- Page 1 NeoGCP3 NeoGCP3 USER MANUAL Rev.A...
- Page 2 NeoGCP3 Table of Contents 1. Product Configuration 1.1 Product view & Main function ……………………………………………………………………….. 3 1.2 Display …………………………………………………………………………………………………. 4 1.3 Control Buttons ……………………………………………………………………………………….. 4 1.4 Connecter ……………………………………………………………………………………………… 5 2. Control Functions Operation using the button …………………………..……………………………………………… 6 2.2 Operation using the external key switch …………………………………………………………….. 6 3.
- Page 3 NeoGCP3 1. Product Configuration 1.1 Product view & Main function 1) Digital control using the MICOM 2) Display measurement value using the 7-SEGMENT, BAR-LED 3) Engine protection (Over speed, High coolant temp, Low-pressure lubricant) and Generator protection (Over voltage, Over current)
- Page 4 NeoGCP3 9) Digital output: 3 point (Start motor output, Governor or solenoid output, Alarm output) 10) Engine sensor input: 2 point (Coolant temp. sensor, Lubricant pressure sensor) 11) Speed sensor input: 1 point (Min AC 0.7[V] magnetic pickup) 1.2 Display...
- Page 5 NeoGCP3 1.4 Connecter Description Description Item Item VDC+ Supply power to controller Genset Voltage input(1-Phase) VDC - DC 8~32[V] MAX AC 550[V] DI COM+ DI1, DI2, DI3 (+) Common power (VDC+) NC : Not use DI1(-) DI1: High-temp. coolant S/W...
- Page 6 NeoGCP3 2. Control Functions Operation using the button Click [START] button to start-up of the generator After the output of the start motor signal from DO1, start motor signal off automatically when it reaches the following conditions: Speed detected by speed sensor (MPU) is detected at 550 [RPM]...
- Page 7 NeoGCP3 3. Setting the menu 3.1 How to setup menu entry & How to set On the main screen, press [WARNNIG RELEASE] button 5 [s] or more to move to the menu screen. If you want to change the parameters,...
