- Page 1 MULTI FORMAT LCD MONITOR DT-G17/21/24/27 Dismantling manual for use by professional recyclers By: JVCKENWOOD Corporation First edition, May 2021...
- Page 2 ● Only the qualified technicians can dismantle the equipment. Disclaimer UNLESS SPECIALLY AGREED TO IN WRITING, JVCKENWOOD Corporation. a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.
- Page 3 Contents 1. Service tools 2. Parts List 3. Dismantling instruction...
- Page 4 1. Service tools Name Application Hexagonal wrench (Width across: 2.5 mm) Screw tightening Torque screwdriver(0,16-0,74Nm) Screw tightening...
- Page 5 2. Parts List 2.1 DT-G17 Parts List NO. Part NO. Description NO. Part NO. Description 42320644 Handle 42400121 JVC nameplate 42320048 Switch cover 42320594 Tally lampshade 39700431 Key board 39800424 Front panel 39700328 Rotary encoder board 1 43420114 Left and right foam...
- Page 6 2.2 DT-G21 Parts List NO. Part NO. Description NO. Part NO. Description 41010027 Speaker 42320594 Tally lampshade 39700431 Key board 42400121 JVC nameplate 39700328 Rotary encoder board 1 39800423 Front panel 39700500 USB board 42310660 LCD holder 42320592 Lower Press plate 41170086 LCD 42330085 Damping pad 42330593 Top Press plate...
- Page 7 2.3 DT-G24 Parts List NO. Part NO. Description NO. Part NO. Description 39700328 Rotary encoder board 1 42400121 JVC nameplate 39700500 USB board 42320594 Tally lampshade 39800397 Speaker cover 39800422 Front panel 41010027 Speaker 42310661 LCD holder 42320592 Lower Press plate 41170064 LCD 41110011 Transformer board 42330593 Top Press plate...
- Page 8 2.4 DT-G27 Parts List NO. Part NO. Description NO. Part NO. Description 39700328 Rotary encoder board 1 42400121 JVC nameplate 39700500 USB board 42320594 Tally lampshade 39800397 Speaker cover 39800421 Front panel 41040027 Speaker 42310662 LCD holder 42320592 Lower Press plate 41170039 LCD 41110011 Transformer board 42320593 Top Press plate...
- Page 9 3. Dismantling instruction The DT-G17(The disassemble instructions of DT-G17/24/21/27 are basically the same) 3.1 Remove all the 15 screws from the rear panel, see FIG. 3(The red circle must be removed). You don’t need to disassemble battery plate if there’s battery plate installed.
- Page 10 FIG. 5 3.4 To disassemble the LCD panel: 1. Remove the 16 screws form the red box, see FIG. 6. FIG. 6...
- Page 11 3.5 DT-G21/24/27 front and rear panel connecting line and PCBA. FIG. 7...
- Page 12 FIG. 8...
