- Page 1 ServoOne 4-450 A 4-450 A 4-210 A 4-210 A Specification Option 2 - Technology SSI Encoder simulation...
- Page 2 Specification ServoOne Specification Option 2 - Technology SSI encoder simulation ID No: 1106.22B.1-00 Date: 02/2011 This documentation applies to: NOTE: This document does not replace the ServoOne Operation Manual. Series Model Hardware version Firmware version Please be sure to observe the information contained in the “For your safety”, “Intended use”...
- Page 3 Table of Contents SSI Encoder Simulation ............. 4 Features ........................4 Pin assignment of SSI Encoder Simulation ...............4 Use of SSI Encoder Simulation ..........5 Enabling SSI Encoder Simulation ................5 Parameter description for SSI Encoder Simulation ...........5 Notes on parameterizing the SSI resolution .............5 Parameterization of polarity and phase ..............6 Suffixing a parity bit ....................6 Using synchronization .....................6...
- Page 4 Specification ServoOne 1. SSI Encoder Simulation 1.2 Pin assignment of SSI Encoder Simulation This document describes the SSI Encoder Simulation technology function of the ServoOne firmware and associated parameters, and provides information for commis- sioning. ATTENTION: For more information on safety, mechanical and electrical instal- lation, pin assignments and parameter configuration refer to the ServoOne Operation Manual and user documentation.
- Page 5 2. Use of SSI Encoder Simulation Parameter Unit Access Data Description type 2807 SyncOffset µs Float32 Shift of synchronization signal to closed-loop control cycle 2808 SyncUse UInt32 Synchronization to read cycle 2809 InSync UInt32 False ServoOne does not run 2.1 Enabling SSI Encoder Simulation synchronously with the read clock True...
- Page 6 Specification ServoOne 2.4 Parameterization of polarity and phase 2.5 Suffixing a parity bit Correct configuration of the polarity and phase is important for error-free operation of A parity bit can optionally be suffixed after the user data. The parity bit is then trans- the SSI interface.
- Page 7 Specification ServoOne SSI Module...
- Page 8 Specification Option 2 - Technology SSI encoder simulation ID No: 1106.22B.1-00 Date: 02/2011 LTi DRiVES GmbH We reserve the right to make technical changes. The contents of our documentation have been compiled with Gewerbestraße 5-9 greatest care and in compliance with our present status of infor- 35633 Lahnau mation.
