Summary of Contents for Tricolor Multi-Viewer
- Page 1 User Manual HDMI 4x1 Quad Multi-Viewer With Seamless Switcher - 1 -...
-
Page 3: Table Of Contents
Contents Introduction....................1 Feature....................... 1 Specification....................2 Operation Controls and Functions............2 4.1. Front Panel......................2 4.2. Rear Panel.......................3 Connection Diagram................4 - I -... -
Page 5: Introduction
1. Introduction This product is a high performance 4 by 1 Quad Multi-Viewer with Seamless switcher. It supports four High definition input source display on one screen, and have three multi-view effect mode. As a switcher, it can also seamlessly switch the four HD input freely. The product can be controlled by various ways, through the front panel button control, IR control, RS232 control etc. -
Page 6: Specification
3. Specification Video Bandwidth 2.25Gbps Input Ports 4 × HDMI (Female type) Output Ports 1 × HDMI (Female type), Audio output PCM2, 5.1, 7.1CH, Dolby 5.1, DTS5.1 480i60Hz, 480p60Hz, 576i50Hz, 576p50Hz, 720p50/60Hz, Input Resolution 1080i50/60Hz, 1080p24/30/50/60Hz, 800x600@60, 1024x768@60, 1280x720@60, 1920x1080@60; Output Resolution 1080p, 720p, 1080i,1024x768,1360x768 Human Body model:... -
Page 7: Rear Panel
1) ON/OFF: Power on/off switch. SERVICE: For factory use only. 3) IR : Remote control receiver window. 4) POWER LED: This red LED illuminates when the device is connected with power supply. 5) IN1,2,3,4 LED: These red LED illuminates when the output select to the corresponding input. -
Page 8: Connection Diagram
monitor with HDMI cable for input source display.The UTP port connect to CAT Receiver by CAT5e/6 cable for signal extend.The Coax is where you connect to the amplifier with coaxial cable. IR RX: Connect to the IR Receiver for IR signal reception. Ensure that remote being used is within the direct line-of-sight of the IR receiver. - Page 9 - 5 -...
