Standard:
Video inputs:
Video outputs:
Audio inputs:
Audio outputs:
Image compression method:
Image records resolutions:
Recording speed adjustment:
Operation modes:
Recording modes:
Supported hard drives:
External storage devices backup:
Searching and playback the records:
Network functions:
Mobile phones support:
Alarm inputs / outputs:
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2021-06-07
User Manual
Code: XVR5116HS-I2
AHD, HD-CVI, HD-TVI, CVBS, TCP/IP DVR XVR5116HS-I2 16 CHANNELS DAHUA
AHD, HD-CVI, HD-TVI, CVBS, TCP/IP
16 pcs BNC
1 pcs HDMI 4K
1 pcs VGA
• 1 pcs - CINCH
• 16 - Audio support via coaxial cable, HD-CVI only
1 pcs CINCH
AI Coding / H.265+ / H.265 / H.264+ / H.264
• AHD / HD-CVI / HD-TVI :
5M-N - 1296 x 1440 ,
4M-N - 1280 x 1440 ,
1080p - 1920 x 1080 ,
1080N - 960 x 1080 ,
720p - 1280 x 720 ,
• CVBS :
960H - 960 x 576
• IP :
max. 6 Mpx - 3072 x 2048
6 Mpx IP @ 1 ... 25 fps
5M-N @ 1 ... 10 fps
4M-N @ 1 ... 15 fps
1080p @ 1 ... 15 fps
1080N @ 1 ... 25 fps
720p @ 1 ... 25 fps
960H @ 1 ... 25 fps
for each channel
16 x AHD / HD-CVI / HD-TVI / CVBS / IP + 8 x IP
Manual, Motion Detection, Schedule
1 x 10 TB SATA
Save single frames and whole records from DVR drive to the USB drive
Records searching: by time + timeline with record type. Playback: forward, fast, slow,
step
Advanced searching (to the one second accuracy)
Intelligent face search AI - simultaneous search in the archive of face recordings
based on max 8 photos taking into account the similarity threshold (for each photo
separately)
1/4/9/16 channel synchronous playback (1/4/9 with AI functions turned on)
Full support via network, Remote records copying, Web Server built-in max. 128 on-
line users
Port no.: 37777 or access by a cloud (P2P)
• Android: Free application
• iOS (iPhone): Free application
See how to configure the P2P function in Dahua recorders and how to enable the
mobile application
gDMSS Plus
iDMSS Plus
XVR5116HS-I2
or DMSS
or DMSS
