Pola Landscape Light
I n s t a l l a t i o n M a n u a l
•
Dimension : 154 x 600 x 141.5mm
•
Weight : 6kg / 13.2lbs
Step.1
Drill holes (4x) for
Expansion Bolt slip in.
v1.0-20191220
Installation
Step.2
Connect L, N, GND
3 wires
Step.3
M8 Expansion Bolt 4x
Unit : mm
Step.4
Fasten nuts (4x)
Advertisement
Table of Contents
Summary of Contents for Ameco Pola
- Page 1 Pola Landscape Light I n s t a l l a t i o n M a n u a l v1.0-20191220 • Dimension : 154 x 600 x 141.5mm • Weight : 6kg / 13.2lbs Unit : mm Installation Step.1...
- Page 2 Pola Landscape Light I n s t a l l a t i o n M a n u a l v1.0-20191220 Note: 1. Please disconnect the electricity supply when install or conduct maintenance to the luminaires. 2. Luminaires should be installed by a qualified electrician and wired in accordance with national regulations.
