AUSTRALIAN MADE CLEO User Manual

400wh portable solar generator

Advertisement

Quick Links

CLEO
400Wh Portable Solar Generator
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLEO and is the answer not in the manual?

Questions and answers

Summary of Contents for AUSTRALIAN MADE CLEO

  • Page 1 CLEO 400Wh Portable Solar Generator User Manual...
  • Page 2: Table Of Contents

    Contents Foreword .................. 3 Safety warning ................. 3 Storage and maintenance ............3 1. Packed Items ..............4 2. Function Introduction ............5 3. Charging Instructions ............6 4. Operational instructions ............7 5. Technical specification ............. 10 6. Trouble shooting ..............11 7.
  • Page 3: Foreword

    Foreword Safety warning 1. Please read all the safety warnings before use and keep the manual. Warranty does not cover damage caused by failure to follow instructions. 2. Please note the warning labels and operate accordingly. 3. Avoid exposing the product to rain or using the product in a humid environment. 4.
  • Page 4: Packed Items

    Customer service to get it resolved. You should receive the following items: Item Quantity Cleo Portable Solar Generator AC adaptor (including AC charging cable) Cigarette lighter cable( cigarette port to DC7909 connector male) MC4 cable (MC4 connector to DC 7909 connector male )
  • Page 5: Function Introduction

    2. Function Introduction 1. Main power button 8. Type-C PD output port 2. DC power button 9. USB output port 3. AC power button 10. LED light button 4. DC12V car ignitor output port 11. LED light 5. Handle bar 12.
  • Page 6: Charging Instructions

    LCD Battery Display: The battery icon indicates the battery level of this product. The battery level is displayed in 5 segments. When the battery is being charged, the icon will start flashing. When the battery is fully charged, the icon would stop flashing and all 5 segments will be filled. !...
  • Page 7: Operational Instructions

    AC charger to charge the product ! Note: Always use the standard AC charger that comes with the product. (1) Insert one end of the adapter into the wall outlet and insert the other end into the input port of the product. (2) Please unplug the charger after charging is completed.
  • Page 8 How to use the product? Turn on/off the product 1. Turn on the product: Press and hold the master power button about 2 seconds to turn on the product. The LED indicator light and the display screen will light up. 2.
  • Page 9 Estimation of backup time 75W LCD TV 20smartphones 20W LED lamp 2 hours 20 hours 5.3 hours 75Watt load 10Watt load 20Watt load 90W refrigerator 80W electric tool 200W electric stewing pot 5 hours 4.4 hours 2 hours. 80Watt load 90W load 200Watt load load power...
  • Page 10: Technical Specification

    5. Technical specification Output Rated voltage 100-120Vac 220-240Vac Rated power 300 W 450W Peak power AC output 300W≤load<450W@120S; Overload 450W≤load@1s; capability Frequency 50/60Hz(adjustable) DC12V output Rated voltage 12Vdc (12-14V workable) 10A ① (cigarette Rated current lighter) 9.6-12.6Vdc ② DC12V output Rated voltage (5521) Rated current...
  • Page 11: Trouble Shooting

    6. Trouble shooting If the product cannot charge or power appliances, please check the following: 1. Make sure the power button is turned on. 2. Make sure the AC and DC power buttons are on, viz. the LED on the right of the button is green.
  • Page 12: Frequently Asked Questions And Answers (Faq)

    Power>300W at 2mins or E36 Inverter output overloaded power >450W Recover by pressing any E37 Inverter output overcurrent AC output short-circuit button System overloaded, AC Total power>380W at output stop 3mins 7. Frequently Asked Questions and Answers (FAQ) ●How to check the state of charge? The battery icon display on the LCD display shows the battery level and charge status.
