Propane Skillet
Instructions for use
© 2006 The Coleman Company, Inc.
www.coleman.com
9988 Series
This unit is an accessory for Coleman®
Propane Grill Models 9993 and 9998. Also read
the additional instructions and warnings that are
provided in the manual that came with your
Coleman® Grill.
CONSUMER/USER: This instruction manual
contains important information necessary for the
proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before
assembling and using the appliance. Follow all
warnings and instructions when using the appliance.
Keep this manual for future reference.
If you have questions about assembly, operation, servicing or repair of this
appliance, please call Coleman at 1-800-835-3278 or TDD: 316-832-8707. In
Canada call 1-800-387-6161.
INSTASTART™ Electronic Ignition
ANSI Z21.58a-2006/CSA 1.6a-2006
Outdoor Cooking Gas Appliances
IMPORTANT
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9988-A41 and is the answer not in the manual?

Questions and answers

Summary of Contents for Coleman 9988-A41

  • Page 1 Keep this manual for future reference. If you have questions about assembly, operation, servicing or repair of this appliance, please call Coleman at 1-800-835-3278 or TDD: 316-832-8707. In Canada call 1-800-387-6161. INSTASTART™ Electronic Ignition ®...
  • Page 2 If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid. 4. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department. Failure to follow these instructions could result in fire or explosion which could cause property damage, personal injury or death.
  • Page 3: Carbon Monoxide Hazard

    Only persons who can understand and follow the instructions should use or service this outdoor skillet. If you need assistance or outdoor skillet information such as an instruction manual or labels, contact The Coleman Company, Inc. DANGER CARBON MONOXIDE HAZARD • This appliance can...
  • Page 4: Explosion - Fire Hazard

    Your local authorities can advise you about these. • This skillet is designed as an accessory for Coleman® Grill models 9993 and 9998. The fuel is regulated through the preset regulator that came with your grill. Do not attempt to adjust.
  • Page 5: Technical Characteristics

    • Keep out of reach of children. Technical Characteristics Input: 8,000 BTU/H Category: Pressure regulated propane. Fuel: Uses fuel system on Coleman® grill models 9993 and 9998. Regulator: Uses regulator on Coleman® grill models 9993 and 9998. Ignition: Piezo electronic ignition. Cover Plate (do not heat)
  • Page 6 NOTE: This Side Solution™ Skillet attachment is designed for use only when properly attached to Coleman® grill models 9993 and 9998. Attempted use or setup in a manner not described in this manual is prohibited and will void the warranty.
  • Page 7: Leak Testing

    Skillet Assembly 6. Push the fuel hose connection through the opening in the side grill panel (Fig. 7). 7. Open the door to reveal the Quick Coupler in the upper corner. Retract the Collar on the Quick Coupler before attaching to the male fitting (Fig.
  • Page 8: Operation

    Leak Testing CAUTION Inspect the gas supply hose before each use. Look underneath the grill to inspect the hose assembly below the grill. If there are cuts, damage, excessive abrasion or wear, replace the hose prior to operating the appliance. During assembly of the grill and when attaching or replacing the L.P.
  • Page 9: Match Lighting

    Side Skillet Burner Lighting INSTASTART™ Electronic Ignition Skillet: 1. Remove skillet. 2. Make sure all valves are OFF. 3. Turn on the cylinder valve. 4. Push in and turn on the Skillet Control Knob counterclockwise to HIGH, then repeatedly press the igniter switch until the flame ignites (Fig 14).
  • Page 10: Cooking Tips

    Side Skillet Burner Lighting ■ A good flame should be blue with minimal yellow tip. Some yellow tips on flames are acceptable as long as no carbon or soot deposits appear (Fig. 18). Yellow Blue Yellow Holes in Burner NOTE: If the burner flame is accidentally extinguished, turn off the control knob and wait 5 minutes before relighting the appliance.
  • Page 11: Care, Maintenance And Cleaning

    Care, Maintenance and Cleaning CAUTION All cleaning and maintenance should be done only when the skillet and grill are cool and with the fuel supply turned off at the cylinder. Suggested Cleaning Materials: • Mild dishwashing liquid detergent • Hot water • Wire brush •...
  • Page 12: Parts List

    No. Part Number Description 9988-5031 Lid Assembly 9988-3421 9988-3911 Eventemp™ Flame Deflector 9988-3611 Parts List Skillet Burner English-11 Part Number Description 9988-5151 Electrode 9987-5111 Igniter Assembly 9986-5181 Knob Assembly please call Cover Plate...
  • Page 13: Limited One Year Warranty

    Coleman, at its option, will repair or replace this product or any component of the product found to be defective during the warranty period.
  • Page 14 Notes: English-13...
  • Page 15 Notes: English-14...
  • Page 16 The Coleman Company, Inc. • 3600 North Hydraulic • Wichita, KS 67219 U.S.A. 1-800-835-3278 • TDD: 316-832-8707 © 2006 The Coleman Company, Inc. All rights reserved. Coleman® and are registered trademarks and INSTASTART™ and EVENTEMP™ are trademarks of The Coleman Company, Inc. www.coleman.com 9988-050 (20070118)
