Installation and technical manual
Dynamic Storage Heater
TTS 20
TTS 24
TTS 30
TTS 36
TTS 40
TTS 51
TTS 61
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR
FUTURE REFERENCE.
BE SURE TO OBSERVE ALL LABELS AND WARNINGS ON THE APPLIANCE
Edition:03/21_public
Id_Nr. 911 360 650
TTN 40
.
1
D
AU
Advertisement
Summary of Contents for Derby TTS 20
- Page 1 Installation and technical manual Dynamic Storage Heater TTS 20 TTN 40 TTS 24 TTS 30 TTS 36 TTS 40 TTS 51 TTS 61 THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. BE SURE TO OBSERVE ALL LABELS AND WARNINGS ON THE APPLIANCE Edition:03/21_public Id_Nr.
- Page 2 Manual Storage Heater Contents Safety page 3 General page 5 Design and Construction page 7 Operation page 8 Installation page 10 Room Thermostats page 16 Technical Data page 17 Attention : The storage heater must only be installed by a competent electrician. Edition:03/21_public...
- Page 3 Manual Storage Heater SPECIAL NOTES – Safety Keep children under 3 years of age away from the appliance unless constant supervision is provided. - The appliance can be switched on and off by 3- to 7-year-old children if they are supervised or have been instructed in the safe use of the appliance and understand the resulting dangers.
- Page 4 Manual Storage Heater Before setting up, have the load-bearing capacity and tread resistance of the floor checked by a specialist. When setting up on deep-pile carpets or similar soft floor coverings, it must be placed on a base plate (accessory) so that the floor clearance is maintained. Safety Due to the surface temperature of the electric heat storage unit, the following safety distances must be observed:...
- Page 5 Manual Storage Heater Introduction We congratulate you on your purchase of your Technotherm storage heater. Although the Installation and Operation of the heater is very simple, we advise that you read this booklet carefully as it gives you important information on safety, the installation and operation, as well as the care of the appliance.
- Page 6 Manual Storage Heater Caution Storage Heaters may become very hot! Electric storage heaters are space heating appliances and will attain surface temperatures in excess of 90°C (195°F) and greater directly in front of or above the discharge grille. Do not create fire hazards by placing flammable objects, materials or substances on, against or near the heater.
- Page 7 Manual Storage Heater Design and Construction TTS heaters are an assembly of 6 primary elements: Case - The attractively designed steel case is finished with a high degree of craftsmanship. All surfaces painted with a neutral off-white baked enamel. This case is very strong and provides the base upon which all other components are supported.
- Page 8 Manual Storage Heater Operating Instructions The operation of TTS heaters is convenient and economical. The heaters charge overnight. Radiation from the casing provides a low level of background heat. The fan can be switched on as desired increasing heat output. Heater Charging Adjustments TTS heater charging can be controlled manually.
- Page 9 Manual Storage Heater Output Control A proportion of the stored heat will be radiated from the casing providing a low level of background heat. Output can be increased by switching on the fan(s) whereby heat is discharged from the low-level outlet grille. This is done at the room thermostat located on the control panel.
- Page 10 Manual Storage Heater Installation Positioning Please read the instructions in the introductory section concerning position, safety and load- bearing capacity. If in doubt, consult a building engineer. Transport To facilitate transport, the heater and the bricks are packaged separately. The 7 bricks per core column are packed in two’s and three’s.
- Page 11 Manual Storage Heater The heater must be prevented from tipping over by fixing the two brackets to the wall using the screws and plugs, all of which are contained in the plastic bag in the right-hand side of the heater cabinet. If these screws and plugs are unfit for the wall fabric in question, other suitable materials must be used.
- Page 12 Manual Storage Heater ..pull the grille slightly outwards and push it to the left to remove it. Remove the front panel screws. Pull the bottom of the front panel out to about 45° and then pull it downwards to remove it from the top panel.
- Page 13 Manual Storage Heater Remove the four screws from the inner front panel and carefully remove the panel itself. Be very careful not to damage the fragile insulation attached to the rear of the panel. Having removed the card holding the heating elements in position, the core bricks are then put into the heater, starting with the bottom row.
- Page 14 Manual Storage Heater The second brick is then set on the far left of the core and the remaining bricks in the middle. This is repeated until all the bricks have been installed. After removing any waste, dust or other particles from the interior of the heater, the panels can be refitted in the reverse order, i.e.
- Page 15 Manual Storage Heater Connection of Supply Cables Warning! THIS APPLIANCE MUST BE EARTHED! Only heat resisting cable shall be used. The wire in the mains cable will be coloured according to the following code: Colours may vary nationally Green and Yellow: Earth Brown: Live...
- Page 16 Manual Storage Heater System Start-up Note: All breakers must be off for the heater to be safely de-energized to permit safe servicing. Steps to activate the system Control Panel - Energize control panel at the circuit breaker. Fans and Thermostats - Check proper operation of fans and thermostats. Check to see that the fans go ON and OFF with operation of the thermostat.
- Page 17 Manual Storage Heater Explanation: Model TTS 20 – TTS 61 – Device with manual control Technical Data: model standard Model TTS 20 TTS 24 TTS 30 TTS 36 TTS 40 TTS 51 TTS 61 Nominal rating * 2000 W 2400 W...
- Page 18 Manual Storage Heater Factory-fitted components A2/Z2 charge control discharge fan(s) Charge control Thermal Relay Safety thermostat line voltage for IRT Control resistor R1..6 Heating elements IRT 24 Z Integral Room Thermostat V1.V2 Fans (TT20&30 only one) grounding equipment Accessories supplied with power stickers.
- Page 19 Manual Storage Heater Technotherm Factory-fitted components Important! Do NOT connect Terminal 13, 14 and 15 to Charge control Safety thermostat power supply. Terminal 14 only when an external Control resistor R1..6 Heating elements Thermostat (accessory) is being use. V1.V2 Fans (TT20&30 only one) IRT 24 Z Integral Room Thermostat grounding...
- Page 20 Always interrupt all electrical circuits before undertaking any work in the electrical compartment. HEAD OFFICE Phone (02) 9605 5119 (02) 9618 3842 9/3 Lancaster St Ingleburn NSW 2565 P.O. Box 568 Ingleburn NSW 1890 E: sales@derbyproducts.com.au W: www.derby-heatbanks.com.au SA/WA NSW/ACT/QLD/VIC Derby Heatbanks Electrical Agencies D.R.
