Ham HumiSense Quick Start Manual

TROUBLESHOOTING

TROUBLESHOOTING
The Status LED is not lit and
the device is shown as
disconnected on the app
This means that the device is not
connected to the Cloud
Check your Internet connection. If
you cannot access the Internet with a
different device on the same Wi-Fi
network check with your ISP
Check that the server is accessible at
https://hamsystems.eu with your
browser. If it is not, check again in 5
minutes or refresh the app / webpage
Try restarting the device with the Reset
Button and / or with removing and re-
attaching the power. Wait for a few
minutes
Check if the device is connected to
your Wi-Fi router / Access Point.
If the device does not appear to be
connected, then repeat the setup
procedure and make sure that the Wi-Fi
name and password are correct. The
device may also need to be whitelisted
depending on your network
configuration. Note that the device and
the app use the ports 9001 and 9002
No readings are shown or
they are too inaccurate
This is probably due to incorrect wiring
Check your wiring based on your sensor
configuration
9
10
Internet connection via Wi-Fi
Power supplied via micro-USB,
terminals or power bank
Easy setup
Various sensor configurations
2 years warranty
HumiSense HumiSense
1. Sensor GND (Black)
2. Sensor SDA (Green)
3. Sensor SCL (Yellow)
4. Sensor 3.3V (Red)
5. 5-12VDC
6. Gen. Input 2
7. Gen. Input 1
11
8. GND
9. Reset Button
10. Setup Button
11. Status LED
