Summary of Contents for Dosy PM-1000
- Page 1 Welcome to the online version of your DOSY Manual. We hope that you find this helpful and informative.
- Page 2 PM-1000 Meter Scale Reading Up to 30 Watts..................30 Scale Up to 300 Watts ................30 Scale X 10 Up to 1000 Watts ................1000 Scale PM-2001 Meter Scale Reading Up to 20 Watts..................20 Scale Up to 200 Watts ................20 Scale X 10 Up to 2000 Watts ................
- Page 3 Peak Watts Figure 1 The PM-1000/PM-2001 watt meter will indicate peak watts when transmitter is modulated. 3. Mode Selector 1. RF Level & Switch Modulation Set SWR Set 1. Turn Mode Selector switch (#3 Fig. 1) to the SWR SET position 2.
