T.BONE Tour Guide Talkback Transmitter Quick Start Manual

Tour Guide Talkback Transmitter

Safety instructions

Intended use
This device is used to receive radio signals and transform them into acoustic signals.
Any other use or use under other operating conditions is considered to be improper
and may result in personal injury or property damage. No liability will be assumed
for damages resulting from improper use.
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and
are not within reach of babies and young children. Choking hazard! En-
sure that children do not detach any small parts (e.g. knobs or the like)
from the unit. They could swallow the pieces and choke! Never let unat-
tended children use electrical devices.
Possible hearing damage
When earphones are connected, the unit can produce volume that
may cause temporary or permanent hearing impairment. Do not
operate the device continuously at high volume. Turn down the
volume immediately if background noise or hearing failure should
occur.

Features

• Guide system transmitter, system component with return channel
(switchable)
• 20 switchable channels in the UHF range 863 - 865 MHz
• Automatic synchronization of all receivers in a group
• LCD display

Operating elements

1
2
3 4 5
Front view Rear view

Display

Channel change
Mute
Volume value 5
2-way communi-
cation on / Ear-
phone volume
value 4
2-way communi-
cation on
Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • info@thomann.de
8
Top view
7 7 7 7 7 7 7
6
Bottom view
9
10
Side view
100 % battery charge level
70 % battery charge level
30 % battery charge level
10 % battery charge level
Quick Start Guide
This quick start guide contains important information on the safe opera-
tion of the product. Read and follow the safety advices and instructions
given. Retain the quick start guide for future reference. If you pass the
product on to others please include this quick start guide.
Electromagnetic compatibility with other electrical equipment
Using The Device near radios or TV sets may cause interference. Then increase the
distance between the devices.
Where to use the product
Never use the product
• in direct sunlight
• in conditions of extreme temperature or humidity
• in extremely dusty or dirty areas
• at locations where the unit can become wet
• near magnetic elds
General handling
• To prevent damage, never use force when operating the switches and controls.
• Never immerse the appliance in water. Just wipe it with a clean dry cloth. Do not
use liquid cleaners such as benzene, thinners or ammable cleaning agents.
Keep foreign substances from the unit!
Keep the device away from containers with liquids. Should any liquid get into the
unit, this could lead to its destruction or re. Be sure not to let any metal objects
into the unit.
• Built-in lithium-polymer battery, micro-USB charging port
• 3.5 mm mini jack socket for clip-on microphone
• Microphone unit with additional input (3.5 mm) for players
• Including lanyard
• Not compatible with t.bone Tour Guide Mini transmitters / receivers
1. Antenna
2. LCD display
3. Channel selection / volume down
4. On / o switch / Mute / Calling up setting parameters
5. Channel selection / volume up
6. Microphone connection
7. Communication switch
8. Eyelet for lanyard
9. Forced shutdown switch
10. Micro USB charging port
DocID: 463218_21.12.2020
