.Never operate this equipment in any manner not specified in these instructions because the
protection provided by the equipment may be impaired.
6.Adequate ventilation should be provided when working on operating combustion engines.
7.This unit is not recommended for high-dust environments.

GENERAL INFORMATION

1.Install the UV bulb and the Bulb-Saver™ (packed separately).
2.Connect the plug to a power outlet that complies with the electrical requirements specified on
the lamp's label.
3.The 120V and 100V lamps require just one three-position switch (on the ballast) to operate.
The first position (lowest) is OFF. The second position (up) turns on the fan, the third position
(up) turns on the lamp.
4.The 230V and 240V lamps require two switches to operate. Turn ON the ballast switch. This
powers both the fan and the lamp head. The unit will not operate unless the ballast/fan
switch is turned ON first. Turn ON the switch on the lamp handle. Allow approximately 3 to 5
minutes for the lamp to reach full lighting intensity. If the lamp fails to light, check that the bulb
is completely screwed into the socket and that both the switches are turned ON.
5.When the lamp is used intermittently and frequently, do not turn it off until the inspection is
complete. Any interruption in the power supply, such as a drop in voltage or changing power
outlets, will cause the bulb to go out. The bulb must then cool for a minimum of 5 minutes
before restarting. Continuous operation will also extend the bulb life.
6.Turn OFF the switch on the lamp handle, but leave the ballast/fan switch ON for 4 to 5
minutes to reduce heat buildup in the lamp head. Turn off all power before storing the lamp.
7.CAUTION: The lamp housing is fan-cooled, but the filter lens will become hot during
operation. The lamp stand is attached to the unit for increased protection. Do not
remove it during operation. Do not stand the lamp on furniture or papers while in operation.

OPERATOR SERVICING

Do not perform any servicing that is not covered in these instructions. Return the lamp to
the factory for maintenance not covered in this section.

HOUSING AND FILTER MAINTENANCE

• Always unplug the lamp from the power outlet before performing any maintenance or
servicing. Allow the UV lamp to cool before handling.
• Immediately clean spills from the housing with water and a mild detergent and wipe dry.
Periodically clean the filter with a glass cleaner and a soft cloth.

BULB/FILTER INSTALLATION OR REPLACEMENT

Use only a Spectroline 100S/M UV bulb. Using any other bulb may damage the unit and
®
will void the warranty.
1. Remove the lamp stand/protector.
2. Detach the silicone-rubber filter holder by peeling it from around the circumference of the lamp
housing. The filter will remain inside the filter holder. (If replacing the filter, press it firmly but
gently inside the filter holder.) Set the filter holder aside.
3. Place the UV bulb through the Bulb-Saver™/collar in the lamp housing. Turn the bulb
clockwise gently but firmly into the socket with the fingertips. (If removing an existing bulb,
turn it counterclockwise.) Do not operate the lamp without the Bulb-Saver.
4. Reattach the filter holder by pressing it with the heel of your hand around the circumference of
the lamp housing. Be sure the groove in the filter holder seats over the rim of the housing.
5. Reattach the lamp stand/protector.

UV INTENSITY VERIFICATION

To ensure that your lamp is operating at the required UV intensity, it should be checked
periodically. The AccuMAX XRP-3000 radiometer/photometer kit uses a dual-wavelength
TM
UV-A/VIS sensor detector to accurately measure ultraviolet irradiance or visible light. The
AccuMAX XR-1000 digital readout unit with the XS-365 UV sensor or the Spectroline DM-365XA
digital readout unit are also recommended for accurate UV-A measurement. The meters are
specially designed to measure the UV irradiance from 320–400nm with a peak at 365nm.
For more information about these units, please contact the Customer Service Department at
Spectronics Corporation. In the U.S. and Canada, call toll-free 1 800-274-8888. Outside the U.S.,
call 516-333-4840.

ELECTRICAL SPECIFICATIONS

Model Filter 120V/60Hz
FC-100 2F958 1.5 Amps
FC-100D 2F350 1.5 Amps
__
FC-100/F 2F958
__
FC-100D/F 2F350
__
FC-100/FA 2F958
__
FC-100D/FA 2F350
__
FC-100/FB 2F958
__
FC-100D/FB 2F350
__
FC-100/J 2F958
__
FC-100D/J 2F350
All bulbs are 100S/M, 100W Medium Base Spot
The FC-100D Series lamps are equipped with a diffusing filter that produces a "diffused spot" beam of
UV-A light.
FC-100 Series
DANGER
230V/50Hz 240V/50Hz 100V/50-60Hz
__ __ __
__ __ __
__ __
0.9 Amps
__ __
0.9 Amps
__ __
0.95 Amps
__ __
0.95 Amps
__ __
0.9 Amps
__ __
0.9 Amps
__ __
2.7 Amps
__ __
2.7 Amps
