16/01/2021
Wall mount
Guidelines
Use the Sonos Arc wall mount kit. You can buy it on www.sonos.com. Follow the instructions
in the kit.
Keep 4.0" (102 mm) space (minimum) between Sonos Arc and your TV.
Make sure the touch controls are facing up.
For best sound quality, keep both ends of Arc at least 1' (30cm) from a wall or other
obstruction.
Mount kit contents
Wall mount bracket
Positioning guide (don't discard—it may look like packing material)
2 knobs
6 wall anchors
6 screws
Note: Don't discard the positioning guide. It may look like packing material.
If your TV is wall-mounted, place the positioning guide against the wall, aligning the top edge
1.
with the bottom of your TV. There should be 5.5" (140 mm) between the top of the wall
mount bracket and the TV.
https://www.sonos.com/support/en-us/sonos-user-guide/index.html#t=sonos-user-guide%2Farc%2Fwallmountarc.htm
Wall mount
1/6

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sonos ARC

Summary of Contents for Sonos ARC

  • Page 1 Keep 4.0" (102 mm) space (minimum) between Sonos Arc and your TV. Make sure the touch controls are facing up. For best sound quality, keep both ends of Arc at least 1' (30cm) from a wall or other obstruction. Mount kit contents Wall mount bracket Positioning guide (don’t discard—it may look like packing material)
  • Page 2 Mark the screw locations and remove the guide. Refer to Wall mounting information for placement help. If you’re using the included wall anchors, use a 5/16" drill bit to drill the pilot holes and then insert the wall anchors. Don’t use the anchors if you’re drilling into wood or plastic. https://www.sonos.com/support/en-us/sonos-user-guide/index.html#t=sonos-user-guide%2Farc%2Fwallmountarc.htm...
  • Page 3 Use a Phillips-head screwdriver or a power drill to screw the bracket to the wall, making sure the arrows in the center are pointing up. Screw the 2 knobs into the back of the soundbar until they are fully tightened. https://www.sonos.com/support/en-us/sonos-user-guide/index.html#t=sonos-user-guide%2Farc%2Fwallmountarc.htm...

  • Page 4: Wall Mounting Information

    Note: If you’re connecting the cables to the TV at this time, be sure to plug the HDMI cable into the HDMI ARC or eARC port on your TV. Slide the soundbar down so the knobs fit into the slots on the wall bracket. Make sure the touch controls are facing up, and the soundbar is fully seated.

  • Page 5: Important Safety Information

    32° F to 104° F (0° C to 40° C) Storage Temperature -4° F to 122° F (-20° C to 50° C) Control Use your remote control, voice, touch controls, or the Sonos S2 app. Supported Devices Connects to TV with HDMI cable (with or without an attached optical adapter).
  • Page 6 11.Unplug this apparatus during lightning storms or when unused for long periods of time. 12.Refer all servicing to Sonos qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cable or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
