GV K-FRAME X
VIDEO PRODUCTION FRAMES
Installation Planning Guide
13-00010-000AA
2/22/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the grass valley GV K-FRAME X and is the answer not in the manual?

Questions and answers

Related Manuals for Belden grass valley GV K-FRAME X

Summary of Contents for Belden grass valley GV K-FRAME X

  • Page 1 GV K-FRAME X VIDEO PRODUCTION FRAMES Installation Planning Guide 13-00010-000AA 2/22/18...
  • Page 2 Copyright and Trademark Notice Copyright © 2018, Grass Valley USA, LLC. All rights reserved. Belden, Belden Sending All The Right Signals, and the Belden logo are trademarks or registered trademarks of Belden Inc. or its affiliated companies in the United States and other jurisdictions.

  • Page 3: Symbols And Their Meanings

    GV K-Frame X Installation Planning Guide Important Safeguards and Notices Symbols and Their Meanings ............iii Warnings .

  • Page 4: Warnings

    Notices The presence of this symbol in or on Grass Valley equipment means that it has been tested and certified as complying with applicable Intertek Testing Services regulations and recommendations for USA/Canada. The presence of this symbol in or on Grass Valley product means that it complies with all applicable European Union (CE) directives.

  • Page 5: Cautions

    GV K-Frame X Installation Planning Guide Cautions Important Safeguards and Notices ........... . iii A caution indicates a possible hazard to equipment that could result in equipment damage.
  • Page 6 Notices • Cards in an earth grounded metal frame or casing do not require any special ESD protection. Battery Handling This product includes a backup battery. There is a danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer.
  • Page 7 GV K-Frame X Installation Planning Guide Identifie une borne de mise à la terre de protection. Il faut relier cette borne à la terre avant d’effectuer toute autre connexion à l’équipement. Identifie une borne de mise à la terre externe qui peut être connectée en tant que borne de mise à...
  • Page 8 Notices • La protection de ce produit contre les courts-circuits (surintensités) dépend de l’installation électrique du bâtiment. Assurez-vous qu'un fusible ou un disjoncteur pour 120 V CA ou 240 V CA est utilisé sur les conducteurs de phase. • Dans le présent manuel, toutes les instructions qui nécessitent d’ouvrir le couvercle de l’équipement sont destinées exclusivement au personnel technique qualifié.
  • Page 9 GV K-Frame X Installation Planning Guide • Si l’équipement n’est pas pourvu d’un modules d’alimentation auto-adaptables, vérifiez la configuration de chacun des modules d'alimentation avant de les mettre sous tension. • Assurez une ventilation adéquate. Pour éviter toute surchauffe du produit, assurez une ventilation de l’équipement conformément aux instructions d’installation.
  • Page 10 Notices Précautions pour les écrans LCD et TFT Regarder l’écran pendant une trop longue période de temps peut nuire à votre vision. Prenez une pause de 10 minutes, après 30 minutes d’utilisation. Si l'écran LCD ou TFT est brisé, manipulez les fragments de verre avec précaution au moment de vous en débarrasser.
  • Page 11 GV K-Frame X Installation Planning Guide Restriction on Hazardous Substances (RoHS) Restriction of Hazardous Substances (RoHS) KAYN-2-25-2M-KC, KAYN-2-25-3M-KC, KAYN-3-35- (Toxic or hazardous Substances and Elements) 3M-KC, KAYN-3-35-4M-KC, KAYN-3-35-4M-KS, KAYN- 3-35-5M-KS, KAYN-4-35-4M-KS, KAYN-4-35-5M-KS, KAYN-PNL-100-15, KAYN-PNL-200-25, KAYN-PNL- 200-35, KAYN-PNL-300-25, KAYN-PNL-300-35, KAYN- PNL-400-25, KAYN-PNL-400-35, KOR-1-15-1M-KCS, KOR-2-20-2M-KCS, KRR-2-25-2M-KC, KRR-2-25-C-...
  • Page 12 Notices Cables and Cable Assemblies Circuit Modules Metal Parts KAYN-ELITE-PS, KAYN-PRO-PS, K-FRM-100CS-KIT, (Toxic or hazardous Substances and Elements) K-FRM-CTRL-CS, K-FRM-INPUT, K-FRM-IO, K-FRM- IO-10GE, K-FRM-ME-DPM-S, K-FRM-OUTPUT and KRR-PRO-PS (Pb) (Hg) (Cd) (Cr6) (PBB) (PBDE) Part name Circuit Modules Metal Parts (Toxic or hazardous Substances and Elements) KOR-PNL-LAN-20 Part name (Pb)
  • Page 13 GV K-Frame X Installation Planning Guide Waste Electrical and Electronic Equipment (WEEE) End-user must dispose of any Waste Electrical and Electronic Equipment (WEEE) separately. Dispose equipment according to your local environmental laws and guidelines. Battery Disposal Your Grass Valley equipment usually comes with at least one button battery located on the main printed circuit board.

  • Page 14: Electromagnetic Compatibility

    Notices Electromagnetic Compatibility This equipment has been tested for verification of compliance with FCC Part 15, Subpart B requirements for class A digital devices. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 15: Table Of Contents

    Table of Contents Electromagnetic Compatibility..........xiv 1 Introduction .
  • Page 16 Table of Contents Suites and Control Surfaces ...........25 Ethernet Switches .

  • Page 17: Introduction

    Introduction Overview The Grass Valley GV K-Frame X family of multi-format digital production switchers provide powerful, groundbreaking features designed to meet the widest range of requirements for live studio, mobile, and post-production applications. The GV K-Frame X Video Processors are the heart of the system, providing extensive video switching and signal processing capabilities.

  • Page 18: Gv K-Frame X Standard Frame

    Introduction GV K-Frame X Standard Frame • Aux bus transitions for dissolves and wipes on aux bus outputs. • Interfaces with Grass Valley routers supporting Native Protocol. • Optional Integrated 10 Channel Image Store capable of delivering up to 64 GB storage of Stills (3,000 images) or “Movies”...
  • Page 19 GV K-Frame X Installation Planning Guide 4-ME 35 Control Panel Menu Panel Menu Panel Articulated Optional Module Optional Device Control Module Panel Control Unit (PCU) Kayenne 4-M/E 35 Control Surface 3-ME 35 Control Panel Menu Panel Menu Panel Optional Device Articulated Control Module Panel Control Unit (PCU)

  • Page 20: Flat Or Curved Control Panel Orientation

    Introduction Flat or Curved Control Panel Orientation Flat or Curved Control Panel Orientation The main Kayenne Control Panel supports different physical orientations. Besides a conventional flat surface, a special support design permits a curved working surface, where the M/Es progressively tilt for improved ergonomics. Curved Control Panel Assembly Flat Control Panel Assembly Curved and Flat Control Surface Installations...

  • Page 21: Menu Application

    GV K-Frame X Installation Planning Guide The Menu Panel has four USB ports, two on the right side edge of the panel and two on the back for keyboard and mouse (wired or wireless are supported). Menu Panel with Articulated Arm Menu Application The Menu application software provided with every K-Frame system can be run on a standard PC.

  • Page 22: Multiple Suite Kayenne Panel System

    Introduction Multiple Suite Kayenne Panel System Multiple Suite Kayenne Panel System A K-Frame system can be subdivided into two suites, if desired, each of which can have two control surfaces (Surface A and Surface B). Each surface has it's own set of Panel Preferences for configuration of the control panel behavior and independent macro systems to allow for independent building and running of macros by each operator at the control surface.

  • Page 23: Touch Screen Menu Panel Option

    GV K-Frame X Installation Planning Guide Karrera 3-ME 35 Control Panel Menu Panel Articulated Optional Touch Screen Karrera Menu Panel with Fanless PC Karrera 3-M/E 35 Control Surface Karrera Menu on PC Karrera 2-ME 25 Control Panel (Customer Supplied PC) Karrera 2-M/E 25 Control Surface Touch Screen Menu Panel Option A hardware Karrera Menu Panel is available as an option, which features a wide format 15...

  • Page 24: Karrera K-Frame System Examples

    Introduction Karrera K-Frame System Examples Karrera K-Frame System Examples Basic Single Suite Karrera Panel System A basic K-Frame system consists of a Control Panel, a Menu application running on a PC, and a Video Processor Frame. The Control Panel and Menu application make up a control surface associated with that frame.

  • Page 25: Gv Korona Control Surface

    GV K-Frame X Installation Planning Guide Suite 1 Karrera 3-ME 35 Control Panel Optional Touch Screen Karrera Menu Panel with with Fanless PC and Articulated Arm KSP 1-ME Standard 15-RU Soft Panel Option GV K-Frame X (Keyboard Included) (Customer Supplied PC) Suite 2 Karrera Menu on PC Karrera 2-ME 25 Control Panel...

  • Page 26: Multiple Suites And Control Surfaces Example

    Introduction Multiple Suites and Control Surfaces Example GV Korona Control Surfaces Multiple Suites and Control Surfaces Example Any Kayenne, Karrera, or GV Korona Control Panel can be configured with any GV K-Frame X Video Processor. The system can be subdivided into two suites and each suite can have up to two control surfaces.
  • Page 27 GV K-Frame X Installation Planning Guide Suite 1 3-M/E 35 Kayenne Control Panel Menu Panel Menu Panel Optional Device Articulated Control Module Panel Control Unit (PCU) 2-M/E 20 GV Korona Control Panel Standard 15-RU GV K-Frame X Suite 2 Karrera Menu on PC 2-M/E 25 Karrera Control Panel (Customer Supplied PC) GV Korona Control Panel Multi-Suite Frame Example...

  • Page 28: Soft Panel (Ksp) Option

    Introduction Soft Panel (KSP) Option Soft Panel (KSP) Option Soft Panel Application The KSP is an optional 1-M/E Soft Panel GUI which provides direct control of switching crosspoints, recalling effects and macros together with an integrated version of the Menu application.

  • Page 29: Supported Control Protocols

    GV K-Frame X Installation Planning Guide Supported Control Protocols • PBus II • Grass Valley CPL (Control Point Language) for Control Panel, Menu, Frame, and Automation systems • GPI Inputs and Outputs • Serial BVW-75 for VTR control • AMP (advanced media protocol) for Profile PVS, Profile XP Media Platform, K2, M-Series, Turbo iDDR, and T2 iDDR systems over Ethernet •...
  • Page 30 Introduction Supported Control Protocols...

  • Page 31: Frame Installation

    Frame Installation 15-RU Video Processor Dimensions 15-RU Dimensions (Front View) CAUTION: Mounting a GV K-Frame X in a rack immediately below equipment that extends forward from the rack may not provide enough clearance to completely remove the door.
  • Page 32 Frame Installation 15-RU Video Processor Dimensions 15-RU Dimensions (Side View)

  • Page 33: 15Ru Video Processor Installation And Airflow

    GV K-Frame X Installation Planning Guide 15RU Video Processor Installation and Airflow Air Exhaust Air Exhaust Air Exhaust Intake DO NOT BLOCK DOOR 15-RU Rack Mounting and Cooling Airflow...

  • Page 34: 15Ru Video Processor Views

    Frame Installation 15RU Video Processor Views 15RU Video Processor Views ME C1 & C2 Image Store Controller ME B1 & B2 with ME ME A1 & A2 ME D1 & D2 IMAGE STORE ME D1 & D2 ME C1 & C2 CONTROLLER &...
  • Page 35 GV K-Frame X Installation Planning Guide VID I/O 1 VID I/O 3 VID I/O 4 VID I/O 5 CONTROL I/O VID I/O 9 VID I/O 10 MOD I/O 1 MOD I/O 3 VID I/O 2 VID I/O 6 VID I/O 7 VID I/O 8 IN 1-16 IN 33-48...

  • Page 36: Power Supply Views

    Frame Installation Power Supply Views Power Supply Views A 1-RU Power Supply Frame provides DC power for the 15-RU Video Processor Frame. Front View with Cover 482 mm 19.0 in. 44 mm 1.72 in. Power Modules (up to 3) Front View Cover Removed DC Power Out Rear View Grounding Lug...

  • Page 37: Power Supply Frame Rack Installation And Airflow

    GV K-Frame X Installation Planning Guide 442 mm 17.4 in. 466 mm 18.3 in. 449 mm 17.7 in. 265 mm 490 mm 10.4 in. 19.2 in. 448 mm 41 mm 17.6 in. 1.6 in. 483 mm 19.0 in. Power Supply Frame Dimensions (Top View) Power Supply Frame Rack Installation and Airflow The power supply frame used with the 15-RU GV K-Frame X is ideally rack mounted immediately above the Video Processor chassis.

  • Page 38: Power Supply Cooling

    Frame Installation Power Supply Cooling Exhaust Power Supply Frame Intake GV K-Frame X Power Supply Rack Installation and Cooling Airflow Rear Rack Support Exhaust Rear Rack Support Intake Power Supply Rack Installation Power Supply Cooling The top surface of the rear of the GV K-Frame X Power Supply Frame has air holes and is slightly recessed, which permits air flow even if equipment is mounted in the rack directly...

  • Page 39: Power Supply Ac Requirements

    GV K-Frame X Installation Planning Guide above. These top recessed air holes must remain open for proper cooling. Ensure paper or other obstructions do not block these air holes. Power Supply AC Requirements The GV K-Frame X 15-RU Power Supply Frame has provision to support up to three hot swappable power modules.

  • Page 40: About Low Line (120V) Operational Considerations

    Frame Installation About Low Line (120V) Operational Considerations Most of the above is not an issue if high line (240V) operation is used. Since AC line currents are approximately half of those at low line, exceeding the current rating of a circuit should not be a problem.

  • Page 41: System Cabling

    System Cabling About the GV K-Frame X System Cabling Section This section provides overview information that is common to all GV K-Frame X systems as well as information specific to Kayenne, Karrera, and GV Korona Control Panels and components. System Cabling Overview The GV K-Frame X systems use Ethernet, serial, and USB connections and custom multi-pin cables for Kayenne.

  • Page 42: Customer Supplied Ethernet Routers And Switches

    System Cabling Customer Supplied Ethernet Routers and Switches Customer Supplied Ethernet Routers and Switches Existing facility Ethernet switches can be used in conjunction with a GV K-Frame X system. If connecting to a network area outside that is used by the GV K-Frame X, use of an appropriately configured Ethernet Router is strongly advised.

  • Page 43: System Cabling For Kayenne Control Panels

    GV K-Frame X Installation Planning Guide GV K-Frame X System Default IP Addresses Devices IP Address Control Panel Surface 1B 192.168.0.177 Control Panel Surface 2A 192.168.0.178 Control Panel Surface 2B 192.168.0.179 Clip Store 192.168.0.180 32-Crosspoint Remote Aux Panels: IP Address: 192.168.1.2 Kayenne Frame IP: 192.168.1.1 Karrera...

  • Page 44: Network Cabling

    System Cabling Network Cabling GV K-Frame X Menu Panel Kayenne PCU Video Processor RS-422/485 Menu Video Keyboard, VGA GPI In/Out Processor Hard RS-232 Tally Disk Kayenne Control Panel Keyboard, VGA Internal Control Menu RS-23 Local Aux Stripe Hard Image Store (option) Disk ME Stripe...

  • Page 45: Suites And Control Surfaces

    GV K-Frame X Installation Planning Guide throughput (to support Image Store file operations) and also offers redundancy. Because the Menu Panel and the Control Panel have independent cable connections, failure of one of these cables will not completely disable the system. Either the Menu Panel or the Control Panel will remain operational after a single network cable failure.

  • Page 46: Kayenne Control Panel Cables

    System Cabling Kayenne Control Panel Cables GV K-Frame X Video Ethernet Kayenne PCU 1 (100m / 300ft max single hop length, Processor unlimited distance using switches) Kayenne Suite 1 Menu Video Menu Panel Processor Internal Control Kayenne Control Panel Menu Image Store Local Aux Stripe (option)

  • Page 47: Kayenne Satellite Panel Cabling

    GV K-Frame X Installation Planning Guide mapped, but this order matches the default configuration. The table below shows the connections for various Kayenne Control Panel models used in a single suite. PCU Port to Control Panel Stripe Connections, Single Suite Control Panel Model PCU Port Panel Stripe...

  • Page 48: Kayenne Touch Screen Menu Panels (Used With Pcu)

    System Cabling Kayenne Touch Screen Menu Panels (Used with PCU) The Single Module Satellite Panel has internal module cabling the same as the other Stripes. Simply plug the module into a port using the provided cable. The Double Module Satellite Panel has a similar internal cabling arrangement, but one cable passes through a hole to the other tray.

  • Page 49: Network Cabling For The Karrera Control Panel

    GV K-Frame X Installation Planning Guide Suite Boundary Suite 1 Ethernet Menu Ethernet Menu Panel (100m / 300ft max single hop length, unlimited distance using switches) DVI-D GV K-Frame X Video Ethernet LAN Processor Switch RS-422/485 Karrera Control Panel, Suite 1 Video GPI In/Out Processor...

  • Page 50: Optional Karrera Local Aux Panel Cabling

    System Cabling Optional Karrera Local Aux Panel Cabling Touch Screen Menu Panel Bottom View Power Supply (80 watts) Power Source Fanless PC USB 2.0 Port Ethernet (front side Connector DVI-D 90 deg.) Type B (straight) Switcher Network Power Input Karrera Control Panel (rear) DVI-D (rear side 90 deg.)
  • Page 51 GV K-Frame X Installation Planning Guide Karrera Control Panel (rear) 12 Volt Panel to DC Out Local Aux Control Redundant AC (not Ethernet) Power Sources (2) Switcher Ethernet Network Karrera Local Aux Panel Use tiewrap for cable strain relief. 12 Volt DC In Local Aux Panel Cabling System Cabling for the GV Korona Control Panel...

  • Page 52: Suites And Control Surfaces

    System Cabling Suites and Control Surfaces GV K-Frame X Video Processor RS-422/485 Video GPI In/Out Processor Tally GV Korona Control Panel Keyboard, VGA Internal Control RS-232 Image Store Operator’s Laptop Clip Store Disable Internet or Wireless Connections Remote Aux Panel Facility LAN Ethernet Switch...

  • Page 53: About Gv K-Frame X Video Cabling

    GV K-Frame X Installation Planning Guide Suite Boundary Suite 1 Ethernet Ethernet (100m / 300ft max single hop length, unlimited distance using switches) GV K-Frame X Video Ethernet LAN Processor Switch RS-422/485 Kayenne Control Panel, Suite 1 Video GPI In/Out Processor Tally Keyboard, VGA...

  • Page 54: Ip I/O

    System Cabling IP I/O Outputs Paired outputs on the back of the Video Processor Frame are numbered 1-8 on each I/O module. Identical signals are present on each of the paired output connectors. All of the outputs carry the same video format, as determined by the standard selected and the connected reference signals.
  • Page 55 GV K-Frame X Installation Planning Guide the Nominal Switcher Delay minus the input time location within the autotiming window (the time location value can be zero, positive, or negative. GV K-Frame X System Timing, 4-M/E System Nominal Autotiming Minimum Maximum Frame Operating Mode Switcher Delay Window...

  • Page 56: Timing Analyzer

    System Cabling Timing Analyzer On GV K-Frame X systems, the autotiming window varies depending on the operating mode. The Timing Analyzer in the Video Settings Menu displays this autotiming information. Note: The maximum switcher delay is approximately one line of video. Timing Analyzer Use the Eng Setup, Video Settings, Timing menu when timing the system.

  • Page 57: Clipstore Cabling

    GV K-Frame X Installation Planning Guide Time Zone Processing Autotiming Range Delay Time Zone Processing Autotiming Range Delay Time Processing Zone Autotiming Range Delay Time Zone Processing Autotiming Range Delay Time Zone Processing Autotiming Range Delay Time Zone Output Autotiming Range Delay Autotiming Center of Time Zone 1...

  • Page 58: Clipstore Video Cabling

    System Cabling ClipStore Video Cabling ClipStore Video Cabling The ClipStore channels on the server backplane are labeled C1-C4 (Channel 1 through Channel 4 on the Summit) from left to right. The Solo backplane is not labeled, Channel 1 is on the left and Channel 2 is on the right when facing the backplane. ClipStore requires SDI connections for both video and key—...
  • Page 59 GV K-Frame X Installation Planning Guide ClipStore (4 Channel Summit) C1 SDI IN 1 C1 SDI IN 2 Channel 1 C1 SDI OUT 1 C1 SDI OUT 2 C2 SDI IN 1 C2 SDI IN 2 Channel 2 C2 SDI OUT 1 C2 SDI OUT 2 Video Processing Frame...

  • Page 60: Video Processor Frame Gpi/Relay Tally Interface

    System Cabling Video Processor Frame GPI/Relay Tally Interface ClipStore (Summit) Aux Bus Out/Video to DA (odd) Aux Bus Aux Bus Out/Key to DA (even) Pair Out Channel 1 Channel 2 Video Processing Frame Video/Key Channels In Channel 3 Channel 4 ClipStore Connection Using Distribution Amplifiers Video Processor Frame GPI/Relay Tally Interface The GPI (General Purpose Interface) and relay tally interface provides a means to transfer...

  • Page 61: Gpi Inputs

    GV K-Frame X Installation Planning Guide the GPI output software and the relay tally is driven by the Relay Tally system software. Relay tally connections can be used to trigger GPIs on external devices. GPI Inputs The purpose of the GPI In pins is to provide a stimulus from the external devices to the switcher.
  • Page 62 System Cabling Relay Tally/GPI Outputs extend across multiple connectors. For example, a situation may require two isolated common buses, half of the commons form the first common bus and the other half form the second common bus. The first four outputs have the common bus tied to +12 Volts. This drives the relay tally lamp system.

  • Page 63: Gpi In, Gpi Out, Relay Tally Pin Assignments

    GV K-Frame X Installation Planning Guide Although the diagram shows mechanical relays, the actual outputs are implemented with solid state relays. The solid state relays are bidirectional; either polarity voltage can be applied. If the switcher GPI/Relay Tally outputs are used to drive downstream DC relays, be sure to install diodes across the relay coils to clamp inductive spikes.
  • Page 64 System Cabling GPI In, GPI Out, Relay Tally Pin Assignments D-37 Female Pin 1 Pin 20 Pin 37 Pin 19 Socket Pinout...
  • Page 65 GV K-Frame X Installation Planning Guide GPI Signals GPI In, Tally, GPI Out Signals (first five boards from left to right) Ribbon 37-Pin Cable D-Sub GPIInCom GPIInCom GPIInCom GPIInCom GPIInCom GPIInCom GPIInCom GPIInCom GPIInCom GPIInCom GPIIn1 GPIIn5 GPIIn9 GPIIn13 GPIIn17 GPIIn2 GPIIn6 GPIIn10...
  • Page 66 System Cabling GPI In, GPI Out, Relay Tally Pin Assignments GPI In, Tally, GPI Out Signals (first five boards from left to right) Ribbon 37-Pin Cable D-Sub Tally15D Tally31H Tally47L Tally63P Tally79T Tally16D Tally32H Tally48L Tally64P Tally80T Reserved Reserved Reserved Reserved Reserved GPI In, Tally, GPI Out Signals (second five boards from left to right)

  • Page 67: Rs-422/485 Port Pin Assignments

    GV K-Frame X Installation Planning Guide GPI In, Tally, GPI Out Signals (second five boards from left to right) Ribbon 37-Pin Cable D-Sub Tally92W Tally108AA Tally124AE Tally1 40AI Tally156AM TallyComX TallyComAB TallyComAF TallyComAJ TallyComAN TallyComX TallyComAB TallyComAF TallyComAJ TallyComAN Tally93X Tally109AB Tally125AF Tally141AJ...
  • Page 68 System Cabling RS-232 Port Pin Assignments Standard VGA and keyboard ports, present on all processor boards, are also available for maintenance. RS-232 Pinouts Socket Signal Chassis Ground Transmit Data D-9 Female Pin 5 Pin 1 Receive Data Not used Signal Ground Not used Pin 9 Pin 6...

  • Page 69: Appendix A Specifications

    Specifications GV K-Frame X Video Processor Specifications Video Standards 3G Modes 1080p 50/59.94/60, Level-A and SMPTE 424M-2006 Level-B (Level B, SDI only) HD Modes 1080i 29.97/30 SMPTE 274M Tables 4 and 5 1080i 25 SMPTE 274M Tables 6 1080sf SMPTE RP211 Table 12-16 IP: 25/29.97/30 SDI: 23.976/24/25/29.97/30 720p 50/59.94/60...
  • Page 70 Specifications GV K-Frame X Video Processor Specifications Environmental Storage temperature -20 to 70 C (-4 to 158 F) Operating temperature 0 to 40 C (32 to 104 F) Relative humidity 0-95% (non-condensing) Electromagnetic environment E2 (according to EN55103-1 and -2 Network Connections Type of connection 10/100/1000 Base T...
  • Page 71 Input Impedance 75 ohm Max cable length SD Video 350 meters (1148 ft.) using Belden 1694A type cable HD Video 200 meters (656 ft.) using Belden 1694A type cable 3G Video 140 meters (459 ft.) using Belden 1694A type cable...
  • Page 72 Specifications GV K-Frame X Video Processor Specifications GV K-Frame X Serial Digital Video Outputs Nominal Amplitude 800 mv peak-to-peak across 75 ohm +/- 10% Rise & Fall Times 400 to 1400 picoseconds 75 ohm termination between 20% and 80% amplitude Timing Jitter £...

  • Page 73: Appendix B Regulatory Notices

    Changes or modifications not expressly approved by Grass Valley, A Belden Brand can affect emission compliance and could void the user’s authority to operate this equipment.

  • Page 74: Fcc Emission Limits

    Regulatory Notices FCC Emission Limits FCC Emission Limits This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may no cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation.

  • Page 75: Dekra Certificate

    GV K-Frame X Installation Planning Guide Category Standard Designed/tested for compliance with: EMC Directive 2004/108/EC Audio, Video and Entertainment Lighting Control for the via EN 55103-1 and 2 European Community. EN55103-1 : 2009 Electromagnetic compatibility. Product family standard for audio, video, audio-visual and entertainment lighting control apparatus for professional use.
  • Page 77 Contact Us Grass Valley Technical Support For technical assistance, contact our international support center, at 1-800-547-8949 (US and Canada) or +1 530 478 4148. To obtain a local phone number for the support center nearest you, please consult the Contact Us section of Grass Valley’s website ( www.grassvalley.com An online form for e-mail contact is also available from the website.
