Thank you for choosing MID products
Before using any machine please be sure to read the entire manual
BT Series
ID-Mounted Pipe Beveling Machine
Operation Manual
MID Industrial Tools INC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT Series and is the answer not in the manual?

Questions and answers

Summary of Contents for MID BT Series

  • Page 1 Thank you for choosing MID products Before using any machine please be sure to read the entire manual BT Series ID-Mounted Pipe Beveling Machine Operation Manual MID Industrial Tools INC...
  • Page 2 TABLE OF CONTENTS PART 1 EQUIPMENT INSTRUCTIONS PART 2 SAFETY INSTRUCTIONS PART 3 MACHINE SPECIFICATIONS PART 4 INSTALLATION AND OPERATION PART 5 IMPORTANT NOTES PART 6 DIAGRAM OF BEVELING TOOL BIT PART 7 DIAGRAM OF EXPANDING BLOCK PART 8 TROUBLE SHOOTING PART 9 EXPLODED VIEWS AND PARTS LIST PART 10...

  • Page 3: Part 1 Equipment Introduction

    PART 1 EQUIPMENT INTRODUCTION BT Series ID-Mounted Pipe Beveling Machine FEATURES: 1. Cutter can hold 3 tool bits at one time Automatic welding require OD Beveling, facing and internal beveling Only using 3 bits at one time can guarantee the precision of beveling 2.
  • Page 4 TYPICAL FUNCTION DESIGN Aluminum housing, light weight The equipment can machine V and U welding seam High strength mandrel and large-area expanding block improves the rigidity Two/three bevel tools can be installed on cutter, pipe can be worked synchronously TYPICAL Buttwelding seam TUBE I.D TUBE I.D TUBE I.D...

  • Page 5: Part 2 Safety Instructions

    PART 2 SAFETY INSTRUCTIONS We take great pride in manufacturing safe, quality products. Please comply with the following safety rules and instructions before operating the equipment. Read the following content before working READ THE OPERATION MANUAL Before operating, you should read the manual and make sure you understand all setup and operating instructions, it can help you save time and avoid injury to the operator and damage to the machine INSPECT MACHINE &...

  • Page 6: Part 3 Machine Specifications

    PART 3 MACHINE SPECIFICATIONS Drive option: Air, Electric Air requirement: 900-1500L Per minute @ 0.6/0.7Mpa Electric requirement:120V60HZ MODEL BT14 Machine Performance Ranges 16-33.4mm 25-88.9mm 60-168.2mm 65-219.0mm 145-355.6mm Working range inside diameter to outside diameter 0.62-1.3'' 1-3.5'' 2.3-6.5'' 2.5-8.6'' 5.7-14'' ≤8mm ≤15mm ≤20mm ≤20mm...

  • Page 7: Operation Procedure

    PART 4 INSTALLATION AND OPERATION SECTION 1 TOOL FEED / BACK INSTRUCTION A. BT1/BT3/BT6 tool feed / back hand wheel See figure: Tool Feed: rotate clockwise Tool Back: rotate counterclockwise B. BT8/VBT14 adopt tool feed/back ratchet spanner See below figure: Tool back position Tool feed position Tool Feed: Press pawl clockwise, pull spanner clockwise...
  • Page 8 distance between tool bit and pipe end high point. 4. Turn on the motor then turn off, let the cutter rotate 1 circle, in order to confirm the machine and tool bit are installed correctly before cutting, Turn on the motor, rotate the tool feed hand wheel (tool feed/back ratchet spanner) manually until the tooling makes contact with the pipe.

  • Page 9: Part 5 Important Notes

    PART 5 IMPORTANT NOTES 1. The carbon brush was adjusted before dispatch, they can feed automatically. Please do not adjust; Note: After 100 working hours, check the wear condition. Replace the carbon brush if needed. If the carbon brush wears out, please turn off the machine immediately, otherwise the motor will be damaged.
  • Page 10 PART 6 DIAGRAM OF BEVELING TOOL BIT M42 Tooling Chart Facing tools Description Part Number Application Sketch Facing tool Material:AISI M42 Width:22mm 42F-0622S Thk:6mm Step type Facing tool Material:AISI M42 Width:22mm 42F-0822S BT3, BT6, BT8 Thk:8mm Step type Facing tool Material:AISI M42 42F-0822 BT3, BT6, BT8...
  • Page 11 Beveling tools Description Part Number Application Sketch 42B-1025-30° Beveling Tool Material:AISIM42 BT14 42B-1025-37.5° Width:25mm a is beveling angle required Thk:10mm 42B-1025-a Inner Beveling tools Description Part Number Application Sketch Inner 42IB-0822S-12° Beveling tool Material:AISI M42 BT3, BT6, BT8 42IB-0822S-15° Width:22mm a is beveling angle required Thk:8mm 42IB-0822S-a...
  • Page 12 PART 7 DIAGRAM OF THE EXPANDING BLOCK Expanding block (extension legs) Model BT14 No Block 15-17 25-29.5 60-70 65-75 Plus pad 145-155 145-185 17-19 29.5-34 70-80 75-85 Plus pad 155-165 185-225 19-21 34-38.5 80-90 85-95 Plus pad 165-175 225-265 21-23 38.5-43 90-100 95-105...

  • Page 13: Troubleshooting

    PART 8 TROUBLE SHOOTING Trouble Possible reason Remedy The cable is not connected Check the cable and the air properly ; Air motor drive may supply device to see if it is Machine does not work have a connection problem properly installed The expansion structure is not Check the expansion screw or...

  • Page 14: Exploded Views And Parts List

    PART 9 EXPLODED VIEWS AND PARTS LIST Important Note: When needing a replacement part, please advise machine Model No. & Part No. BT1 BT3 BT6 P Air Motor Assembly Part No.: AMA136 No. Part No. Description Qty No. Part No. Description Qty AMA13601 Housing AMA13611 Exhaust cover AMA13602 Deep groove ball bearing...
  • Page 15 BT8 P Air Motor Assembly Part No.: AMA8 No. Part No. Description Qty No. Part No. Description Qty AMA801 Housing AMA811 Exhaust cover AMA802 Deep groove ball bearing AMA812 Motor rear cover AMA803 Rotor front cover AMA813 Pin AMA804 Eccentric stator AMA814 Cylinder spring AMA805 Motor rotor AMA815 Rotation Switch AMA806 Blade AMA816 Valve element AMA807 Rotor rear cover AMA817...
  • Page 16 BT14 P Air Motor Assembly Part No.: AMA14 No. Part No. Description Qty No. Part No. Description Qty AMA1401 Housing AMA1409 O ring AMA1402 Deep groove ball bearing AMA1410 O ring AMA1403 Rotor front cover AMA1411 Exhaust cover AMA1404 Eccentric stator AMA1412 Motor rear cover AMA1405 Motor rotor AMA1413 Ball Valve AMA1406 Blade AMA1414 Switch handle AMA1407 Rotor rear cover AMA1415...
  • Page 17 Electric Motor Adaptor BT1 BOSCH motor 1-7 Assembly Part No. EA1B 8-21 Assembly Part No. V1BPC BT1 Bosch Motor No Part No.: Description Qty Part No.: Description Qty EA1B01 Shell back cover EA1B12 Helical gear shaft EA1B02 Stator EA1B13 Flat key EA1B03 Carbon brush EA1B14 Bearing EA1B04 Stator housing EA1B15 Helical gear EA1B05...
  • Page 18 Electric Motor Adaptor BT3 BOSCH motor 1-7 Assembly Part No. EA3B 8-21 Assmbly Part No. V3BPC BT3 Bosch Motor No. Part No Description Qty No. Part No Description Qty EA3B01 Shell back cover EA3B12 Helical gear shaft EA3B02 Stator EA3B13 Flat key EA3B03 Carbon brush EA3B14 Bearing EA3B04 Stator housing EA3B15 Helical gear...
  • Page 19 Electric Motor Adaptor BT6 BOSCH motor 1-7 Assembly Part No. EA6B 8-21 Assmbly Part No. V6BPC BT6 Bosch Motor No Part No.: Description Qty Part No.: Description Qty EA6B01 Shell back cover EA6B12 Helical gear shaft EA6B02 Stator EA6B13 Flat key EA6B03 Carbon brush EA6B14 Bearing EA6B04 Stator housing EA6B15 Helical gear EA6B05...
  • Page 20 Electric Motor Adaptor Assembly Part No.: ED10 13 14 25 26 27 30 31 33 34 No. Part No.: Description Qty No. Part No.: Description Qty ED1001 Screw M4X25 ED1018 Rotor shaft gear ED1002 spring washer4 ED1019 Reducer ED1003 ventilation cover ED1020 spring washer5 ED1004 Motor cover ED1021 Screw M5X30 ED1005 Bearing 628 ED1022...
  • Page 21 Electric Motor Adaptor BT14 Assembly Part No.: ED14 13 14 25 26 27 30 31 33 34 No. Part No.: Description Qty No. Part No.: Description Qty ED1401 Screw M4X25 ED1418 Rotor shaft gear ED1402 spring washer4 ED1419 Reducer ED1403 ventilation cover ED1420 Spring washer5 ED1404 Motor cover ED1421 Screw M5X30 ED1405 Bearing 628...

  • Page 22: Part 10 Ordering Information

    Or take photo for replacement parts, send an email to us. REPAIR INFORMATION Please call MID prior to returning any equipment for repair. We will advise you of shipping and handling. Please enclose with machine to be repaired your name, address, phone number and a brief description of problem or work to be done.
  • Page 23 The Model No. you bought : What’s your overall evaluation of MID product: What’s your suggestion and expectation for MID product: Thanks for your support and cooperation, please post or email the sheet to us, we will embody it to our database.

  • Page 24: Warranty Card

    MID INDUSTRIAL TOOLS INC 7407 Spencer Highway Suite 310, Houston, Texas, USA WARRANTY CARD Company name Address Contact person Phone number Model No. Serial No. Production date Warranty period Inspector: Company seal: Warranty Rules: Warranty period starts from the date shipped on board, 12 month free warranty.
  • Page 25 MID INDUSTRIAL TOOLS INC 7407 Spencer Highway Suite 310, Houston, Texas, USA +1 (346)267-2247 pbrady@mid-pipe.com...
