Coachman 2022 Owner's Handbook Manual page 193

MODEL
Number of Berths
Interior Length
Overall Length
Overall Width
Overall Height
(including T.V Aerial)
Overall Height
(including Air Conditioner)
Maximum Headroom
Wheel Rim
Tyre Size
Tyre Pressure
(bar / psi at quoted MTPLM)
Bed Sizes - mm - option 1
Bed Sizes - mm - option 2
MTPLM
Mass in Running Order
Personal Payload
Options Payload
Total / Maximum User Payload
Maximum Hitch Weight
Upper MTPLM
(Optional weight plate upgrade)
* Estimated weights. Please refer to the website for confirmed weights. Note:- Please consult your dealer for terms and conditions regarding a weight plate upgrade to the upper MTPLM.
Coachman Caravan Company Limited, Amsterdam Road, Sutton Fields Industrial Estate, Hull, HU7 0XF
V I P s t a n d a r d s p e c i f i c a t i o n s ( b a s e d o n t h e m o d e l s b e l o w )
460
2
4750mm / 15' 7"
6380mm / 20' 11"
2310mm / 7' 7"
2650mm / 8' 8"
2750mm / 9' 0"
1955mm / 6' 5"
5.5J x 14
185 R14 104
4.5 / 65
2 x Single
1845 x 725 ( 6' 0" x 2' 4" )
1 x Double
2075 x 1720 ( 6' 9" x 5' 8" )
1444kg / 28.4cwt
1319kg / 26cwt
125kg / 2.4cwt
0kg / 0cwt
125kg / 2.4cwt
100kg / 1.9cwt
1500kg
520
3
5420mm / 17' 9"
7050mm / 23' 2"
2310mm / 7' 7"
2650mm / 8' 8"
2750mm / 9' 0"
1955mm / 6' 5"
5.5J x 14
185 R14 104
4.5 / 65
2 x Single 1980 x 760 ( 6' 5" x 2' 5" )
1845 x 725 ( 6' 0" x 2' 4" )
1 x Single 1720 x 700 ( 5' 7" x 2' 3" )
1830 x 720 ( 6' 0"x 2' 4" )
1900 x 1320 ( 6' 2" x 4' 4" )
1 x Double
2075 x 1720 ( 6' 9" x 5' 8" ) 1980 x 1400 ( 6' 5" x 4' 6" )
1 x Single
1830 x 720 ( 6' 0" x 2' 4" ) 1900 x 1320 ( 6' 2" x 4' 4" )
1544kg / 30.4cwt
1402kg / 27.6cwt
142kg / 2.8cwt
0kg / 0cwt
142kg / 2.8cwt
100kg / 1.9cwt
1550kg
w w w. c o a c h m a n . c o . u k
540 Xtra
4
5800mm / 19' 0"
7430mm / 24' 5"
2440mm / 8' 0"
2650mm / 8' 8"
2750mm / 9' 0"
1955mm / 6' 5"
6.0J x 15
205 / 70 R15 106
4.5 / 65
1 x Single
1 x Single
1 x Double
1 x Double
1 x Double
1700kg / 33.5cwt
1544kg / 30.4cwt
156kg / 3.1cwt
0kg / 0cwt
156kg / 3.1cwt
100kg / 1.9cwt
1800kg
