PCB Piezotronics ICP M350C04 Installation And Operating Manual page 15

Shock, ceramic-shear, 1 mv/g, 5k g range, filtered, 10-32 top

Advertisement

Model Number
350C04
Performance
Sensitivity(± 30 %)
Measurement Range
Frequency Range(± 1 dB)
Frequency
Range(- 3 dB)
Electrical Filter Corner Frequency(- 3 dB)
Mechanical Filter Resonant Frequency
Resonant Frequency
Broadband Resolution(1 to 10,000 Hz)
2
Non-Linearity(per 1000 g (9810 m/s
))
Transverse Sensitivity
Environmental
Overload Limit(Shock)
Temperature Range(Operating)
Temperature
Range(Storage)
Temperature Response
Base Strain Sensitivity
Electrical
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Discharge Time Constant
Settling Time(within 10% of bias)
Physical
Sensing Element
Sensing Geometry
Housing Material
Sealing
Size (Hex x Height)
Weight
Electrical Connector
10-32 Coaxial Jack
Electrical Connection Position
Mounting Thread
[5]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP
is a registered trademark of PCB Piezotronics, Inc.
ICP® SHOCK ACCELEROMETER
EN GLISH
SI
1.0 mV/g
0.10 mV/(m/s²)
± 5,000 g pk
± 49,000 m/s² pk
0.4 to 10,000 Hz
0.4 to 10,000 Hz
0.2 to 25,000 Hz
0.2 to 25,000 Hz
17 kHz
17 kHz
35 kHz
35 kHz
≥ 100 kHz
≥ 100 kHz
0.02 g rms
0.20 m/s² rms
≤ 2.0 %
≤ 2.0 %
≤ 7 %
≤ 7 %
± 50,000 g pk
± 490,000 m/s² pk
0 to +150 °F
-18 to +66 °C
-40 to +200 °F
-40 to +93 °C
See Graph
See Graph
0.002 g/µε
0.02 (m/s²)/µε
20 to 30 VDC
20 to 30 VDC
2 to 20 mA
2 to 20 mA
≤ 200 Ohm
≤ 200 Ohm
8 to 14 VDC
8 to 14 VDC
1.0 to 2.0 sec
1.0 to 2.0 sec
< 10 sec
< 10 sec
Ceramic
Ceramic
Shear
Shear
Titanium
Titanium
Hermetic
Hermetic
0.375 in x 1.15 in
9.5 mm x 29.2 mm
0.19 oz
5.4 gm
10-32 Coaxial Jack
Top
Top
1/4-28 Male
1/4-28 Male
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
- Metric Mount
M
Mounting Thread
[1]
[2][3]
W
- Water Resistant Cable
[2][4]
Electrical Connector
[2]
[2]
[2]
[2]
N OTES:
[1]Typical corner frequency for coupled electrical and mechanical filters.
[2]Typical.
[3]Electrical filter is a second order filter.
[4]Amplitude at resonance is +9 dB.
[5]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model ACS-14 High G shock accelerometer calibration using Hopkinson bar. (1)
Model ACS-22 NIST Traceable frequency response (100Hz to ±1 dB point) (1)
Entered: LK
Engineer: AJA
Date: 12/17/2020 Date: 12/17/2020 Date: 12/17/2020 Date: 12/17/2020 60172
3425 Walden Avenue, Depew, NY 14043
Revision: B
ECN #: 51341
OPTION AL VERSION S
M6 x 0.75 Male
M6 x 0.75 Male
Sealed Attached Cable
Sealed Attached Cable
Sales: RWM
Approved: BAM
Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
