European standard EN 1004
www.marchetti.eu
S M A R T T O W E R
Instructions for use
and maintenance
The products identified in this handbook have
been manufactured by MARCHETTI s.r.l. With
QUALITY SYSTEM MANAGEMENT, certified by Tuv
Italia, in accordance with ISO 9001
Instructions Manual EN 1298 – IM – it x en
Mobile access towers must only be used for finishing, maintenance and similar works. This instructions
manual contains important instructions on use, maintenance and safety of the mobile access tower;
the operator must be completely aware of them before use. Strictly complying with this manual
means working in compliance with the provisions of the current standard on health and safety in the
workplace Leg. Decree. 09.04.2008 no. 81.
MARCHETTI S.r.l.
Via Piemonte, 22
06062 Città della Pieve - Perugia - Italy
Tel. + 39 0578 20348 - Fax + 39 0578 226488
MOBILE ACCESS TOWER
DOC. CUSTOMER ASSISTANCE
N. 136 REV. 0 DEL 23/04/2018
Code 11211
info@marchetti.eu
www.marchetti.eu
Advertisement
Table of Contents
Summary of Contents for Marchetti SMART TOWER
- Page 1 S M A R T T O W E R Instructions for use and maintenance The products identified in this handbook have been manufactured by MARCHETTI s.r.l. With QUALITY SYSTEM MANAGEMENT, certified by Tuv DOC. CUSTOMER ASSISTANCE N. 136 REV. 0 DEL 23/04/2018...
- Page 2 ATTENTION: • Read and understand this manual in its entirety. • Follow the instructions as indicated. • Before any installation, verify the integrity of each individual component. Do not use damaged or not whole components The mobile access tower on wheels is made according to the standards.
-
Page 3: Table Of Contents
Table of elements composing the configurations A1 - A2 - A3 pag. 7 To create configurations with final tower H=0.85 m (A1T-A2T-A3T) pag. 7 simply add the following elements “SMART TOWER” TOWER DESIGN pag. 8 CONFIGURATIONS UNI EN 1004 pag. 9 ASSEMBLY AND DISMANTLING pag. -
Page 4: Reference Standards
“Consumers’ Code”. 2. DESIGNATION, CLASS, CAPACITY SMART TOWER mobile access tower EN 1004 – 3 – 5 / 5 XXCD manufactured in compliance with Leg. Decree 81/08 and Technical Standard EN 1004; Class of loads distributed uniformly equal to “3” (2.0 KN/m2);... -
Page 5: Declaration Of Conformity
MARCHETTI s.r.l. with headquarters in Città della Pieve (Pg) - Via Piemonte, 22: DECLARES - that the mobile tower SMART TOWER was manufactured in compliance with Leg. Decree 09.04.2008 no. 81 and in particular the Technical Standard EN 1004 (July 2005) - that it is manufactured in compliance with the prototype which has surpassed rigidity testing, pursuant to Appendix “A”... -
Page 6: General Information
4. GENERAL INFORMATION 4.1 Access to work platform Access to the work platform can only take place inside the tower using one of the following methods: - vertical rung ladder, composed of beams on the side frames of the structure - inclined rung ladder, internal - inclined step ladder, internal. -
Page 7: Identification
5. IDENTIFICATION EN 1004 - Class “3” (2.00 KN/m Overall permitted load 200 kg Maximum number of surfaces loaded simultaneously Table of elements composing the configurations A1 - A2 - A3 - A4 Code Component Elements Weight CONFIGURATIONS 21386 Smart più 28,00 33815 Foldable base 17,00... -
Page 8: Smart Tower" Tower Design
“SMART TOWER” TOWER DESIGN 21936 HORIZONTAL BRACE 21393 FINAL TOWER 33831 WORK PLATFORM 21387 TOWER 21388 WORK PLATFORM WITH TOEBOARDS 33815 FOLDABLE BASE 20998 STABILIZERS... -
Page 9: Configurations Uni En 1004
CONFIGURATIONS EN 1004 Smart Più H Tower = 1,75 m H Tower = 1,75 m H Work = 1,00 m H Work = 1,00 m H Tower = 3,25 m H Tower = 4,75 m H Tower = 3,66 m H Work = 1,90 m H Work = 3,40 m H Work = 2,50 m... -
Page 10: Assembly And Dismantling
6. ASSEMBLY AND DISMANTLING 6.1 General information For assembly and dismantling of the mobile access towers, at least 2 people are necessary and it is indispensable they are familiar with the assembly and use instructions; b) Based on the height which must be reached, choose to set up one of the configurations outlined on page 9. - Page 11 C) Insert one of the connecting brace, by joining the first rung of the two base bearing frames. D) Place the two bearing frames, taking care to insert the spring pins and verify the cor- rect hooking. E) Hook the two connecting brace at the union between the frames.
- Page 12 I) If the SMART TOWER must be erected to a work platform height above m 1,99, the 4 stabilizers must be fitted. L) Position the stabilizers with an angle of about 120° in relation to the tower’s longer side. Make sure the stabilizer adhere well to the ground.
-
Page 13: Dismantling Instructions
6.4 Dismantling instructions Dismantling of the towers must take place by executing the necessary operations in the inverse order to those for assembly; the elements composing the towers must be lowered from above using ropes or other suitable devices, avoiding sudden impact with the ground. 7. -
Page 14: Movement Procedure
8.3 Movement procedure a) The mobile access towers can only be moved manually, on compact, smooth surfaces free of obstacles, perfectly level and in the absence of wind; b) Before moving, lift the adjustable feet off the ground, if present, and the stabiliser brackets by a quantity not over 20 mm and release the brake on the wheels;... -
Page 15: Instructions For Use And Maintenance
Legislative Decree 09.04.2008 no. 81 www.marchetti.eu CERTIFICATED EN ISO 9001 MOBILE ACCESS TOWER S M A R T T O W E R Instructions for use and maintenance This Instruction Manual must be consulted in conjunction with the EN 1298-IM-it x en... -
Page 16: General Information
10. GENERAL INFORMATION 10.1 Configurations table according to Leg. Decree 81/08 H. max H. max Foldable Tower Final No min No Braces Base Wall Tower work base 1,50 Tower work H< 7m Section anchorage platform platform Every 2 9,66 m 8,40 m n°1... -
Page 17: Information Completion
10.2 Access to work platform It is compulsory to access the work platform inside the tower, the beams on the side support frames composing the access ladder. People responsible for using the mobile access tower must use a fall- proof device connected to the safety harness that limits free falling to no more than 0.70 metres. This device must slide along a rope anchored on top of the last beam of the last side support frame and under the wheel support block of the base section. -
Page 18: Check List
CHECK LIST Mobile access tower Mod. Service of A) Verify that the mobile tower is vertical or requires repositioning B) Verify that the structural assembly is always correct and complete C) Verify that no environmental changes affect the safe use of the mobile tower... - Page 19 CHECK LIST Mobile access tower Mod. Service of A) Verify that the mobile tower is vertical or requires repositioning B) Verify that the structural assembly is always correct and complete C) Verify that no environmental changes affect the safe use of the mobile tower Numerical verification of components Cleaning of components Integrity of components...
- Page 20 Via Piemonte, 22 - 06062 Città della Pieve - Perugia - Italy Tel. + 39 0578 20348 - Fax + 39 0578 226488 info@marchetti.eu - www.marchetti.eu...
