- Page 1 Invacare® PreciseR ™ Pediatric Flowmeter IRCPF16AW en User Manual This manual MUST be given to the user of the product. BEFORE using this product, read this manual and save for future reference.
- Page 2 All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written permission from Invacare. Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted.
-
Page 3: Table Of Contents
Contents 1 General ......... 4 1.1 Symbols . -
Page 4: General
Invacare® PreciseRx™ Pediatric Flowmeter 1 General General Warning Sign The background color inside the 1.1 Symbols triangle is yellow on product labels. DANGER! Read Manual – Danger indicates an imminently hazardous situation which, if not avoided, will result in The color of the symbol background is death or serious injury. -
Page 5: Intended Use
Output Fitting The device is a free standing, non-electrically powered, This product complies with Directive accessory for connection to the output fitting of an Invacare 93/42/EEC concerning medical devices. 5 liter output oxygen concentrator that delivers low flow rates of less than one (1) liter per minute to a pediatric The launch date of this product is stated in patient through a pediatric nasal cannula. - Page 6 Invacare® PreciseRx™ Pediatric Flowmeter oxygen concentrator. The input gas is then supplied to the input of a variable flow rate device and flow meter for flow rate adjustment and subsequent delivery to the output fitting for delivery to a pediatric patient through an externally connected administration accessory, a pediatric nasal cannula.
-
Page 7: Safety
DO NOT damage: use any lubricants on concentrator or accessory – DO NOT SMOKE while using this device. DO fittings unless recommended by Invacare. NOT use near OPEN FLAME or IGNITION – Keep the oxygen tubing, cord, AC adapter, SOURCES. - Page 8 – This product is intended to be set up by other manufacturers have not been tested by adults or under adult supervision only after Invacare and are not recommended for use reading and understanding the instructions and with Invacare products.
- Page 9 Risk of Injury Risk of Injury or Death A change in altitude may affect total oxygen While Invacare strives to produce the best available for use. To prevent oxygen deprivation: oxygen devices in the market today, the oxygen – Consult a physician before traveling to higher concentrator can fail to produce oxygen due to or lower altitudes to determine if the patient’s...
- Page 10 – Users should contact your dealer or Invacare for service. – DO NOT disassemble. Refer servicing to qualified service personnel. There are no user serviceable parts.
-
Page 11: Setup
4. Examine exterior of the flowmeter for nicks, dents, to the patient. scratches or other damages. Inspect all components. – Invacare recommends that crush resistant oxygen tubing (not supplied) be used with this Storage product. - Page 12 Invacare® PreciseRx™ Pediatric Flowmeter 1. Turn the Invacare 5 liter output concentrator on. An indicator light on the control panel will illuminate. Refer to the concentrator user manual for setup and use. 2. Set the oxygen concentrator to 2.0 L/min.
-
Page 13: Setup Without A Humidifier Bottle
Setup 3.3 Setup Without a Humidifier Bottle 1. Connect a 2.1 m (7 ft) oxygen tubing E from the output fitting C of the concentrator D to the input fitting B of the Pediatric Flowmeter A. 2. Connect a 7.6 m (25 ft) maximum length oxygen tubing (not shown) to the output fitting F of the Pediatric Flowmeter A. -
Page 14: Setup With A Humidifier Bottle
H manufacturer for instructions on filling and connecting to oxygen tubing. 3. After filling the humidifier bottle with water, place it in the humidifier compartment on the Invacare concentrator D (see concentrator user manual for mounting the bottle). 4. Connect 2.1 m (7 ft) maximum oxygen tubing G from... -
Page 15: Setting The Flowrate On The Pediatric Flowmeter
Setup 3.5 Setting the Flowrate on the Pediatric 1. Set the Pediatric Flowmeter as prescribed by the patient’s physician. Flowmeter The flowrate on the standard concentrator WARNING! flowmeter will drop below the 2.0 L/min setting – DO NOT select a different setting unless the after the flowmeter is installed and operating. -
Page 16: After Use
Invacare® PreciseRx™ Pediatric Flowmeter 4 After Use 4.1 Recycling Information This product has been supplied from an environmentally aware manufacturer. Follow local governing ordinances and recycling plans regarding disposal of the device or accessories normally used in operation. The device does not generate waste or residue in operation. -
Page 17: Technical Data
Technical data 5 Technical data 5.1 Specifications INPUT PRESSURE RATING: 34.5 ± 3.45 kPa (5 ± 0.5 psi) OXYGEN INPUT: 2 L/min, 85% to 95.6% oxygen MAXIMUM OUTPUT PRESSURE: 27.6 kPa (4.0 psi) OXYGEN OUTPUT FLOW: 0–750 cc/min (0–3/4 L/min) FLOW ADJUSTABLE IN INCREMENTS: 50 cc/min (1/16 L/min) FLOW ACCURACY:... -
Page 18: Warranty
Terms and conditions of the warranty are part of the general terms and conditions particular to the individual countries in which this product is sold. Contact information for your local Invacare office is located inside the back cover of this manual. 1150712-D... - Page 19 Ireland • Tel: (353) 1 810 7084 • Fax: (353) 1 810 7085 • ireland@invacare.com • www.invacare.ie Italia: Invacare Mecc San s.r.l., Via dei Pini 62, I-36016 Thiene (VI) • Tel: (39) 0445 38 00 59 • Fax: (39) 0445 38 00 34 • italia@invacare.com • www.invacare.it Nederland: Invacare AE, Galvanistraat 14–3, NL–6716 BZ Ede •...
- Page 20 Invacare Corporation EU Representative Invacare Deutschland GmbH Kleiststraße 49 One Invacare Way D-32457 Porta Westfalica Elyria, Ohio 44035 Germany United States Tel: (49) (0) 5731 754 0 Tel: 440–329–6000 Fax: (49) (0) 5731 754 52191 Tel: 800–333–6900 Technical Services Tel: 440–329–6593 Tel: 800–832–4707...
