Instructions
®
Pulse
WiFi Tank Level Monitor
Measures the distance between the device and the surface of the fluid to determine the
volume of fluid within a tank. For use only with Pulse Level. Intended fluids: oil, diesel,
waste oil, automatic transmission fluid (ATF), kerosene, anti-freeze, windshield washer
solution, waste water, and DEF. For professional use only. Not suitable for tank overfill
protection.
Not approved for use in explosive atmospheres or hazardous (classified) locations.
Part No. 25T460
Important Safety Instructions
Read all warnings and instructions in this
manual and in all related Pulse manuals
before using the equipment. Save all
instructions.
WARNING
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
•
Do not alter or modify equipment. Alterations or
modifications may void agency approvals and
create safety hazards.
•
Make sure all equipment is rated and approved for
the environment in which you are using it.
•
Use equipment only for its intended purpose. Call
your distributor for information.
•
Keep children and animals away from work area.
•
Comply with all applicable safety regulations.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the
work area to help prevent serious injury, including
eye injury, hearing loss, and inhalation of toxic fumes.
Level
This Tank Level Monitor (TLM) contains FCC ID 56T784.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
•
This device may not case harmful interference.
•
This device must accept any interference received,
including interference that may cause undesired
operation.
3A8507C
EN
Advertisement
Table of Contents
Related Manuals for Graco Pulse 25T460
Summary of Contents for Graco Pulse 25T460
- Page 1 Instructions ® Pulse Level WiFi Tank Level Monitor 3A8507C Measures the distance between the device and the surface of the fluid to determine the volume of fluid within a tank. For use only with Pulse Level. Intended fluids: oil, diesel, waste oil, automatic transmission fluid (ATF), kerosene, anti-freeze, windshield washer solution, waste water, and DEF.
-
Page 2: Installation
ABS plastic threads. 2. Using a mobile device (e.g. laptop, smart phone, tablet), search for a WiFi network beginning with Connecting to a Network GRACO and connect. 3. Open a web browser and enter “192.168.4.1” into the address bar. Summary Please refer to the instructions in this section, unless 4. -
Page 3: Typical Installation
Installation Typical Installation Error Flash Patterns (LED) No. of Flashes Function Resolution Unable to find WiFi Verify that Connect to network WiFi was selected on the browser Unable to connect to Improve WiFi signal WiFi network strength or enable MAC filtering on the router WiFi password is Verify information... -
Page 4: Installation Examples
Installation Installation Examples Drilling 1. Select a flat area on the top of the tank located towards the center (F . 5). If the tank does not contain a suitable positioned opening at the top of the tank, it will be necessary to 2. -
Page 5: Recycling And Disposal
Installation Recycling and Disposal • Do not dispose of batteries or electronic components with household or commercial waste. End of Product Life • Deliver remaining product to a recycling facility. At the end of the product’s useful life, dismantle and recycle it in a responsible manner. -
Page 6: Replace Batteries
Service Service After the TLM has been installed, the only additional maintenance or service necessary is changing the batteries. Replace Batteries WARNING Fire and Explosion Hazard Sparking can occur when changing batteries. Only 4. Replace the 3.6V C-size battery. See Technical replace the batteries in a non-hazardous location Specifications, page 8, for battery information. - Page 7 Dimension - Tank Specifications Dimension - Tank Specifications Vertical Tank: Obround Tank: • Maximum Volume - 999,999 gallons or liters. • Maximum volume = 999,999 gallons or liters. • Tank walls must be uniformly vertical from empty • Tank end walls must be flat; they cannot be any level to full.
-
Page 8: Technical Specifications
Technical Specifications Technical Specifications Tank Level Monitor (TLM) Metric ® oil, kerosene, diesel, lubricants, additives, DEF/AdBlue , coolants, Compatible Fluids water, waste oil, waste water, automatic transmission fluid (AFT), anti-freeze, and windshield washer solution Ultrasonic Tank Depth Measurement range 5.0 in. to 9 ft. 7 in. 12 cm (minimum) to 300 cm Fluid Level Measurement Accuracy +/- 1.0 in. -
Page 9: Graco Extended Warranty
(including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or property, or any other incidental or consequential loss) shall be available. Any action for breach of warranty must be brought within two (2) years of the date of sale Graco makes no warranty, and disclaims all implied warranties of merchantability and fitness for a particular purpose in connection with accessories, equipment, materials or components sold but not manufactured by Graco. - Page 10 Original instructions. This manual contains English. MM 3A8507 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA Copyright 2021, Graco Inc. All Graco manufacturing locations are registered to ISO 9001. www.graco.com...
