Remote Controlled Heavy Duty Switch, X-10 Activated
With Built-in Signal Bridge, and Repeater Function
Overview
The ELK-9100 is a remote controlled heavy duty switch which may be used with 220/240 Volt electrical appliances, water
heaters, pool pumps, or 110/120 branch lighting loads. It can be activated by an X-10 power line signal or contact closure
source. The unit features built-in signal bridging across both legs of the 220/240 power circuit for improved performance of
X-10 powerline signaling. It also features a selectable repeater function to provide more reliable X-10 communications over
longer distances.
Features
• Controlled Remotely from X-10 Power Line Carrier Commands.
• Optional Dry Contact Closure Activation.
• 30 Amp Long Life Double Pole Relay Contacts.
• Control One 220-240 Volts A.C. Device: Water Heater, Pool or Irrigation Pump, Heater, etc.
• Control Two 115-120 Volts A.C. Devices: Lights, Motors, etc.
• Built-in signal bridging of the two 220-240 Volts A.C. legs improves X-10 signal performance in the entire building.
• Selectable X-10 signal repeater functionality.
• Single or Dual Commands may be programmed to turn the relay On/Off. Dual commands reduce false activation.
• On-site programming of X-10 signal(s).
• Manual On/Off Push Button Control.
• LED Status indicators for X-10 signal, Circuit 1(Relay 1), and Circuit 2 (Relay 2).
• EEProm Memory remembers the last relay state in the event of a power fluctuation.
• Heavy Duty PVC enclosure prefitted with 1/2" conduit connector. Not suitable for wet locations.
• Color coded 18" wire leads, #10 AWG, MTW, stranded nickel plated copper rated for 30 Amps A.C.
• Mounting hardware included.
• Lifetime Limited Warranty.
Specifications
• Operating Voltage: 220-240 Volts A.C., drawn locally from the electrical panel (line) source.*
• Nominal Current Draw: 26mA
• Relay Contact Rating: 30 Amps at 120/240 Volts A.C.
• Wire Harness: 18" wire leads, #10 AWG, MTW, stranded nickel plated copper rated for 30 Amps A.C.
• Size: 4.36" W x 6.36" H x 2" D.
* Note: The ELK-9100 cannot be powered from GFCI Ground Fault Breakers.
However, GFCI Breakers can be utilized on the output (load) side of the ELK-9100.
* Note: The ELK-9100 is not compatible with the Leviton model 6325 Telephone Transponder due to some non-standard
line signals that the Leviton transmits.
05/03
ULTRAMATE
ELK-9100
OR
PO Box 100 • 3266 US Hwy. 70 West
Hildebran, NC 28637 • USA
828- 397-4200 • FAX 828- 397-4415
http://www.elkproducts.com • Email: info@elkproducts.com
ELK PRODUCTS, INC.
